Summary of Contents for TUCAN SYSTEMS iLevil2 AW
- Page 1 iLevil Wireless Integrated Avionics Module Instruction Manual AD-AHRS, GPS, ADS-B 978 / 1090 MHz Receiver...
-
Page 2: Gps Antenna
iLevil 2 AW ADS-B ANTENNA STATIC PRESSURE DYNAMIC PRESSURE GPS ANTENNA ON/OFF SWITCH CHARGING LED ADS-B LED POWER/ GPS LED MINI USB PORT DB15... -
Page 3: Package Contents
When using the iLevil AW as a “portable” device, you must first charge the internal batteries: • Charge the iLevil2 AW fully using the USB cable and dual 12V car charger supplied. • You may use the 1amp socket for the iLevil and the 2amp socket for your tablet. - Page 4 Alignment • Attach the supplied ADS-B antenna and GPS antenna. See top label for reference. • Align the airplane icon on the iLevil’s top label with the roll axis of your aircraft. ON/OFF switch should face the back of the aircraft. Pressure ports and Antenna connectors should face the front.
- Page 5 Connecting to your favorite App The iLevil series offers the most compatibility with Apps on both iOS and Android platforms. • Turn ON your iLevil by flipping the ON/OFF switch. (LEDs will light up) • Tap Settings icon on your tablet. •...
-
Page 6: Led Indicators
LED Indicators Label Status Slow Blink Green: Power ON / No GPS Fix Power/GPS Solid Green: Power ON / GPS fix acquired Off: Power Off Slow Blink Green: Traffic Received ADS-B Solid Green: Weather and traffic received Off: No traffic or Weather received Solid Green: Charging Charging... -
Page 7: Magnetic Heading
Magnetic Heading There are two ways to obtain heading information from the iLevil, depending on the navigation App of choice, you may choose between the following: - True Track: Heading information based on GPS track. - Magnetic Heading: Heading information determined by a combination of 3-axis magnetometer and gyros that form part of the internal AHRS. -
Page 8: Specifications
Specifications AHRS WIFI • 360 degree pitch and bank operation • Android and iOS compatible • GPS Independent attitude. • Supports up to 10 devices connected • 300 deg/sec max turn rate simultaneously (UDP broadcast) • 4Gs max rating. • Supports multiple protocols: •... -
Page 9: Environmental Requirements
Environmental requirements • Temperature range: -10° to 40 ° C (14 ° F to 104 ° F). • Clear view to sky for best GPS reception. • For best ADS-B reception line of sight view with ADS-B ground based towers and min 2000 ft. •... - Page 10 Levil Data Relay The iLevil2 AW features three RS-232 serial ports that can be used for data transfer between tablets and other avionics in the cockpit. For more information check the iLevil Relay feature on our website. DB15 pin description...
-
Page 11: Helpful Tips
• We are always innovating! Stay up to date with Levil developments and App integrations by filling out the Warranty registration card and check the “sign me up for newsletters” checkbox. • iLevil2 AW comes with a standard ADS-B antenna, however, external antennas are also available on our website for remote mount applications: www.shop.levil.com •... -
Page 12: Warranty
Please register your product online, or by filling out the product registration form enclosed. Contact Us Technical Support: General Information: Sales: 407-542-3971 407-542-3971 407-542-3971 techsupport@levil.com info@levil.com sales@levil.com www.aviation.levil.com/support www.aviation.levil.com www.aviation.levil.com powered by TUCAN SYSTEMS...
