For proper handling of the higher reading resolution and the extended status indicator capabilities of
the HR-E LCD encoder, the following software versions are required for your reading system:
Oeading Data Ianagement Software
ReadCenter® Data: Version 1.11.12.27 or higher (does not include extended status
indicator capabilities)
ReadCenter Analytics and ReadCenter Analytics Mobile: Version 2.12.7.6 or later
Iobile Oeading Systems
ORS: Version 2.2.1 or later
Handheld Oeading Systems
Badger Meter Field Application Suite: Version 2.2.3 or later
ORION Field Application route reading software: Version 2.2.3 or later
ORION Endpoint Utility programming & quick read software: Version 2.2.2 or later
Please contact Badger Meter Technical Support at 1-800-456-5023 or the appropriate
endpoint provider if you need assistance.
LCD-UM-01482-EN-07 (April 2019)
High Resolution LCD Encoders
HR-E® LCD, HR-E® LCD 4-20
I
IMPORTAR
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HR-E LCD and is the answer not in the manual?

Questions and answers

Lynn Willow
April 21, 2025

Why is my encoder not reading. It is new. And how do I clear an alarm.

1 comments:
Mr. Anderson
May 11, 2025

The Badger Meter HR-E LCD encoder may not be reading due to a communication error between the encoder and the endpoint. This is indicated when BEACON receives data but cannot obtain a reading. The alarm can also be triggered by conditions like no measured flow for 30 days or suspected leaks.

To clear the alarm:
- For communication errors, the condition clears automatically when a new valid reading is obtained.
- For suspected leaks, the alarm clears automatically after a 15-minute no-flow interval.
- For 30-day no usage, the alarm clears once flow resumes.
- The end-of-life alarm triggered at 19 years does not clear automatically.

Ensure the device is properly aligned with the IR port and remains still during operation to avoid read errors.

This answer is automatically generated

Summary of Contents for Badger Meter HR-E LCD

  • Page 1 HR-E® LCD, HR-E® LCD 4-20 IMPORTAR For proper handling of the higher reading resolution and the extended status indicator capabilities of the HR-E LCD encoder, the following software versions are required for your reading system: Oeading Data Ianagement Software •...
  • Page 2: Table Of Contents

    HR-E LCD 4-20 . . . . . . . . . . . . . . . . . . .
  • Page 3: Introduction

    The HR-E LCD 4-20 is a permanently sealed, electronic LCD absolute encoder that produces an industry standard ASCII encoded output as well as an analog 4-20 mA DC output signal with a dual output wire design . HR-E LCD 4-20 encoders are designed for use with all current Badger Meter Recordall®...
  • Page 4: Product Overview

    IR Programming Status Port Indicators Figure 1: HR-E LCD encoder face Visual Display Units of Measure The units of measure are factory-programmed and user-programmable . Options include U .S . gallons, Imperial gallons, cubic feet, cubic meters and liters .
  • Page 5: 6-Digit Totalization

    When water is flowing through the meter, the display includes a series of moving segments to represent a flow finder . This screen displays for 5 seconds . 6-digit totalization mode is active on the HR-E LCD and HR-E LCD 4-20 encoders . Model 25 Disc Series Meter Calibrated in Gallons In 9- and 6-digit totalization mode, the display also includes indicator lines above and below the digits to provide the electronic equivalent of the white and black number wheels on a mechanical encoder .
  • Page 6: Installing The Encoder

    The following connection options are available . For more information on in-line connectors, refer to the document, ORION Water Endpoints Installation Manual, available at www.badgermeter.com . HR-E LCD The HR-E LCD encoder has a single cable, available with three different wiring options . Refer to Figure •...
  • Page 7: Hr-E Lcd

    MPORTANT The standard electronic encoder output resolution of the HR-E LCD encoder is 9 digits. Though the encoder output is 9-digit resolution, the reading resolution sent to the reading software is dependent on the endpoint that the encoder is connected to.
  • Page 8: Status Indicators

    . All HR-E LCD encoders are delivered in storage mode so that a meter alarm is not triggered . During storage mode, the meter model displays on the encoder . As water begins to flow through the meter, the encoder switches from storage mode to normal operation upon sensing two (2) revolutions of the meter magnet .
  • Page 9: Hr-E Lcd 4-20

    HR-E LCD 4-20 HR-E LCD 4-20 The HR-E LCD 4-20 is a permanently sealed, electronic LCD absolute encoder which produces an industry standard ASCII encoded output as well as a 4-20 mA DC output signal through a dual output wire design .
  • Page 10: Analog Output

    MPORTANT The standard electronic encoder output resolution of the HR-E LCD 4-20 encoder is 9 digits. Though the encoder output is 9-digit resolution, the reading resolution sent to the reading software is dependent on the endpoint that the encoder is connected to.
  • Page 11: Status Indicators

    . All HR-E LCD 4-20 encoders are delivered in storage mode so that a meter alarm is not triggered . During storage mode, the meter model displays on the encoder . As water begins to flow through the meter, the encoder switches from storage mode to normal operation upon sensing two (2) revolutions of the meter magnet .
  • Page 12 The Americas | Badger Meter | 4545 West Brown Deer Rd | PO Box 245036 | Milwaukee, WI 53224-9536 | 800-876-3837 | 414-355-0400 México | Badger Meter de las Americas, S.A. de C.V. | Pedro Luis Ogazón N°32 | Esq. Angelina N°24 | Colonia Guadalupe Inn | CP 01050 | México, DF | México | +52-55-5662-0882 Europe, Eastern Europe Branch Office (for Poland, Latvia, Lithuania, Estonia, Ukraine, Belarus) | Badger Meter Europe | ul.
