- Page 1 Instruction Manual MOBILEMULE™ 4 CHANNEL MOBILE DVR WITH GPS TRACKING AND LIVE VIDEO OPTIONS RVS-6200 VEHICLE SAFETY - IT'S ALL WE DO.
-
Page 2: Table Of Contents
Table of Contents 1 Before You Start ..........................3 2 Product specication ........................4 3 Front /back panel and DVR installat ion instruction.................6 Front panel interface......................6 Back panel interface......................7 Wiring instruction .........................9 3.3.1 AV input cable......................9 3.3.2 Power cable......................9 3.3.3 Alarm I/O ......................11 Device Installation Guide ....................13 3.4.1 Unpack and check accessaries................13 3.4.2 Installation instructions of SD card, HDD enclosure, shell and stand... -
Page 3: Before You Start
Before You Start • Read this manual carefully before installation. • Do not use this system in a rainy or humid environment. • If any solid/liquid goes inside the system, cut of f the power immediately. • Do not attempt to repair/disassemble DVR. Please contact our tech team with any problems. •... -
Page 4: Product SpeciCation
2 Product Specification... - Page 5 Upgrading mode Manual/Automatical/Remote Firmware upgrading Upgrading method USB disk/Wireless network/SD card AV input 4ch interface SDXC High speed card - up to 512GB (Format 512 Card To FAT32 On Computer) SD card USB interface 1 USB 2.0 (support U disk/mouse/upgrade) Ignition input 1 ACC signal Interface...
-
Page 6: Front /Back Panel And Dvr Installat Ion Instruction
Front/Back Panel and Installation Instruction Front Panel Interface Serial Interface Parameter Descripon number Power LED, light on when power works normally Alarm LED, light on when device works abnormally Light on when system normal Light on when SD card in properly Indicator Infrared receiver module used to receive remote control signals... -
Page 7: Back Panel Interface
Serial Parameter Interface Descripon number The first SD card, commonly used Indicator USB port to plug in Mouse (LED) Debug window DEBUG 3.2 Back Panel Interface... - Page 8 Parameter Name Descripon Number Power interface PWR_IN Power input interface, DC6V～DC36V Network VGA connection Video and Pin 1 is VDD(+12V), pin 2 is GND,pin 3 is audio input audio input, pin 4 is video input. interface Input vehicle speed pulse signal, differential input;...
-
Page 9: Wiring Instruction
3.3 Wiring instruction 3.3.1 AV input cable Picture 3: Diagram of AV input cable Wire Serial number Mark on the cable end 12V power supply for video camera Ground wire Audio pickup input A-IN wire Video input wire V-IN Table 5 3.3.2 Power Cable Picture 4: Power input cable picture... - Page 10 The power cable shown in picture four ends in a 6 pin white plug. This connects to the 6 pin white socket on the back of the DVR. The red (+) and black (ground) connect to the vehicle directly. The yellow cable is connected to ignition.
-
Page 11: Alarm I/O
3.3.3 Alarm I/O Picture 6: Definion of alarm connector The device has an interface with 4 alarm inputs and 2 alarm outputs. These alarms can be connects to a variety of triggers. The principle diagram of brake detection is as shown below. When the brake pedal is pressed, the DVR is able to detect the high level or the low level. - Page 12 Picture 7: The principle diagram of the brake detecon The alarm outputs have a maximum current capability of 200MA. If you want to drive a device with higher current requirement, you must connect external relay. Shown below is the alarm output wiring diagram. Picture 8: Alarm principle diagram...
-
Page 13: Device Installation Guide
3.4 Device Installation Guide 3.4.1 Unpack and check accessories While unpacking, please check device for damage. If device is damaged, do not install and get in touch with the supplier. In the product box there is a packing list. Please cross check the list below with the device and accompanying accessories. - Page 14 Picture 9 SIM Card / SD card installaon diagram Open the DVR to see both the SIM and SD card slots: Picture 10 SIM Card / SD card installaon diagram 2...
-
Page 15: Soft Are Keyboard Input
Keyboard Input System can use numbers, lower/uppercase English letters and Chinese Characters. DVR Operation Guide Right click to open login interface: Input Username/password, click OK to login to the menu. -
Page 16: Users' Login
5.1 User login Default Username is admin, with no password. -
Page 17: Directly Preview Interface
5.2 Video Preview 5.3 System Setting... -
Page 18: General Setting
5.3.1 General Setting 5.3.2 Video Setting 10 18... -
Page 19: Record Setting
5.3.3 Record Setting 5.3.4 Alarm Control... -
Page 20: Record Setting
Camera Settings Set CH Trigger/Delay Time/Distance Grid Line 5.3.5 Motion Detection... -
Page 21: Monitor Display
5.3.6 Monitor display The grid lines are adjustable (move the purple points) After adjustment, right click the mouse to save settings. -
Page 22: Advanced Options
5.4 Advanced Options 5.4.1 System Upgrade Copy the upgrading file to the root directory of the USB disk. Then re-power on the device, it will upgrade automatically. -
Page 23: Restore Default
5.4.2 Restore Default Copy Configuration File 1) Click Backup 2) Disconnect Mouse 3) Connect USB Device 4) Will Display "Congratulations, Action Succedded!" Copy Configuration File 1) Click Resume 2) Disconnect Mouse 3) Connect USB Device 4) Will Display "Congratulations, Action Succedded!" 5.4.3 Display settings Margin Settings: can adapt to different monitor. -
Page 24: Username
5.4.4 Username 5.4.5 Encode Overview... -
Page 25: System Info
5.5 System Info... -
Page 26: File Backup
5.6 File Backup 5.7 Disk Management Disk need to be formated in the device when using it for the first time. If the disk was not detected by the device, confirm the device is locked. -
Page 27: Vehicle Settings
5.8 Vehicle Settings 5.8.1 Basic Info If you want to change the vehicle ID number, please login with super password"szmzkj"... -
Page 28: G-Sensor
5.8.2 G-Sensor 5.8.3 Power Management... -
Page 29: Wi-Fi Setting
5.8.4 Wi-Fi Setting The device can save 6 WiFi ESSID (Access Points). Turn on "WiFi" and save as show below. 5.8.4.1 Network Status... -
Page 30: 4G Setup
The device will detect the 3G/4G Module Type automatically. Insert the right SIM card which corresponding with the Module Type detected. Putting in the wireless account will automatically connect it. If it does not connect, consult your SIM card carrier or search on Internet to make sure you put the correct parameters (Dial Number, login Name, Password). -
Page 31: Network Settings
5.8.6 Network Settings We have set it with our server in factory, if use different server please set your server’s IP (or Domain), the Port should be same with your server setup. 5.9 Playback... -
Page 32: A.q
6 FAQ 1) The monitor shows the time but no video, and the picture is black. A) Check whether the video signal cable and power cable of camera are properly connected, and camera is working normally. B) Check whether the preview switch of display setting is off or not. 2) When the DVR starts up with an SD card, it can’t record. - Page 33 D) Check whether video source and display device connection E) Check whether the format selection between PAL and NTSC is wrong. 13)Alarm I/O does not work A) Alarm is set wrong. B) The connection of alarm is wrong. C) The input signal of alarm is wrong. 14) DVR does not delay shutting down under the ignition mode A) Delay time is not set.
- Page 34 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 VEHICLE SAFETY - IT'S ALL WE DO.
