Summary of Contents for Planar PLL2251MW
- Page 1 PLL2251MW LCD Monitor...
-
Page 2: Table Of Contents
Advanced Operation—OSD Menu ......................... 13 About the Stand ......... 16 Supporting Timing Modes ............................17 Technical Information ..............................18 Wall-mount instruction............................... 19 Care and Maintenance ..............................20 Troubleshooting ................................20 Planar Support ................................21... -
Page 3: Operation Instructions
Operation Instructions Thank you for purchasing the PLL2251MW LED LCD monitor. Please read this guide thoroughly before installation. FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This LED LCD Monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 4 COMMUNIQUE D’AVERTISSEMENT DE LA FCC CONCERNANT LES INTERFERENCE DE FREQUENCE RADIO: (SEULEMENT POUR MODELES CERTIFIE PAR LA FCC) Ce moniteur a été testé et à été trouvé conforme aux limites pour un appareil numérique de Classe B, suivant la partie 15 des règlements de la FCC. Ces limites ont été développées pour offrir une protection satisfaisante contre les interférences nuisibles dans une installation résidentielle.
-
Page 5: Unpacking Instructions
Unpacking Instructions Move the LED Monitor out of the package and take off the plastic bag and Polystyrene Foam. Remove base from plastic bag and attach to base. Adjust the Panel between -5° leaning forward and 15° leaning backward. Safety Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. -
Page 6: Consignes De Sécurité
Consignes de sécurité Respectez tous les avertissements, les précautions et conseils d’entretien recommandés dans ce manuel de l’utilisateur pour maximiser la durée de vie de votre appareil. A faire : Éteindre le produit avant de le nettoyer. La surface de l'écran tactile peut être nettoyée avec un chiffon doux et propre imprégné d’un nettoyant doux du commerce pour vitres ou d'un mélange à... -
Page 7: Package Overview
Package Overview LED LCD Monitor s ’ r... -
Page 8: First Setup
First Setup Install the stand base 1. Lay the LED LCD Monitor flat on a table with the LED screen face down. To prevent the LED LCD Monitor from being scratched, put a piece of soft cloth on the table on which the screen will be set. -
Page 9: Front View Of The Product
Front View of the Product OSD Menu On/Off Brightness*/ Scroll Down/ Adjust Decrease Blue Light Reducer* / Scroll Up/ Adjust Increase Input Select/ Confirm Select Power On/Off LED Indicator . -
Page 10: Rear View Of The Product
Rear View of the Product HDMI input (HDMI 19 pin) VGA input (D-Sub 15 pin) Audio input Power input (AC input) -
Page 11: Quick Installation
Quick Installation 1. Connect either VGA or HDMI Video Source from the monitor to the computer. Make sure both monitor and computer are powered OFF. 2. Connect the audio cable from audio output of computer to the audio input of the monitor. 3. -
Page 12: Basic Operation
Basic Operation Before using the LED LCD monitor: Connect external equipments properly. Insert the power plug, and the power LED indicator will light orange. Power On/Off To turn the LED LCD monitor on/off: Press button on the front of LED LCD monitor. The power LED indicator lights blue when the LED LCD monitor is on. - Page 13 Option 2: OSD & Power button lock – all 5 buttons including the “POWER” button are locked. Press and hold the 1 button and the ▼ button for 3 seconds to lock all 5 buttons. The LED Monitor will show a “Lock Out” message for 3 seconds and the message will disappear automatically.
-
Page 14: Advanced Operation-Osd Menu
Advanced Operation—OSD Menu You can use the OSD menu to adjust various settings for your LED LCD monitor . Press the 1 button to display the OSD Menu, and use ▲▼ to select the desired OSD menu. Short Cuts Function from the button(s) AUTO IMAGE ADJUST: To auto adjust Horizontal Position, Vertical Position, Phase (Fine Tune) and Clock (H. - Page 15 OVER DRIVE: Allows the user to change the Over Drive strength. Improve the quality of the motion pictures. INPUT SELECT: When Input Select is pressed, change Input signal to VGA, HDMI, or Auto. AUDIO ADJUST: To adjust the audio functions. VOLUME: To adjust the volume of speaker output.
- Page 16 MANUAL IMAGE ADJUST: To manually adjust the HORIZONTAL SIZE, H. /V. POSITION, FINE TUNE and SHARPNESS. H./V. POSITION: To adjust the horizontal and vertical position of the video. HORIZONTAL POSITION: ▲: move screen to the right, ▼: move screen to the left. VERTICAL POSITION: ▲: move screen up, ▼: move screen down.
-
Page 17: About The Stand
About the Stand The stand allows you to easily adjust the height, swivel, tilt, and portrait mode of your monitor to provide maximum ergonomic comfort. 1) Height adjustment 2) Swivel 160° 160° 130mm 3) Tilt 4) Pivot -5~20° 90° 90°... -
Page 18: Supporting Timing Modes
Supporting Timing Modes STANDARD RESOLUTION 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA... -
Page 19: Technical Information
Technical Information Technical Specification Panel 21.5” TFT (with LED backlight) Power Management Normal On: 25 Watts (typical), 28 Watts (maximum) ECO Mode 1 On: 18 Watts (typical) ECO Mode 2 On: 15 Watts (typical) ECO Mode 3 On: 12 Watts (typical) Standby Mode: <... -
Page 20: Wall-Mount Instruction
Wall-mount instruction Preparing To Install The Optional Wall Mount Arm (not included) This LED LCD Monitor can be attached to a wall mounting arm purchased separately. Turn the power OFF then disconnect the cables from the LED LCD Monitor before performing the procedure below. 1. -
Page 21: Care And Maintenance
Care and Maintenance Care Avoid exposing your LED LCD monitor directly to sunlight or other heat source. Place your LED LCD monitor away from the sun to reduce glare. Put your LED LCD monitor in a well ventilated area. ... -
Page 22: Planar Support
Planar Support Cables and Accessories To find cables and accessories for your Planar monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com Technical Support Visit Planar at http://www.planar.com/support for operations manuals, touchscreen drivers, warranty information and access to Planar's Technical Library for online trouble shooting. - Page 23 Planar, a Leyard company 04/2018 Planar, a Leyard company Planar, a Leyard company. 3 0 0 11 0 0 0 1 9 4 2 0 0 0...
