K&K Sound Dual Channel Pro Product Manual

D U A L -C H A N N E L PRO PRE A M P
The Dual Channel Pro Preamp is an extremely
powerful yet small dual-channel mixer in a belt clip
box. It is designed for mixing a combination of
transducers, pickups, or dynamic microphones
(microphones that do not need power) on one
instrument to achieve the best possible sound. It
offers volume, gain, 3-band EQ for each channel.
The tone controls feature an extended range of +/-
20 dB, which exceeds many mixers on the market
today. To keep the box as small as possible, the
gain and tone controls are trim pots inside the unit
(small potentiometers for adjustment with a supplied
screwdriver). During a performance, you can
conveniently balance the two channels on the
volume control knobs.
Before first use, please insert a 9-volt battery. To
switch the battery off, always unplug the
MAIN/MIX OUT jack.
This manual covers both the Dual Channel Pro and
Dual Channel Pro ST Preamps.
Please see the next page for setting up the Dual
Channel Pro ST Preamp.
92798 Cape Arago Hwy, Coos Bay, OR 97420 | 541-888-3517 | Toll Free 1-800-867-6863 | kksound.com
SETTING UP THE DUAL CHANNEL PRO
PREAMP (MONO)
1. Remove the snap-off lid. There is no need to
undo any screws to remove the lid.
Important: Please do not tamper with the
screw on the bottom of the preamp!
2. Insert a 9-volt battery into the designated
compartment.
3. On the inside of the lid is a diagram for the
internal trim pot controls. In the box you will
find a small screwdriver for the adjustment
of the trim pots. It is attached with a Velcro
fastener.
4. Connect your pickups to the two inputs and
connect the output via a mono ¼" guitar
cable to an amplifier or mixing board.
5. Set your amp to a flat setting first. Adjust the
gain trim pots of each individual channel
until both channels are at about the same
volume. Adjust EQ trim pots to your
preference. Close the lid and you are ready
to go.
