- Page 1 I I nstallation and user manual Wi-Fi Box / Puck Serial number: Production date:...
-
Page 2: Table Of Contents
Mobile device (for Wi-Fi Box only)....................8 Installation of the Wi-Fi Box..............9 Connecting the Puck................10 Setup of the Bellfires Gas app............... 11 Registration..........................11 Connecting to the home network with KWIK connect..............13 Connecting to the home network with standard setup............... 14 Appliance settings........................15... - Page 3 Contents Operating the appliance with the Bellfires Gas app....... 17 Start screen..........................17 Description of the symbols......................18 8.2.1 Menu symbols......................... 18 8.2.2 Other symbols......................... 19 Main menu..........................19 8.3.1 Profiles..........................19 8.3.2 Manual operation......................20 8.3.3 Thermostatic operation....................21 8.3.4 Timer..........................22 8.3.5 Program mode........................
-
Page 4: About This Document
The illustrations are for instructional use only. Screenshots of the Bellfires Gas app are from an Apple IPad. The screenshots of the Bellfires Gas app on other mobile devices can be different. -
Page 5: How To Work With This Document
A note shows more information. Symbol Description Visual sign that there is a hazard Visual sign that there is a notice Related documentation All documents that belongs to the Bellfires gas appliance. • Preparation manual • Installation and maintenance manual •... -
Page 6: Description
3.1.1 Wi-Fi Box The Wi-Fi Box is intended for indoor use in combination with a Bellfires gas appliance and with the Bellfires Gas app in combination with a hand set or Puck. Do not use it for other purposes. 3.1.2 Puck The Puck is intended for indoor use in combination with a Bellfires gas appliance. -
Page 7: Overview Of The Puck
Description I I tem Description LED 2 Green Connected to the home network (router) Blue blinking A Wi-Fi network has been detected Not connected to the home network (router) Standby mode is active. No power supply 3.2.3 Overview of the Puck Item Description ON/OFF button... -
Page 8: Requirements
Requirements Requirements Wi-Fi router (for Wi-Fi Box only) Minimum requirements Wi-Fi router: • Compatible with IEEE 802.11n/g/b • WPA2 encryption • Radio frequency: 2.4 GHz • Wireless auto channel: Automated search for Wi-Fi radio channel free of interference • Support of the User Datagram Protocol (UDP) •... -
Page 9: Installation Of The Wi-Fi Box
Installation of the Wi-Fi Box Installation of the Wi-Fi Box Make sure you have a Symax-2 receiver and a Symax-2 handset (8 or 10 buttons). Both can be recognized by the blue sticker. If not, contact your dealer. Connect the 4-wire cable on the connector marked ' ' SI ' on the receiver. Connect the other side of the 4-wire cable on the connector marked ' ' receiver' on the Wi-Fi Box Make sure LED 1 is green. -
Page 10: Connecting The Puck
Connecting the Puck Connecting the Puck Remove the lid of the battery compartment at the back of the Puck. Put 2 batteries (type AAA, 1.5 Volt) in the battery compartment. Make sure the batteries are put correctly as indicated in the battery holder. Put the lid on the battery compartment. -
Page 11: Setup Of The Bellfires Gas App
Wi-Fi router supports the Use Datagram Protocol (UDP). Do all procedures in this chapter. Download the ' ' Bellfires Gas app' from Google Play or Apple App Store and install on your mobile device. Make sure you have the SSID name and password of your Wi-Fi router. They are usually shown on a sticker on the router. - Page 12 Select R R egister Confirm your registration by clicking on the link in the e-mail that has been sent to you. Upon successful verification of your account, you can login on the Bellfires Gas app. • Return to the Bellfires Gas app.
-
Page 13: Connecting To The Home Network With Kwik Connect
Setup of the Bellfires Gas app 7 7 .2 Connecting to the home network with KWIK connect Note: • Make sure the router obeys the requirements. Refer to chapter details. • Before you continue with the connection procedure, make sure that your mobile device is connected to the correct network. -
Page 14: Connecting To The Home Network With Standard Setup
Setup of the Bellfires Gas app If connection is unsuccessful se- lect S S tandard Setup. Continue the instructions in chapter Press the reset button on the Wi-Fi Box for 7 seconds and select R R e- try. Connecting to the home network with standard setup Note: •... -
Page 15: Appliance Settings
The message 'No internet connection' is to be ig- nored • Go back to the Bellfires Gas app The Bellfires Gas app starts to con- nect the Wi-Fi Box to the selected home network. After successful connection the screen shows the appliance settings page. - Page 16 Setup of the Bellfires Gas app Scroll down and select F F inish to complete the appliance settings. • Select S S tart APP to operate the appliance. • Select the ' ' +' sign to connect another Wi-Fi-box. Repeat the...
-
Page 17: Operating The Appliance With The Bellfires Gas App
Operating the appliance with the Bellfires Gas Operating the appliance with the Bellfires Gas Start screen All functions of the Bellfires Gas app are accessible from the menu or the icons on the start screen. Number Option Description ON/OFF button To start or stop the appliance. -
Page 18: Description Of The Symbols
Operating the appliance with the Bellfires Gas 8 8 .2 Description of the symbols 8.2.1 Menu symbols Symbol Function Description Profiles Define or choose your personal operating profile. Maximum 4 user profiles can be set, Manual mode Manual adjustment of the flame height. -
Page 19: Other Symbols
Operating the appliance with the Bellfires Gas S S ymbol Function Description Help Help pages with information about the menu func- tions 8.2.2 Other symbols Symbol Function Description Home Go to the start screen ON / OFF Start or stop the appliance... -
Page 20: Manual Operation
Operating the appliance with the Bellfires Gas S S et a user profile Select one of the four user profiles. The selected user profile shows in the left hand corner of the screen. Select a function that must be included in the selected profile and set this function to the correct value or correct position. -
Page 21: Thermostatic Operation
Operating the appliance with the Bellfires Gas • Set the flame height by selecting one of the segments in the circle. • Select one of the three pre-defined settings with the three buttons on the bottom of the screen. Options are L L ow flame, S S tandby (pilot flame is ON) and H H igh flame. -
Page 22: Timer
Operating the appliance with the Bellfires Gas • Set the required room temperature by selecting a segment of the circle. During this selection the set temperature shows in the center of the circle. • After selection of the required temperature, the room temperature is shown in the center of the circle. - Page 23 N N ote: Before use of the Program mode make sure the time in the Wi-Fi Box is synchronized with the time of the mobile device. Open the settings page in the Bellfires Gas app. Press under 'Fireplace settings' on the name of the appliance.
-
Page 24: Eco Mode
Operating the appliance with the Bellfires Gas S S et a program Select one of the eight available programs by pressing on the number of the program Set the start time and the start temperature by selecting the green segments. -
Page 25: Fan (Optional)
Operating the appliance with the Bellfires Gas S S et a flame cycle Select ECO mode from the menu. Select L L ow fire, M M edium fire or H H igh fire by pressing one of the three flame icons on the bottom of the screen. -
Page 26: Lighting (Optional)
Operating the appliance with the Bellfires Gas Set the fan speed by selecting the preferred speed 1 to 4. Press the Power button on the bottom of the screen. Press the Power button on the bottom of the screen again to stop the ventilator. -
Page 27: Aux (Double Burner)
The A A UX symbol is yellow in the quick menu, when the double burner is active. 8.3.10 Safety lock With active safety lock, it is not possible to use the functions of the Bellfires Gas app. It is only possible to switch the appliance to OFF. Activating the safety lock Open the main menu Press the S S afety lock icon for two seconds. -
Page 28: Operating The Appliance With The Puck
Operating the appliance with the Puck Operating the appliance with the Puck Start the appliance Press and hold the ON/OFF button until two short beeps confirm the start of the start-up sequence. The main burners start when the pilot flame ignition is confirmed. -
Page 29: Troubleshooting
Wi-Fi Box and the receiver. Also, if applicable and possible, make screen shots of the error code that shows in the Bellfires Gas app or make a screen shot of the page when the problem occurred. - Page 30 The appliance sometimes does Multiple users are on the same Press the reset button on the not react to the Wi-Fi Box Wi-Fi channel. Bellfires Gas app for 1 second to change to another channel 3.2.1 (refer to chapter and end of this chapter).
-
Page 31: Technical Data
Technical data 1 1 1 Technical data Wi-Fi Box Puck Temperature range 0 ºC - 80 ºC 0 ºC - 55 ºC Radio frequency 2.4 GHz 868 MHz Power supply 6 VDC 2 x 1.5 V 'AAA' alkaline batter- Wireless communication •... -
Page 32: Warranty Terms
Complaints will only be accepted if they are reported to the Bellfires dealer, together with the serial number of the Bellfires appliance which is stated on the front of the user manual. In addition, the original receipt (invoice, receipt, cash receipt) showing the date of purchase must also be submitted. - Page 33 Article 5: Warranty period This warranty will only be granted during the warranty period. The body of the Bellfires appliance is guaranteed for a period of 10 years against construction and/or material faults, starting from the moment of purchase. For other parts of the Bellfires appliance, a similar warranty applies from the moment of purchase for a period of two years.
- Page 34 Warranty Terms 3 3 4 Wifi Box...
- Page 35 Warranty Terms Wifi Box 3 3 5...
- Page 36 Y Y our Bellfires dealer 001 - 19.11.2018 - 342810...
