Instruction Manual

Belt-Driven Reciprocating
Air Compressors
Revision: 2019-06-07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T20D and is the answer not in the manual?

Questions and answers

john peters
June 23, 2025

HOW DO I ADJUST THECUT OFF AT 110 PSI AIRMAC TE20 WORK HORSE

0

Subscribe to Our Youtube Channel

Summary of Contents for AIRMAC T20D

  • Page 1: Instruction Manual

    Instruction Manual Belt-Driven Reciprocating Air Compressors Revision: 2019-06-07...
  • Page 2 If after reading this manual you still have any questions or concerns about your compressor, please contact your local authorised Airmac dealer or Glenco Air & Power Pty Ltd before operating the unit. This manual should be considered a permanent part of the compressor and should remain with it if resold.

  • Page 3: Table Of Contents

    Instruction Manual Airmac Air Compressors Contents Safety ……………………………………………….………………………………….…………………. Product Familiarisation ……….…………………….……………………………………………. Application and Function ………………………………………………………………………… Receipt and Inspection …….……………………………..........Installation ……………………………..……………………………………………………………….. Operation …….…………………………………………………………………………………………. Maintenance and Repair ……….………………………………………………………………… Troubleshooting ………..………………………………………………………………………….. Transport ……………...………………………………………………………………………………… 10.0 Storage ………………………….………………………............ 11.0 Dismantling and Disposal ..………………............12.0 Specifications …………………………………………………………………………………………..

  • Page 4: Safety

    Instruction Manual Airmac Air Compressors Safety The air compressor set should only be operated by authorised persons. All users should follow the instructions and safety warnings as (a) described in this instruction manual, (b) shown on any decals affixed to the unit and (c) described in the Plant Risk Assessment that’s also available from the manufacturer.
  • Page 5 Instruction Manual Airmac Air Compressors Always refuel an engine-powered compressor outdoors in a well-ventilated area. Do not remove the fuel cap or refuel the compressor while the engine is running. Always turn engine off and allow it to cool down before refuelling. Do not overfill the fuel tank; leave room for the fuel to expand. Check for fuel leaks after refuelling.
  • Page 6 Instruction Manual Airmac Air Compressors Rusted, cracked or damaged air receiver tanks can explode and cause death or serious injury and must be replaced. Drain tank daily or after each use through valve located at bottom of tank. Release compressed air from the tank before servicing. Do not weld, drill or otherwise modify the air receiver tank.

  • Page 7: Product Familiarisation

    Instruction Manual Airmac Air Compressors Product Familiarisation The major components and primary controls of the various compressor types within the Airmac range are identified in Figures 2-1 to 2-7 below. Users should familiarise themselves with their own compressor’s features. Item...
  • Page 8 Instruction Manual Airmac Air Compressors Item Description Item Description Compressor Pump Pallet Foot Mount Air Filter Vibration Isolator Crankcase Breather Non-Return Valve Oil Fill Cap Unloading Line Oil Drain Plug Safety Valve Oil Level Sight Glass Drain Valve Electric Motor...
  • Page 9 Instruction Manual Airmac Air Compressors Item Description Item Description Compressor Pump V-Belt Drive Guard Air Filter Pallet Foot Mount Crankcase Breather Non-Return Valve Oil Fill Cap Unloading Line Oil Drain Plug Safety Valve (Behind Item 18) Oil Level Sight Glass...
  • Page 10 Instruction Manual Airmac Air Compressors Item Description Item Description Compressor Pump Non-Return Valve Unloading Line Air Filter Head Unloading Line Crankcase Breather Safety Valve (Behind Item 18) Oil Fill Cap Drain Valve Oil Drain Plug Discharge Outlet Valve Oil Level Sight Glass...
  • Page 11 Instruction Manual Airmac Air Compressors Item Description Item Description Compressor Pump Pallet Foot Mount Air Filter Non-Return Valve Crankcase Breather Unloading Line Electric Motor Safety Valve (Behind Item 15) Motor Position Adjustor Drain Valve Air Receiver Tank Discharge Outlet Valve...
  • Page 12 Instruction Manual Airmac Air Compressors Item Description Item Description Compressor Pump Wheel Air Filter Handle Crankcase Breather Non-Return Valve Oil Fill Cap Easy-Start Valve Oil Drain Plug Head Unloading Line Oil Level Sight Glass Safety Valve (Behind Item 21) Petrol Engine...
  • Page 13 Instruction Manual Airmac Air Compressors Item Description Item Description Compressor Pump Wheel Air Filter Non-Return Valve Crankcase Breather Easy-Start Valve Oil Fill Cap Head Unloading Line Oil Drain Plug Safety Valve Oil Level Sight Glass Drain Valve Diesel Engine Air Receiver Pressure Gauge...

  • Page 14: Application And Function

    Airmac Air Compressors Application and Function Your Airmac air compressor is an air cooled, reciprocating type. Depending on the model, it is fitted with either an oil lubricated or oil free compressor pump, which will feature either single-stage or two-stage compression. It is typically supplied as a compact, self-contained, air receiver tank mounted unit that is automatically regulated and driven by an electric motor or internal combustion engine through V-belts.
  • Page 15 Airmac air receiver tanks are designed and manufactured to comply with the requirements of Australian Standard AS 1210 and all Australian Workplace Health and Safety Regulations. A copy of the Manufacturer’s Data Report (as per AS 4458) is available from your Airmac dealer or Glenco Air & Power Pty Ltd upon request.

  • Page 16: Receipt And Inspection

    Airmac dealer immediately. Do not operate unit if damaged during shipping, handling or use. Read the compressor model label to verify it is the correct one as ordered. For electric compressors, check the motor nameplate to verify that it is compatible with the available electricity supply.

  • Page 17: Installation

    Instruction Manual Airmac Air Compressors Installation Handling Remove the air compressor from its shipping carton and pallet before mounting. Do not use the timber shipping pallet for mounting the compressor. Portable wheel-mounted compressors should only be lifted manually as a last resort and always as a joint lift by at least two persons.
  • Page 18 Instruction Manual Airmac Air Compressors stress on the air receiver tank. Use metal shims to pack under any “short” feet, if necessary, which is most often due to the floor surface not being perfectly level rather than the mounting feet being uneven.
  • Page 19 Instruction Manual Airmac Air Compressors Figure 5-1 Freestanding Foot-Mounting Arrangement The compressor can be bolted to a firm, level foundation that is strong enough to support its weight such as a concrete floor or alternatively secured to a vehicle chassis or tray for mobile applications.
  • Page 20 Instruction Manual Airmac Air Compressors Figure 5-3 Preferred Bolted-Down, Foot-Mounting Arrangement – Option 1 (c) Another preferred method as shown in Figure 5-4 is for the compressor set to be mounted on correctly selected and installed industrial vibration isolators. Specialist providers include Mackay (www.mackayrubber.com.au) and Embelton (www.embelton.com).
  • Page 21 Instruction Manual Airmac Air Compressors Figure 5-5 Prohibited Bolted-Down, Foot-Mounting Arrangements Ambient Temperature The air compressor is designed for operation in ambient temperatures of between 0°C (32°F) and 40°C (104°F). Where possible in hot areas, the compressor should be operated in the shade to prevent additional heat load due to solar radiation.
  • Page 22 Instruction Manual Airmac Air Compressors remote air inlets, relocate the compressor, or construct a ventilated enclosure or baffle walls. Discharge and Condensate Piping All piping, fittings, air receiver tanks, and so on connected to the compressor discharge must be certified safe for the unit’s discharge pressure and temperature. Do not use PVC plastic in the compressed air discharge line.
  • Page 23 Instruction Manual Airmac Air Compressors Table 5-2 Recommended Minimum Hose ID for Compressed Air Lines Length of Hose (metres) Flow (L/m) ⅜” ⅜” ⅜” ⅜” ⅜” ⅜” 1,132 ½” ½” ½” 1,698 ¾” ¾” ¾” To convert metres to feet, multiply by 3.281. To convert L/min to cfm, divide by 28.3.
  • Page 24 Instruction Manual Airmac Air Compressors duty 15 Amp socket. Compressors fitted with a heavy duty three-pin 15 Amp plug (on which the earth pin is noticeably larger in cross-section than the other two pins) must only be connected to a heavy duty 15 Amp socket.
  • Page 25 Ideally, it is recommended to use a performance matched Airmac 12 Volt battery kit that is available from your local authorised Airmac dealer; as shown in Figure 5-8, the kit includes a battery, battery mounting bracket, battery clamp, colour-coded battery cables and the requisite fasteners.
  • Page 26 Instruction Manual Airmac Air Compressors Table 5-5 12 Volt Battery Requirements Cold Cranking Capacity Engine Make & Model Performance (Ah) (CCA) Honda GX200 Not Specified Honda GX270 Not Specified Honda GX390 Not Specified Yanmar L48 Yanmar L70 Yanmar L100 Observe the following procedure for connecting the battery to your compressor: (a) Connect the battery positive (+) cable to the starter solenoid terminal as shown in Figure 5-6.
  • Page 27 Instruction Manual Airmac Air Compressors Figure 5-7 Battery Negative (-) Cable Connection to Engine Mounting Bolt Figure 5-8 Airmac 12 Volt Battery Kit Installed 2019-06-07 © Glenco Air & Power Pty Ltd...

  • Page 28: Operation

    Instruction Manual Airmac Air Compressors Operation Precautions Before operating the air compressor, always check first to ensure that it has been received, inspected and installed in accordance with the instructions herein. Rectify any discrepancies before proceeding further. Check the compressor pump’s oil level by looking at the sight glass. The oil level should be at the top of the red circle or at the “H”...
  • Page 29 Instruction Manual Airmac Air Compressors Figure 6-2 Filter-Regulator Condensate Drain Valve in the Semi-Automatic Position 240 Volt Single Pump Air Compressors Check that the electricity supply is turned off. Check that the compressor’s pressure switch is turned to the OFF position marked “0”.
  • Page 30 Instruction Manual Airmac Air Compressors threaded male air line fitting. Check that the threaded connection is secure by ensuring that it has been properly tightened and also by trying to pull the air hose or pipe away from the outlet valve.
  • Page 31 Instruction Manual Airmac Air Compressors 650 kPa (94 psi) or 950 kPa (138 psi) depending on the model. It will also stop automatically whenever the air receiver pressure reaches the pre-set cut-out pressure of approximately 870 kPa (126 psi) or 1,200 kPa (174 psi), respectively, depending on the model.
  • Page 32 Instruction Manual Airmac Air Compressors hold it there until the engine starts. Release the key as soon as the engine starts. Do not engage the electric starter for more than five seconds at a time. (b) If the engine doesn’t start, release the key and wait 10 seconds before repeating the previous step.
  • Page 33 Instruction Manual Airmac Air Compressors instruction manual for the diesel engine. Do not touch the engine throttle control lever; it will operate automatically. To start using the engine’s recoil (or “rope”) starter: (a) Turn the engine control switch clockwise to the “ON” position using the ignition key, if fitted.
  • Page 34 Instruction Manual Airmac Air Compressors hand side of the engine behind the oil filler cap / dipstick and pull it forwards. Hold firmly until the engine stops. Refer to Figure 6-3. (b) For engines with an electric starter: Turn the ignition key anticlockwise to the “OFF” position.

  • Page 35: Maintenance And Repair

    The maintenance tasks recommended herein can generally be undertaken by anyone with proficient mechanical ability and access to proper tools. Alternatively, your Airmac dealer can carry out this work. For best results, the following repair procedures should always be observed: (a) Use new gaskets, seals and O-rings during reassembly.
  • Page 36 Instruction Manual Airmac Air Compressors Table 7-1 Recommended Maintenance Schedule for Oil Lubricated Compressors Elapsed Time or Operating Hours (whichever occurs first) 3 Mths 1 Year 2 Years Activity 1 Day 1 Week Month 500 h 2,000 h 4,000 h Check Oil Level ●...
  • Page 37 Instruction Manual Airmac Air Compressors ambient temperature range in which the compressor will be operating. The compressor pump has been filled at the factory with SAE 15W-40 mineral based engine oil that is suitable for ambient temperatures from −15°C (5°F) to over 40°C (104°F). Mineral based, semi-synthetic or fully synthetic oils may be used, but different types of oils should not be mixed together.
  • Page 38 Instruction Manual Airmac Air Compressors If there’s an excessive accumulation of condensate during compressor operation or the system is not depressurised after use, the condensate should be evacuated manually by turning the drain valve handle until the arrow symbol is pointing vertically downwards (▼).
  • Page 39 Instruction Manual Airmac Air Compressors Do not tamper with the safety valve. It is designed to automatically release air if the tank pressure exceeds a pre-set maximum. Air Tightness While the air receiver tank is pressurised to at least 650 kPa (94 psi) and the compressor is switched off, listen for any audible air leaks.
  • Page 40 Airmac Air Compressors 7.11 12 Volt Battery If the compressor is equipped with a genuine Airmac 12 Volt battery kit, the battery is a sealed-for- life type that requires no regular maintenance. It is automatically charged whenever the compressor is running.
  • Page 41 Instruction Manual Airmac Air Compressors 7.14 Fastener Torques Table 7-3 Recommended Assembly Torques Thread Spanner Size Size Torque Torque Item (mm) (mm) (Nm) (lbf-ft) Fusheng CA-51 Cylinder Head Bolt Fusheng VA-51 Cylinder Head Bolt 16.2 Fusheng C/V/TA-65 Cylinder Head Bolt 16.2...

  • Page 42: Troubleshooting

    It is recommended for your convenience that this troubleshooting guide be consulted prior to contacting an Airmac dealer or Glenco Air & Power Pty Ltd for advice. Additional technical information is available online for download at www.glencoairpower.com.au.
  • Page 43 Instruction Manual Airmac Air Compressors Table 8.1 Troubleshooting Chart Symptom Possible Cause Corrective Action 9. 415 V, < 11 kW: Thermal 9. 415 V, < 11 kW: Manually overload relay in pressure reset pressure switch to switch tripped. the “AUTO” position.
  • Page 44 Instruction Manual Airmac Air Compressors Table 8.1 Troubleshooting Chart Symptom Possible Cause Corrective Action or totally seized. compressor pump. 11. Engine fault. 11. See engine manual. Compressor pump does not 1. Loose engine or motor 1. Tighten or replace pulleys come up to speed.
  • Page 45 Instruction Manual Airmac Air Compressors Table 8.1 Troubleshooting Chart Symptom Possible Cause Corrective Action unable to reach cut-out compressor pump larger or additional pressure. capacity. compressor(s). 2. Air leaks. 2. Tighten, refit or replace leaking connections or components. 3. Blocked or dirty inlet air 3.
  • Page 46 Instruction Manual Airmac Air Compressors Table 8.1 Troubleshooting Chart Symptom Possible Cause Corrective Action pumping mode and unloading when air demand is at 50% reduce with either or off mode. of compressor output. decreased or increased compressed air demand. 2. Air leaks.
  • Page 47 Instruction Manual Airmac Air Compressors Table 8.1 Troubleshooting Chart Symptom Possible Cause Corrective Action 3. Blocked or faulty non- 3. Clean, repair or replace return valve. non-return valve. Short initial discharge of air 1. Correct function of the 1. Nil (no fault).

  • Page 48: Transport

    Instruction Manual Airmac Air Compressors Transport Always switch off the air compressor and de-pressurise the air receiver tank before transporting the unit. Turn the engine fuel valve off, if fitted, and always keep the compressor upright to prevent oil or fuel spillage.

  • Page 49: Dismantling And Disposal

    / overhaul or prior to final disposal at the end of its service life. Dismantling should only be carried out by a mechanically proficient person with access to proper tools or alternatively by your Airmac dealer. Before dismantling the compressor, switch off the unit, disconnect the power supply, turn off the fuel supply valve, carefully de-pressurise and drain the air receiver tank, drain out the fuel tank and piping, and drain the lubricating oil from the compressor pump and engine.

  • Page 50: Specifications

    Instruction Manual Airmac Air Compressors 12.0 Specifications 12.1 240 Volt Electric Air Compressors Fusheng Cut-Out Max. Electric Tank Outlet Airmac Displ. Weight Pump Pressure Pressure Motor Vol. Size Model (L/min) (L/min) (kg) Model (kPa) (kPa) (kW) VA-65 1,000 1.65 1/4"...
  • Page 51 T30D ES TA-80 1,000 Electric 1/2" B35D ES 1,200 L100 Electric 3/4" V40D ES VA-100 1,105 1,000 L100 Electric 3/4" T20D MFC TA-65 1,000 Rope 1/4" T20D MFC ES TA-65 1,000 Electric 1/4" 2019-06-07 © Glenco Air & Power Pty Ltd...

  • Page 52: Wiring Diagrams

    Instruction Manual Airmac Air Compressors 13.0 Wiring Diagrams 13.1 11 kW Star-Delta Starter Wiring Diagram 2019-06-07 © Glenco Air & Power Pty Ltd...

  • Page 53: Warranty Against Defects

    14.3 Warranty Conditions Glenco Air & Power Pty Ltd (the “Company”) warrants that its Airmac air compressors (the “Goods”) shall be free from defects in material and workmanship for a period of twenty-four (24) months from the date of original sale (hereinafter the “Warranty Period”).
  • Page 54 Instruction Manual Airmac Air Compressors and availability of replacement parts. The Company shall not be obligated, however, to repair or replace Goods which have been: repaired by others; abused; improperly installed, operated, maintained, repaired, transported or stored; not serviced to schedule using genuine spare parts; altered or otherwise misused or damaged in any way.

  • Page 55: Record Of Maintenance And Repair

    Instruction Manual Airmac Air Compressors 15.0 Record of Maintenance and Repair Date Maintenance or Repair Activity 2019-06-07 © Glenco Air & Power Pty Ltd...
