• Wireless Repeater Unit in a Rugged, Industrial Housing
• Simple to Order, Configure, & Install
• Increase Range an Additional 1 Mile Line-of-Sight, 500 Ft Indoor
• Remote or Attached Antenna
• Flanges for Wall or Pipe Mounting
• Software Available for Even Easier Setup
• Rugged, IP68, NEMA 4X Enclosure
PRECISION DIGITAL CORPORATION
1.800.561.8187
PDW30 & PDW90 Repeater Field Unit
Instruction Manual
www.
Wireless System
information@itm.com
.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PDW30 and is the answer not in the manual?

Questions and answers

Related Manuals for PRECISION DIGITAL PDW30

Summary of Contents for PRECISION DIGITAL PDW30

  • Page 1 PDW30 & PDW90 Repeater Field Unit Instruction Manual Wireless System • Wireless Repeater Unit in a Rugged, Industrial Housing • Simple to Order, Configure, & Install • Increase Range an Additional 1 Mile Line-of-Sight, 500 Ft Indoor • Remote or Attached Antenna •...

  • Page 2: Limited Warranty

    Precision Digital Corporation warrants this product against defects in material or workman- ship for the specified period under “Specifications” from the date of shipment from the fac- tory. Precision Digital’s liability under this limited warranty shall not exceed the purchase value, repair, or replacement of the defective unit.

  • Page 3: Table Of Contents

    Mounting Dimensions ..........................15 PDA6963 Stainless Steel Pipe Mounting Kit ....................15 Table of Figures Figure 1. PDW30 Device Assembly, Rear View ................... 8 Figure 2. Power Connections ........................8 Figure 3. Enclosure Dimensions – Front View .................... 15 Figure 4. Enclosure Dimensions – Side Cross Section View ..............15 Figure 5.

  • Page 4: Introduction

    Precision Digital PDW30R wireless signal repeaters are used to retransmit wireless signals when connectivity between PDW30 or PDW90 wireless units is an issue. They are incredibly simple to install as they only require power and a network ID. Any units in range of the repeater with the same network ID will retransmit through it, thus increasing signal strength.

  • Page 5: Specifications

    PDW30 & PDW90 Repeater Field Unit Instruction Manual Specifications Except where noted all specifications apply to operation at +25°C. Mounting May be mounted directly to conduit. General Two mounting holes for 1.5" pipe or Display 32-character dual-line alphanumeric wall mounting. See Mounting Dimen-...

  • Page 6: Safety Information

    PDW30 & PDW90 Repeater Field Unit Instruction Manual Safety Information Caution: Read complete instructions Warning: Read all product labels prior to installation and operation of the completely and follow all instructions device. and requirements listed on the labels for installation or service.

  • Page 7: Pre-Installed Conduit Plug

    PDW30 & PDW90 Repeater Field Unit Instruction Manual Pre-Installed Conduit Plug The PDW30R is supplied with one pre-installed optional conduit plug for installations that do not require the use of both conduit entries. The conduit plug includes an internal hexagonal socket recess for re- moval.

  • Page 8: Connections

    Power Connector Power connections are made to a two-terminal connector la- beled POWER in Figure 1. The PDW30 is reverse polarity protected; it will not be damaged if wired backward. Make sure that the power supply can provide between 12 and 28 VDC to the wireless device.

  • Page 9: Setup And Programming

    PDW30 & PDW90 Repeater Field Unit Instruction Manual Setup and Programming Overview Setup and programming is done through the programming buttons located underneath the enclosure cover. After power connection has been completed and verified, apply power to the device. Programming Buttons The units can be programmed using the buttons located behind the enclosure cover.

  • Page 10: Pdw Manager Software

    Use of PDW Manager is required for programming advanced settings such as wireless encryption. Note: Units must be powered externally prior to programming via USB. Instructions on the use of PDW Manager to program the PDW30 wireless units can be found under Pro- gramming with PDW Manager on page 13.

  • Page 11: Setup Menu

    PDW30 & PDW90 Repeater Field Unit Instruction Manual Setup Menu The setup menu consists of network ID, password, and factory defaults restoration. Run Mode RSSI 10 increments selected digit. <------> selects next digit to the right. NETWORK ID NETWORK ID...

  • Page 12: Password Setup

    PDW30 & PDW90 Repeater Field Unit Instruction Manual Password Setup Both the primary and secondary wireless units may be protected with a four-digit numeric password in or- der to prevent unauthorized tampering. When a password has been set, you will be prompted to enter that password in order to access the device menu.

  • Page 13: Programming With Pdw Manager

    PDW30 & PDW90 Repeater Field Unit Instruction Manual Programming with PDW Manager PDW Manager allows you to program the PDW30R wireless repeater unit from a PC with a USB connec- tion. The unit connects to a PC via the micro USB connection on its face, underneath the enclosure cover.
  • Page 14 PDW30 & PDW90 Repeater Field Unit Instruction Manual Device communication can be secured by enabling 128-bit AES encryption. A channel mask may also be set for interference immunity. The encryption key and channel mask may be entered on the Advanced tab.

  • Page 15: Mounting Dimensions

    PDW30 & PDW90 Repeater Field Unit Instruction Manual Mounting Dimensions 2.31 (58.6) 4.00 (101.6) Ø 0.35 (Ø 9.0) 2.17 (55.0) 4.27 (108.4) 2.74 (69.7) 3.62 (92.0) 2.44 (61.9) 4.30 (109.2) ½ " NP T Figure 3. Enclosure Dimensions – Front Figure 4.
