Summary of Contents for ARKY AED
- Page 1 Manual ARKY Outdoor cabinet (24V)
- Page 2 0°C. The electronics and metal components of the defibrillator should be kept dry to make sure the AED functions well at all times. Therefore the ARKY AED outdoor cabinet is provided with a waterproof...
-
Page 3: Table Of Contents
CONTENT Components Installation of the cabinet Alarm Electrical Assembly Specifications Declaration of conformity... -
Page 4: Components
COMPONENTS Magnet for alarm Hook for elastic band to keep the AED in place Screw Screw cover Eye for padlock/breakaway seal Thermostat... -
Page 5: Installation Of The Cabinet
INSTALLATION OF THE CABINET Install the cabinet at a place where it will not be exposed to direct sunlight and rainfall. Use the screws to install the cabinet. The screws are fitted with neoprene rings for a watertight seal. IMPORTANT The adapter and cables are not waterproof and should therefore be stored in a dry, frost free place. -
Page 6: Electrical Assembly
ELECTRICAL ASSEMBLY The cabinet is supplied with a 55W heating element. A thermostat controls the temperature in the cabinet and keeps it frost free. For safety reasons the installation of the outdoor cabinet to the electricity grid should only be carried out by a certified electrician. It is important that the cabinet is connected to an electricity grid with an Earth Leakage Circuit Breaker. -
Page 7: Specifications
SPECIFICATIONS Weight: 3,6 kg Outside dimensions 34 x 40 x 20 cm (HxWxD) Inside dimensions 28 x 32 x 18 cm (HxWxD) ELECTRICAL SUPPLY Heating element 55W Feed: AC 100-240 V ~1,5 A 50 ~ 60 Hz Feed: DC 24V,5A ALARM Feed: 3 button cell batteries LR44... -
Page 8: Declaration Of Conformity
Defibrion bv Verlengde Bremenweg 12 9723 JV Groningen Product: AED Outdoor Cabinet Dit product is ontwikkeld en geproduceerd volgens en in overeenstemming met de volgende normen en voorschriften: This product complies with the essential requirements and provisions of following standards and methods:...
