- Page 1 INSTRUCTION MANUAL TV Stand Media Console SKY3766 + SKY3767 + SKY3768 Ver. 2...
- Page 2 NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. • Do not stand on or use any part of this item as a step ladder. • Firmly secure all bolts, screws and knobs before use. •...
- Page 3 PARTS DIVIDER RIGHT SIDE BOTTOM 1 PC 1 PC 1 PC LEFT SIDE DRAWER BACK MIDDLE SHELF 1 PC 1 PC 1 PC BACK TABLETOP LEFT PANEL 1 PC 1 PC 1 PC RIGHT PANEL BACK PANEL DRAWER BOTTOM 1 PC 1 PC 1 PC FRONT PANEL...
- Page 4 PRODUCT ASSEMBLY Attach the part 11 slider set (L/R) to the part B right side and part A divider with six part 3 screws, three screws per slider railing. NOTE: Slide the railing back and forth to reveal the screw holes. Attach the right side and divider to the part C bottom with four part 7 cam bolts, two part 10 dowels, and four part 8 cam locks.
- Page 5 PRODUCT ASSEMBLY Attach the part D left side with two part 7 cam bolts, two part 10 dowels, and two part 8 cam locks. Turn the cam locks to secure the left side. Insert two part 9 cam caps. NOTE: Use part 13 glue to secure the dowels. Slide in part E drawer back.
- Page 6 PRODUCT ASSEMBLY Unscrew the connecting plate from four part 12 legs. Attach four connecting plates with sixteen part 2 screws, four screws per plate. Screw the legs back onto the connecting plates. Stand the assembly upright. Attach the part H tabletop with four part 7 cam bolts, four part 10 dowels, and four part 8 cam locks. Turn the cam locks to secure the tabletop.
- Page 7 PRODUCT ASSEMBLY Attach the part I left panel and part J right panel to the part K back panel with four part 1 screws, two screws per panel. Slide in part L drawer bottom. Attach a part 6 handle to the part M front panel with two part 4 screws.
- Page 8 ENJOY YOUR PRODUCT! PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included. All returned items will receive a full refund back to the original payment method.
