Summary of Contents for Suaoki G19

  • Page 1 G19 12V/24V Jump Starter User Manual...
  • Page 2 Thank you for choosing Suaoki 12V/24V Jump Starter. Please take some time to familiarize yourself with the instructions before trying out this product. You may need to keep this manual for future reference. Main Features SUAOKI G19 1. Intelligently detect the voltage of your car battery 2.
  • Page 3 A - USB Output Port B - Power Indicator Light C - Master Button D -12V Indicator Light E - 12V Forced Start Button F - Input Port G - LED Flashlight H - 24V Forced Start Button J - 24V Indicator Light Notice 1.
  • Page 4 Instruction How to read the power indicator light? 1. Check the remaining power level Press the master button to activate the lights. There are 4 indicator lights in total to display the amount of battery power left. See the chart below to understand how the No. of lights and battery level corresponds: No.
  • Page 5 Blind area-It cannot 13.5V≤Vb 12V and 24V indicator identify the voltage ≤14.5V light flash alternately of vehicle’s battery 14.5V≤Vb 24V indicator light The voltage of 24V ≤16V flashes battery is too low 14.5V≤Vb 24V indicator light You can start the ≤16V is on engine now...
  • Page 6 Note: DO NOT use the car charger on a 24V car. Failure to fully charge this product may be caused by prolonged storage. Battery capacity could be restored by fully discharge this product using USB output port and then fully charge it. Repeat this discharge/charge cycle for several times.
  • Page 7 How to use the LED flashlight? 1. Double-click the master button to turn on the flashlight. 2. Single-click the button to change the flashlight mode in sequence: Strong →Strobe →SOS →Off. How to start a 12V/24V vehicle? 1. Check the remaining power. Make sure that the residual capacity of the jump starter is more than 75% when you are going to start a 24V vehicle, or more than 50% when you are going to start a 12V vehicle.
  • Page 8 Manual Force Start NOTE: There is no short circuit protection under manual force start mode. Please make sure that the battery clamps are connected correctly. 1. Disconnect the clamps from the battery of your vehicle. 2. Confirm the voltage of your vehicle. 1) If the voltage of your vehicle is 12V, you need to hold the FORCED START 12V button for 5 seconds.
  • Page 9 Intelligent Protection 1. 12V / 24V Short Circuit Protection Short-circuit situations Effects Short circuit protection Short-circuit the red and black clamps when the jump starter is off. Short-circuit the red and black clamps when the power indicator light is on. Short-circuit the red No effects and black clamps...
  • Page 10 When the red and black clamps are reversely connected to the polarities of car battery. When the clamps are loosely connected to the car battery. 2. USB Output Short Circuit Protection If the USB output port is shorted, all four power indicator lights would flash.
  • Page 11 DC plug and re-connect the adapter with the socket. D. Reverse Polarity Protection: 12V/24V indicator lights flash alternatively. The built-in buzzer would keep beeping until the clamps are connected correctly. Product Parameter Model: G19 Battery Capacity: 24000mAh/88.8Wh Input: 15V/2A USB Output: 5V/2.4A Start Output Voltage: 12V/24V Start current: 500A-12V,250A-24V Peak current: 1000A-12V;...
  • Page 12 Contact US Website: www.suaoki.com E-mail: support@Suaoki.com For any inquiries or comments concerning our products, please send an email to support@suaoki.com, and we will respond to you as soon as possible. EN-11...
  • Page 13 MADE IN CHINA Web: www.suaoki.com E-mail: support@suaoki.com...
