Integrated Larder Fridge
MICL88
- 88cm - Slider Fixings
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING
Installation and Operating Instructions
- In Column
Advertisement
Table of Contents
Related Manuals for Montpelier MICL88
Summary of Contents for Montpelier MICL88
- Page 1 Installation and Operating Instructions Integrated Larder Fridge - In Column MICL88 - 88cm - Slider Fixings Please read these instructions carefully before attempting to install or use this appliance. We recommend that you keep these instructions in a safe place for future reference.
- Page 2 Welcome Thank you for choosing this Montpellier Integrated Larder Fridge. Our refrigeration products have been designed to provide you with the best combination of style, reliability and performance to give you years of trouble-free use. You may be familiar with a similar product, but please take time to read these instructions carefully before installing or using your Fridge to ensure you get the most from your purchase.
-
Page 3: Table Of Contents
CONTENTS 1 SAFETY INSTRUCTIONS ................. 4 1.1 General Safety Warnings ....................4 1.2 Installation warnings .......................7 1.3 Electrical information (For UK type plug) ................7 1.4 During Usage........................8 2 DESCRIPTION OF THE APPLIANCE ............... 9 3 USING THE APPLIANCE .................. 9 3.1 Thermostat Setting ......................9 3.2 Temperature Settings Warnings ..................9 4 FOOD STORAGE .................... -
Page 4: Safety Instructions
1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings Read this user manual carefully. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. - Page 5 natural gas, but it is explosive. In the event of a leak due to damage of the cooler elements, move your fridge away from open flames or heat sources and ventilate the room where the appliance is located for a few minutes.
- Page 6 • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 7: Installation Warnings
• Clearance of at least 150 mm is required 1.2 Installation warnings at the top of your appliance. Do not place Before using your fridge for the first time, anything on top of your appliance. please pay attention to the following points: •... -
Page 8: During Usage
1. Remove the fuse cover and fuse. this product is disposed of correctly, you will help prevent potential negative 2. Fit replacement 13A fuse, ASTA consequences for the environment and approved to BS 1362 type, into the fuse human health, which could otherwise be cover. -
Page 9: Description Of The Appliance
2 DESCRIPTION OF THE 3 USING THE APPLIANCE APPLIANCE 3.1 Thermostat Setting The fridge thermostat automatically regulates the temperature of the compartment. Fridge temperatures can be obtained by rotating the knob to higher numbers, 1 to 5. Important note: Do not try to rotate the knob beyond position 1, it will stop your appliance from working. -
Page 10: Food Storage
4 FOOD STORAGE • When the appliance is first switched on, allow it to run for 24 hours in order to • To reduce humidity and avoid the reach operating temperature. During this consequent formation of frost, always time, do not open the door and do not store liquids in sealed containers in the keep a large quantity of food inside. -
Page 11: Cleaning And Maintenance
5 CLEANING AND • Do not put food in front of the air flow passage. MAINTENANCE • Consume packaged foods before the recommended expiry date. Disconnect the unit from the power supply before cleaning. NOTE: Potatoes, onions and garlic should not be stored in the refrigerator. Do not wash your appliance by pouring water on it. -
Page 12: Defrosting
5.1 Defrosting 5.2 Replacing the Light Bulb Defrosting the Refrigerator Important note: Unplug the unit from Compartment the power supply before start the process. 1. Remove the screw on the light cover by screw driver. (Fig.1) 2. Press the hooks on light cover. (Fig. 2) 3. -
Page 13: Shipment And Repositioning
6 SHIPMENT AND 7 BEFORE CALLING AFTER- REPOSITIONING SALES SERVICE Your fridge is not operating 6.1 Transportation and Changing Check if: Positioning • There is power • The original packaging and foam may be • The plug is correctly connected to the kept for re-transportation (optional). -
Page 14: Tips For Saving Energy
8 TIPS FOR SAVING ENERGY The door is not opening and closing properly 1. Install the appliance in a cool, well- Check if: ventilated room, but not in direct sunlight • There is food or packaging preventing the and not near a heat source (such as a door from closing radiator or oven) otherwise an insulating •... - Page 15 Here For You Here For You After-sales assistance If you continue to experience problems with your Integrated Larder Fridge, please call the Montpellier After-sales assistance customer service helpline on: 01759 487839 If you continue to experience problems with your Integrated Larder Fridge, please call the Montpellier Please have all your product details available, including the model number, serial number, date of purchase, customer service helpline on: 01759 487839...
- Page 16 Montpellier Domestic Appliances Ltd. Unit 1, Tewkesbury Retail Park, Northway Lane, Tewkesbury, Gloucestershire GL20 8JU www.montpellier-appliances.com The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
