This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians.Any attempt to service
or repair the product or products dealt with in this service information by anyone else could result in serious injury or death`
2010 Haier washing Machine
C
All rights reserved. Unauthorized copying and distribution is a violation of law.
SERVICE MANUAL
Twin-tub washing machine
WARNING
Order No.TL1801S004V1.1
Model:
LMDR8124PBAB0
LMDR0224PBAB0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Haier LMDR8124PBAB0
Summary of Contents for Haier LMDR8124PBAB0
- Page 1 Products powered by electricity should be serviced or repaired only by experienced professional technicians.Any attempt to service or repair the product or products dealt with in this service information by anyone else could result in serious injury or death` 2010 Haier washing Machine All rights reserved. Unauthorized copying and distribution is a violation of law.
-
Page 2: Table Of Contents
Issue Service Manual Rev. Model NO:LMDR8124/0224PBAB0 Chapter 1: CONTENTS 1.Contents Features 3. Specifications 4. Safety precondition Warning and cautions Installation and accessory parts 6-1.Dismantle and installation 6-2 .Points of Attention in After-sales Service Appearance brief introduction 7-1.Net dimension 7-2.Name parts 8. -
Page 3: Features
Issue Service Manual Rev. Model NO:LMDR8124/0224PBAB0 Chapter 2: FEATURES Features Full plastic cabinet Full plastic twin-tub integrated with cabinet no rustiness for be affected with damp Choose water current and washing time Choose spinning time Separate washing and spinning Full plastic washing tub and spinning tub Concavo-convex on veins in Tub side Special drain lid Wide range voltage design,not be afraid of fluctuating... -
Page 4: Specifications
Service Manual Issue Rev. Model NO:LMDR8124/0224PBAB0 Chapter 3: SPECIFICATIONS Model LMDR8124PBAB0 / LMDR0224PBAB0 Free standing √ Features for use 14.0/20.0 Wash capacity 10.0/14.0 Spin capacity Level/Volume 1/41L 2/62L 3/85L 4/102L / 1/67L 2/92L 3/118L 4/140L Preset × Residual dampness <115... -
Page 5: Safety Precondition
Issue Service Manual Rev. Model NO:LMDR8124/0224PBAB0 Chapter 4: safety precondition Contents marked with that symbol are related to the safety of the Warning sign product and the users.Please operate in strict conformity to the contents. Contents marked with that symbol are actions forbidden to perform. Forbidding sign Performing of those actions may result in damage of the machine or injure the personal safety of the user. -
Page 6: Warning And Cautions
Issue Service Manual Rev. Model NO:LMDR8124/0224PBAB0 Chapter 5: WARNING AND CAUTIONS Do not decompose, repair or alter the machine by yourself. Do not put any hot or heavy items Do not wash laundries with volatile ( such as the kettle with hot water ) materials (such as thinner, petrol etc.). -
Page 7: Installation And Accessory Parts
Issue Service Manual Rev. Model NO:LMDR8124/0224PBAB0 Chapter 6: INSTALLATION AND ACCESSORY PARTS 6.1 Dismantle and installation Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Usage of the drain hose 0.8m≤h≤1.2m... - Page 8 Issue Service Manual Rev. Model NO:LMDR8124/0224PBAB0 Figure 1 indicates the ex factory installation position of the drain hose(In wash tub). Extend the drain hose Take out the drain hose from the wash tub,fix the drain hose in drain valve parts , make the drain hose extend towards back side.
- Page 9 Issue Service Manual Rev. Model NO:LMDR8124/0224PBAB0 Dismantling and installation of the base frame Dismantle the back cover. Loosen the wires. Loosen the fastening screw of the spin tub shaft. Separate the shaft from the brake wheel. Loosen the brake hook. Take off the brake cable frame from the installation groove of the twin-tub.
-
Page 10: Points Of Attention In After-Sales Service
Issue Service Manual Rev. Model NO:LMDR8124/0224PBAB0 Dismantling and installation of the bearing seat Once the bearing seat is taken off, it can not be utilized again. Therefore do not dismantle it as far as possible. In case that it has to be replaced, please dismantle it as per following sequence, then install a new bearing seat. -
Page 11: Appearance Brief Introduction
Service Manual Issue Rev. Model NO:LMDR8124/0224PBAB0 Chapter 7: APPEARANCE BRIEF INTRODUCTION 7.1 Net dimension Unit (mm) Figura 6 LMDR8124PBAB0: height:1020mm width:960mm depth:552mm LMDR0224PBAB0: height:1050mm width:915mm depth:550mm... -
Page 12: 7-2.Name Parts
Service Manual Issue Model NO:LMDR8124/0224PBAB0 Rev. 7.2 Name of parts Drain selector Wash selector Wash timer Wash tub cover Water-filling entrance Water-filling transfer Control panel Major frame Draining hose Figure 7 Spin tub outer cover Spin tub inner cover Spin timer Spin tub frame Spin tub Wash tub... -
Page 13: Maintenance Service And Check Method
Service Manual Issue Rev. Model NO:LMDR8124/0224PBAB0 Chapter 8: MAINTENANCE SERVICE AND CHECK METHOD 8.1 Wash part Insert the power plug , but the machine does not work Check if the wash timer is opened ? Open the wash timer. Switch on the power. Check if the power source is available? Check if the contact between Replace the plug... -
Page 14: Spin Parts
Issue Service Manual Rev. Model NO:LMDR8124/0224PBAB0 8.2 Spin part Check if the spin timer Open the spin timer. is opened ? Check if the power source Switch on the power. is available? Check if the contact between Replace the plug the plug and receptacle is good? or receptacle. -
Page 15: Spin Parts
Issue Service Manual Rev. Model NO:LMDR8124/0224PBAB0 8.3 check noise and others There is metal rubbing noise in braking Add the brake or replace If the brake arm the brake arm. has brake block ? The washing noise is too large Is the motor noise large? Replace the motor. - Page 16 Issue Service Manual Rev. Model NO:LMDR8124/0224PBAB0 The spinning noise is too large If the washing machine Set the machine horizontally. is set horizontally? If the sundries fall off between the Clean the sundries spin tub and twin-tub Add the oil between the bearing and the If there is different noise spin-tub.
- Page 17 Service Manual Issue Rev. Model NO:LMDR8124/0224PBAB0 Not draining Set the switch to drain, the machine does not work. Install the knob again. Check if the select knob install? Replace the knob . Check if the select knob shatter? Check if the Drain pullback Replace or adjust the drain band loosened or snapped? pullback band .
-
Page 18: Trouble-Shooting Answer To Question
Service Manual Issue Rev. Model NO:LMDR8124/0224PBAB0 Chapter 9: Trouble-shooting answer to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company. -
Page 19: Wiring Diagram
Issue Service Manual Rev. Model NO:LMDR8124/0224PBAB0 Chapter 10: WIRING DIAGRAM Spin Timer Purple Blue Orange Purple Safety switch Spin Brown Grey Motor Red/White Drain Pump Drain Switch Brown Blue Fuse Brown Wash Motor Yellow Black Wash Timer White Blue Green Figure 9 There is overload protector installed in the motor. - Page 20 Sincere Forever Group Haier Industrial Park, No.1, Haier Road 266101, Qingdao, China http://www.haier.com...
