Page 1: Hardware Guide
Aport-214PG FreeRTOS Programmable Device Server Hardware Guide Version: 1.0 2018 APR. Copyright © Artila Electronics Co., Ltd. All Rights Reserved... - Page 2 Aport-214PG Hardware Guide Trademarks The Artila logo is a registered trademark of Artila Inc. All other trademarks or registered marks in this manual belong to their respective manufacturers. Disclaimer Information in this document is subject to change without notice and does not represent a commitment on the part of Artila.
- Page 3 Aport-214PG Hardware Guide Document Amendment History Revision Date Remark V 1.0 2018 Apr. Initial ARTILA...
-
Page 4: Table Of Contents
Aport-214PG Hardware Guide Table of Contents Introduction ....................5 Features....................5 Specifications ..................5 Packing List ..................6 Optional Accessory ................6 Layout ......................7 Outline ....................7 Dimension ..................... 8 Pin Assignment and Definition..............9 LED Indicator ..................9 Power In: (+9 ~ +48VDC) .............. -
Page 5: Introduction
Software developer can use powerful Atmel Studio to program to compile and debug their applications. Lots of example programs are included for users to jump start their applications. A Manager utility is included to discover Aport-214PG and upgrade its application firmware remotely. -
Page 6: Packing List
Packing List Aport-214PG: Programmable device server Software toolchain (download from Atmel web support) Manager Utility (download from Artila web) Optional Accessory DK-35A (36-DK35K-000): DIN RAIL Mounting Kit PWR-12V-1A (31-62100-000): 110~240VAC to 12VDC 1A Power Adaptor... -
Page 7: Layout
Aport-214PG Hardware Guide 2. Layout 2.1 Outline ARTILA... -
Page 8: Dimension
Aport-214PG Hardware Guide 2.2 Dimension Unit=mm ARTILA... -
Page 9: Pin Assignment And Definition
3. Pin Assignment and Definition LED Indicator The LED provides the Aport-214PG operation information described as follow: RDY: Ready LED keeps ON when Aport-214PG software is ready for operation. PWR: Power LED keeps ON if power (+9VDC to +48VDC) is correct. ... -
Page 10: Rs-485 Serial Port (D1 & D2)
The Aport-214PG equips on-board 120Ohm termination resistor for each RS-485 port. Default setting is disable termination resistor. In order to enable termination resistor, please remove the top cover of the Aport-214PG, and the adjust the associated jumper to short position1 - 2, shown below:...
