WASD V3 User Manual

V3 / V3B User Manual
The V3 keyboard features a DIP switch on the backside of the keyboard to enable or disable various modes of function.
Box Contents
1. Mechanical Keyboard
2. USB Cable
3. Wire Keycap Puller
DIP Switch Settings
Unplug keyboard before changing DIP switch positions. Plug keyboard back in for new settings to take effect.
Switch State Function
SW 1 Off
User Programmed Layer
SW 2 Off
SW 1 On QWERTY Mode (non-
SW 2 Off programmable)
SW 1 On
Mac Mode
SW 2 On
SW3 Off Scroll Lock LED = Current Layer LED
SW3 On Scroll Lock LED = Scroll Lock LED
SW4 Off / On Factory Reset
SW5 Off Fn Key Enabled
SW5 On Fn Key Disabled
SW6 Off Pgm Key Disabled
SW6 On Pgm Key Enabled
*Keyboard must be powered off to switch modes.
Version 0.14 Firmware
x1
x1
x1
Notes
Default is "QWERTY"
Standard QWERTY Layout
User cannot program the 1 – 4 layers
QWERTY Layout, programmable
Reverses Alt and OS Key Positions
This action will revert all keyboard settings back to factory defaults. Unplug keyboard
and set SW4 on. Plug in keyboard. All indicator LED's will flash red for 20 seconds and
then turn solid green which means factory reset is complete.
When Fn Key is enabled, you can access the built in multimedia and lighting control
keys.
Default position of the Fn Key is the Menu Key.
Enable the Pgm Key to access the keyboard's programming functions.
Default position of the Pgm Key is the right Ctrl Key.
