Summary of Contents for MS Schippers Pro 150
-
Page 1: Ms Semen Storage Pro 150
MS Semen Storage Pro 150 4508425 MS Semen Storage PRO 150 Operating instructions ..................... 3 4508425/11-01-2016/F... -
Page 2: Table Of Contents
Introduction ............................. 4 MS Semen storage ........................... 5 Recommendations ..........................5 Installing the MS Semen Storage Pro 150 ....................5 Technical specifications ........................... 6 Precautionary measures and safety instructions ..................7 The MS Semen Storage PRO 150 Display ....................8 Adjusting the default temperature ...................... -
Page 3: Provisions
MS Schippers reserves the right at any time, without prior notice, to make changes to the structure of equipment or the information in the manual, without any resulting obligation to apply these changes to products already delivered. -
Page 4: Introduction
However, it remains the user's responsibility to observe the safety regulations during working operations. The MS Semen Storage Pro 150 is a sperm storage cabinet with a whopping 150-litre volume, suitable for Professional farmers and breeders. Temperature control is extremely accurate, with additional cooling and heating capacity to maintain the optimum temperature, keeping it stable and consistent. -
Page 5: Ms Semen Storage
Avoid shocks during movements. We advise you to turn off the MS Semen Storage Pro 150 when not in use, to save electricity. Do not place the MS Semen Storage Pro 150 in direct sunlight, because that will lead to higher energy consumption. -
Page 6: Technical Specifications
Technical specifications Model MS Semen Storage Pro 150 Capacity 150 L Cooling agent R-134 Fluorine-free coolant Power used 230 V ~ 50 HZ Fuse 5 x 20 mm, F5AL 250 V Ambient temperature: 5-35 ℃, Humidity: ≤95% Air pressure: 860 - 1060 hPa... -
Page 7: Precautionary Measures And Safety Instructions
This appliance complies with safety regulations applicable within the European Union. We use the following symbols in this manual, to ensure proper and safe use of the MS Semen Storage Pro 150. This symbol indicates a tip This symbol indicates a general point for attention... -
Page 8: The Ms Semen Storage Pro 150 Display
The MS Semen Storage PRO 150 Display (1) "RUN" will illuminate when the MS Semen Storage Pro 150 is running. (2) "HEAT" will illuminate when the heating element is active, and will go out when it is switched off. (3) "COOL" will illuminate when the storage cabinet is cooling, and will go out when refrigeration is disengaged. -
Page 9: Adjusting The Default Temperature
Adjusting the default temperature By default, the MS Semen Storage Pro 150 is set at 17 °C but you can set it to the precise temperature you require. Figure 1 shows you the standard menu on the MS Semen Storage Pro 150. The 20 °C is the actual compartment temperature and 17 °C is the set value, to which the unit must be... - Page 10 To adjust the default UV-light setting, simply press the button on the extreme right ("Settings") twice. You can see the screen that will follow in figure 4. Figure 4 Using the up “▲” and down “▼” you can adjust the default value of 0 minutes to the required time.
