Summary of Contents for Cartizan WCAM-26T
- Page 1 Total Solution for Car Audio & Video Interface User Manual Model No.: WCAM-26T Digital Video to Wi-Fi Transmitter Cartizan Technology | www.icartizan.com...
-
Page 2: Table Of Contents
Total Solution for Car Audio & Video Interface CONTENTS 1. Overview ................................3 2. Specification ..............................4 3. Packing List ............................... 5 4. Connection Diagram ............................6 5. Operation Instruction ............................7 6. Special Remark ............................... 10 Cartizan Technology | www.icartizan.com... -
Page 3: Overview
Auto trigger the Android phone even under locked（You should activate the App manually on iPhone） Excellent design for cable plug, preventing short circuit or loose connection APP supports both Android and iOS. Compact design, plug and play installation. 3 / 10 Cartizan Technology | www.icartizan.com... -
Page 4: Specification
Camera on: 190mA / Camera off: 68mA Booting Time 4 seconds Video Standard PAL / NTSC Transmit Power 135M:13dB; 54M:13dB ; 11M:17dB Max Transmission Distance Working Temperature -40 to +85°C Suitable OS Android / iOS 4 / 10 Cartizan Technology | www.icartizan.com... -
Page 5: Packing List
Total Solution for Car Audio & Video Interface 3. Packing List 5 / 10 Cartizan Technology | www.icartizan.com... -
Page 6: Connection Diagram
Total Solution for Car Audio & Video Interface 4. Connection Diagram Supports Android smart phone, iPhone and aftermarket Android head unit 6 / 10 Cartizan Technology | www.icartizan.com... -
Page 7: Operation Instruction
② Record, click to record, icon turns red, click again to stop record. ③ Screen capture, click to capture the current screen. ④ Review, review the recorded videos and pictures. ⑤ Setting, setting options are as below: 7 / 10 Cartizan Technology | www.icartizan.com... - Page 8 Camera Switch, power supply for camera controlled by App, switch on to supply power for camera, and then the video appears. (Suggest: keep switch off unless using front view camera or DVR.) Brightness, Brightness adjustment Contrast, Contrast adjustment 8 / 10 Cartizan Technology | www.icartizan.com...
- Page 9 Horizontal/Vertical Mirror, Camera video is flipped horizontally/vertically New SSID, set name of the Wi-Fi hotpot New Password, set password of Wi-Fi (no less than 8 characters), it won't take effect until restart. (Note: Default setting is no password) 9 / 10 Cartizan Technology | www.icartizan.com...
-
Page 10: Special Remark
The App will run for 2 hours in the background by default. ② Some phones cannot auto connect the Wi-Fi under locked，in case of this situation, please keep your phone unlocked until the Wi-Fi is connected. 10 / 10 Cartizan Technology | www.icartizan.com...
