Connects2 CAM-UNI-SW1 User Manual

U s e r M a n u a l
CAM-UNI-SW1
Rear/Front Camera Control Box

PRODUCT FEATURES:

Camera switching unit which has the ability to control both a front and
rear view camera.
The switching unit outputs the image from the rear view camera when
reverse gear is engaged and automatically switches to the front view
camera image which stays on for 10 seconds when reverse gear is dis-
engaged. The switching unit has a front view camera trigger input which
enables the user to activate just the front camera image. The unit also
provides a switched +12V output when either the front or rear camera is
active which provides an ideal power source for the display monitor.
Operating Voltage: 12V DC (Negative Ground)
Current consumption: 235mA @ 13.8V
Stand-by current: 45mA @ 13.8V
DISCLAIMER:
Prior to Installation
Read the manual prior to installation. Technical knowledge is necessary for installation.
Please ensure you use the correct tools to avoid damage to the vehicle or product.
Connects2 can not be held responsible for the installation of this product.

Technical Support

Connects2 want to provide a fast and suitable resolution should you encounter any tech-
nical issues. With this in mind, when contacting Connects2, try to provide as much Infor-
mation as possible. This will speed up the process and help us to help you.
Please use our dedicated online technical support centre: support.connects2.com
