- Page 1 FULLY GUARANTEED OPERATING & SAFETY INSTRUCTIONS AMX110 AMX620 AMX622 intex.com.au portamix.co.nz •...
-
Page 2: Technical Data
• Serious injury can occur through misuse or accident. Do not work in a cluttered or unsafe working area. Keep children away from mixing equipment. • The machine must not be damp and must not be operated in a wet environment. • Always wear eye, respiratory and hearing protection equipment and suitable protective clothing. • Always inspect cable and plug before using machine. All repairs must be carried out by a qualified professional. • M achines that are used with wet materials or in damp areas should be used with a residual current circuit breaker. Use only extension cables that are intended for outdoor use and are protected against splash water. (picture 1) (picture 2) (picture 3) • Ensure the machine is turned off before connecting to the power socket. 2 › INTEX GROUP MEGAMIXER MANUAL | w intex.com.au w intex.com.au | . INTEX GROUP MEGAMIXER MANUAL › 3... -
Page 3: Maintenance
After switching the machine on, the machine can be help on by pressing the lock button. To verify that the protective insulation remains intact, the machine much be subjected to a To release and turn off, press then release the switch. technical safety test afterwards. For this reason, this work much be performed exclusively by a professional workshop. CHANGING GEAR (2 SPEED GEARBOX MODELS) Ensure that the motor is turned of and rotation has stopped. The unit should be stored in a dry place where it is protected against moisture. Depress the gear change slide button and shift to next gear position. DISCONNECTING THE M14 THREADED MIXING-PADDLE: Using a flat open-end wrench on the spindle flats of the mixing tool and machine spindle, unthread the mixing-paddle from the spindle by turning it anti-clockwise. 4 › INTEX GROUP MEGAMIXER MANUAL | w intex.com.au w intex.com.au | . INTEX GROUP MEGAMIXER MANUAL › 5... -
Page 4: Parts Diagram
BACK COVER FOR MOTOR HOUSING BACK HANDLE BOLT FOR HANDLE FIXING SCREW ST 3.8×14 INSIDE COVER OF BACK HANDLE CABLE PRESSING BOARD SWITCH CAPALITAR 6 › INTEX GROUP MEGAMIXER MANUAL | w intex.com.au w intex.com.au | . INTEX GROUP MEGAMIXER MANUAL › 7... - Page 5 CROSSING TAPPING SCREW ST3X25-F SWITCH(FA2-6/2D-A1-B1-F3) HOUSING BACK COVER HEAD HOUSING CROSSING TAPPING SCREW ST5X45-F MAIN DRIVING SHAFT MIXER PADDLE KEY 4X8 SPANNER 8 › INTEX GROUP MEGAMIXER MANUAL | w intex.com.au w intex.com.au | . INTEX GROUP MEGAMIXER MANUAL › 9...
- Page 6 CROSSING TAPPING SCREW ST5X55-F PUSHING BUTTON SPRING CABLE CABLE SLEEVE KEY 5X45 CABLE PLATE TWOGANG GEAR CROSSING TAPPING SCREW ST4X14-F VARIABLE SHAFT MIXING PADDLE 10 › INTEX GROUP MEGAMIXER MANUAL | w intex.com.au w intex.com.au | . INTEX GROUP MEGAMIXER MANUAL › 11...
- Page 7 3 – 7 AMCOR WAY CAMPBELLFIELD VICTORIA 3061, AUSTRALIA PO BOX 109 SOMERTON VICTORIA 3062, AUSTRALIA P +61 3 9357 9299 F + 61 3 9357 0777 intex.com.au SPE SYSTEMS 1 EDWIN FEIST PLACE MASTERTON 5810 P.O BOX 2007 MASTERTON 5842...
