  • Page 1 Advanced Electrical Materials...
  • Page 2 Please note that all product, product specifications and data detailed in this brochure are subject to change without notice to improve reliability, function, design or otherwise. Morgan AM&T B.V. and its affiliates does not assume any responsibility for the correctness of this information nor for damages consequent to its use.
  • Page 3 www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...

  • Page 4: Table Of Contents

    CONTENTS PAGE Introduction ........................1 Recommendations ......................4 First time Use ........................5 Minimum PC requirements: ........................5 Registration of software on 1 use ......................6 Software update procedure ........................11 Using the MSPro14 Measuring Box................12 Welcome Screen ............................13 Home Screen ..............................
  • Page 5 Adding Datasets............................ 46 Printing ..............................48 Reading and Comparing Values ......................49 Adjusting Profiles ..........................49 Zooming behaviour ..........................50 Alarms ..............................50 Downloading .Mas files ......................... 50 Appendix A: Specifications ..................51 Appendix B: Warranty & Repairs ................52 Warranty ..............................

  • Page 6: Introduction

    INTRODUCTION The primary object of maintaining or reconditioning a commutator or slip ring (Collector) is to remove those irregularities which lead to impaired brush efficiency and reduced brush and collector life. Collectors should, in an ideal world, be smooth and true. A collector that is in bad condition should be either re-ground or turned.
  • Page 7 An unacceptable commutator profile An acceptable slip ring profile An unacceptable slip ring profile Therefore congratulations on purchasing the MSPro14 – the new and improved Surface Profiler from Morgan Advanced Materials. The MSPro14 is used for: • Collector surface profiling and measures TIR, MBTB as well as collector diameter •...
  • Page 8 Optimised sensor head that is not negatively affected by Helically Grooved Slip Rings • Zero setting light indicators for easy set up • Previous Morgan supplied profiler measurements (.mas files) can be stored and combined • Extra extensive memory for storing information and editable on the data acquisition box •...

  • Page 9: Recommendations

    It is recommended that the sensor is calibrated every 12 months – this can either be done by sending your MSPro14 to your local Morgan Sales office or directly to Morgan Advanced Materials Netherlands. www.morganadvancedmaterials.com...

  • Page 10: First Time Use

    FIRST TIME USE Minimum PC requirements: • Operating system: Windows XP or higher • Minimal 100MB of free disk space • Minimum of 1GB RAM memory • One free USB 2.0 port Once connected to a PC using the USB-cable, the Measuring Box reports itself as new USB-device. The Measuring Box may be accessed using a Windows File Explorer standard program.

  • Page 11: Registration Of Software On 1 St Use

    Registration of software on 1 Insert the supplied USB Memory stick into the PC and open the file; double-click on the software link which looks like: Follow the on-screen instructions; if there are any warnings displayed regarding the software installation which could depend on your PC configuration, then press “Yes”, however, if in doubt always contact your IT administrator.
  • Page 12 Click Next The default file location is selected; however, change if you require and click “Next” to continue www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...
  • Page 13 Once details are correct, press “Install” Once installation is complete, press “Next” www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...
  • Page 14 The DASPro14 software is now ready to be registered prior to first use and can be done as follows: Double-click the link shown below which should be on your PC desktop: This will then open the following screen: If a registration key is already known, enter it in the appropriate field, else click the link which opens a webpage: www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...
  • Page 15 http://www.morganelectricalmaterials.com/mspro14-registration-form Once the necessary fields have been completed the submit button should be pressed and this will automatically send an email to: MSPro14.register@morganplc.com so that a registration key can be sent back to the user. Once the registration key is received enter it in the appropriate field and press “OK” and the software will open accordingly.

  • Page 16: Software Update Procedure

    Software update procedure Software updating will not be done automatically. The procedure for doing this on both PC-software and MSPro14 Box is as follows: • The user will receive an attachment in an email sent to the address used for registering the PC software or is instructed to download it from a specific server.

  • Page 17: Using The Mspro14 Measuring Box

    USING THE MSPRO14 MEASURING BOX First, connect the sensor to the MSPro14 measuring box then turn the unit on; wait for it to start-up at which point you will see the following screen: The status bar will show how the loading is progressing and once loaded the Welcome Screen will be displayed.

  • Page 18: Welcome Screen

    Welcome Screen This screen shows both the MSPro14 product ID and box software version. The symbols on the top of the screen mean the following: The size of the memory will be at least 30 Mbyte. This should be enough to store at least 250 datasets.

  • Page 19: Home Screen

    Home Screen There are 4 options to use: Start Measurement View Data Settings Help www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...

  • Page 20: Settings

    SETTINGS From this screen you can alter 6-off different settings: Date & Time www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...

  • Page 21: Units & Language

    Units & Language There are 5 different languages to choose from: English, Dutch, French, German and Spanish Alarms Alarms can be set depending on the tolerances you require www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...

  • Page 22: Display

    Display Brightness can be automatic or user defined Power Management www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...

  • Page 23: Sensor Settings

    Sensor Settings This will display when the sensor number is correct If the sensor number is not valid or entered then this is shown www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...

  • Page 24: Start Measurement

    START MEASUREMENT Once you decide to take a measurement you must determine the type of collector on which the profile is being taken, i.e. Commutator or Slip-ring Commutator www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...
  • Page 25 On this screen as much information as possible is to be filled in as it can be used to generate your own company specific machine database, and in order for a machine to be saved in the database the top 3 fields are to be completed: •...

  • Page 26: Setting The Sensor

    Setting the Sensor The sensor has been designed so that for the greatest measurement range the sensor head should be positioned mid-way through its travel, i.e. 3mm (118mil) in real terms, out of a possible 6mm (236mil). The ideal displacement is 0.00mm (0mil) however anywhere between ±0.2mm (±8mil) can be used as a start point.
  • Page 27 www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...
  • Page 28 • When the sensor head is in position (ideally the display will be green), tighten the clamp in the holder or sleeve fully so that there is no movement from the sensor. Only hand tighten the sensor and do not use any tools or other equipment (as over tightening may damage the clamp).

  • Page 29: Completing One Recording

    Completing one Recording The collector should be rotated and the unit will start taking recordings www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...
  • Page 30 When rotation is detected the will change to ; the recording will stop automatically if the number of bars (or diameter) was entered, else will have to be pressed. It is possible to alter the way the readings are displayed by pressing the button;...
  • Page 31 On completion of the recording, the following summary page is displayed: The symbols on the bottom of the screen mean the following: Return to home screen without saving Re-take recording, therefore deleting existing one www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...
  • Page 32 View alarms/errors – if this symbol is highlighted in red View radial plot Save recording If there are any alarms triggered/errors they will be displayed as follows: The radial plot button allows the user to have an overview of the general shape – and zoom in and out. www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...
  • Page 33 If the user wants to save the recording, the following screen is displayed: The default filename is in the format: year/month/day-hour/minute/second – hence it will be totally unique; this filename can be over-written and/or modified if desired. button must be pressed – provided In order to add the machine details into the database, the the machine information is not already in the database, unless the user wants to update the existing data with the latest reading(s).
  • Page 34 The information can be transferred into the database by pressing the button. Once the user wants to save the recording, the button must be pressed. This will then lead to the following options: www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...
  • Page 35 Same Machine returns the user to the sensor setup Different Machine returns the user to the Start Measurement screen Return to home screen www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...

  • Page 36: Slip-Ring

    Slip-ring On this screen as much information as possible is to be filled in as it can be used to generate your own company specific machine database, and in order for a machine to be saved in the database the top 3 fields are to be completed: •...

  • Page 37: Setting The Sensor

    The next screen is used to determine whether you require TIR and Low Point alarms, and if so, the value at which it is triggered; note that the default is that which is set in the Alarms page. Setting the Sensor Set the Sensor in the same way as that described for a Commutator.

  • Page 38: Completing One Recording

    Completing one Recording The collector should be rotated and the unit will start taking recordings When rotation is detected the will change to ; the recording will stop automatically if the diameter was entered, else will have to be pressed. www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...
  • Page 39 It is possible to alter the way the readings are displayed by pressing the button; this will alternate between either text or a real-time graph. On completion of the recording, the following summary page is displayed: The symbols on the bottom of the screen mean the following: www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...
  • Page 40 Return to home screen without saving Re-take recording View alarms/errors – if this symbol is highlighted in red View radial plot Save recording If there are any alarms triggered/errors they will be displayed as follows: The radial plot button allows the user to have an overview of the general shape – and zoom in and out. www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...
  • Page 41 The results can be saved in exactly the same way as that described in the Commutator section. button must be pressed – provided In order to add the machine details into the database, the the machine information is not already in the database, unless the user wants to update the existing data with the latest reading(s).
  • Page 42 The information can be transferred into the database by pressing the button and saved as previously described. www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...

  • Page 43: View Data

    VIEW DATA When the user wants to view previously taken collector readings, the following screen will be displayed: Scrolling through the data sets can be achieved by using the arrows on the side of the screen. When the required data set is located, the button should be pressed.
  • Page 44 Once the required recording is located the button is again pressed to continue; this will then display the same screen as that displayed following the completion of the recording, i.e.: The different icons can be selected as previously described. www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...

  • Page 45: Standby Screen

    Standby Screen On the main menu, the button gives the user the following options: Turns the screen off Turns the unit off Returns to home screen After pressing the “Display Off” button the screen will go blank/turn off; when the screen is then pressed again the following is shown: www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...
  • Page 46 Pressing the screen again takes you back to the Home screen The Power Off button shows the following screen: Return to home screen without turning off Turns unit off www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...
  • Page 47 www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...

  • Page 48: Pc Analysis Software

    PC ANALYSIS SOFTWARE DASPro14 To open the DASPro14 software double-click the link as shown below: GENERAL • The DASPro14 can be run on a PC or Laptop running Windows ® XP or higher. • Multiple Measuring Boxes can be managed by a single PC or Laptop. •...
  • Page 49 • Tab bar: 1. Info: The info tab shows information about the loaded measurement and allows the user to make changes: a) User details (eg. Company, Operator, etc) b) Alarm Settings: BTB, TIR, etc. c) Recording details (eg. Name, type, size, etc.) 2.
  • Page 50 3. Chart: The chart tab will show a linear plot of the selected recording(s). Available functions are: a) Pan & zoom b) Rotate, flip & align plot c) Adjust axis scale & colours d) Show/hide horizontal and/or vertical gridlines e) Copy (copy chart plot + legend as a picture on the clipboard) Print (chart plot + headers) 4.

  • Page 51: Using Daspro14 For The First Time

    b) Rotate, flip & align plot c) Adjust axes scale & colours d) Show/hide middle circle, limit circles and/or central gridlines e) Copy radial plot + legend as a picture on the clipboard Print (radial plot + headers) • Menu bar 1.
  • Page 52 • By selecting “Download from Measurement Box” and following the on-screen instructions Once there are datasets on the PC, they can be added by pressing the button; the dataset will then be displayed in the dedicated area. Clicking on the dataset displays the individual recordings: Double-clicking on the individual recording will add it to the recordings list where it can be viewed in detail by selecting one of the 4 different tabs www.morganadvancedmaterials.com...

  • Page 53: Printing

    Printing To print a report on the data, click File>Print Report and select what needs to be printed from the available options and follow on-screen instructions www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...

  • Page 54: Reading And Comparing Values

    Reading and Comparing Values • When a chart is displayed it is possible to follow the profile and obtain specific information along the length of the profile; this can be done by placing the cross-hair at the required point and clicking the left mouse button.

  • Page 55: Zooming Behaviour

    – Lists any Mica insulation (between commutator bars) which are not recessed below the bar surface. Downloading .Mas files It is possible to download profiles taken on the previous version of the profiler that Morgan used to offer; this can be done by selecting “File>Importing MAS File…” and following the on-screen instructions. www.morganadvancedmaterials.com...

  • Page 56: Appendix A: Specifications

    APPENDIX A: SPECIFICATIONS These specifications may be changed in future versions: www.morganadvancedmaterials.com Insert Registered Legal Entity name, address and number, or all other details as required to comply with regional regulations...

  • Page 57: Appendix B: Warranty & Repairs

    Users own risk. In the unlikely event that repairs are necessary please contact your local Morgan sales office. They can inform you on how to proceed. You can contact them as well if you want to have your MSPro14 calibrated.
  • Page 58 Follow us on Follow us on Follow us on http://www.youtube.com/morganadvanced https://twitter.com/morganadvanced http://www.linkedin.com/company/morgan-advanced-materials https://www.facebook.com/MorganAdvancedMaterials www.morganadvancedmaterials.com Morgan Advanced Materials plc Quadrant, 55-57 High Street, www.morganadvancedmaterials.com Windsor, Berkshire, SL4 1LP United Kingdom www.morganelectricalmaterials.com Copyright 10.2014 Copyright applied 05/13 - Designed and Produced by Inspiration Ltd...
