Primus BALLISTA100T Setup Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
BALLISTA100T
SETUP

Advertisement

loading
Need help?

Need help?

Do you have a question about the BALLISTA100T and is the answer not in the manual?

Questions and answers

Related Manuals for Primus BALLISTA100T

Summary of Contents for Primus BALLISTA100T

  • Page 1 BALLISTA100T SETUP...
  • Page 2 I. WINDOWS REQUIREMENT • Windows XP/ Windows Vista /Windows 7 /Windows 8 /Windows 10 • Available USB port (V1.1/2.0/3.0) • 5MB of free disk space...
  • Page 3 II. SETUP...
  • Page 4 1. Download the Ballista software from our website at primusgaming.com/software. 2. Connect the gaming keyboard to an available USB port. 3. Double click the BALLISTA100T_Setup file. 4. You will be prompted to select the setup language. The available languages are English or Spanish.
  • Page 5 4.2MB of free disk space. Click Next to continue. 7. Select Start Menu folder location where you want the software to be displayed. The default location is Primus\BALLISTA100T. You may change this path if desired. Click Next when done.
  • Page 6 8. You are now ready to install your brand new Primus BALLISTA100T gaming keyboard. Click on Install. 9. Click on Finish to complete the setup.
  • Page 7 III. MAIN SOFTWARE INTERFACE...
  • Page 8 The Main software screen will be displayed. In this menu you can configure the lights, setup a macro, assign personalized keys, and set different profiles.
  • Page 9 1. Programming profiles You can assign up to 3 different profiles. To do so, click on Profile 1, make all the software changes you would like to assign to this profile slot and then click Apply to save the settings. Do the same for Profile 2 and 3.
  • Page 10 2. Programming keys The software allows for all keys to be customized in order to execute specific functions. Keys can be programmed as follows: • Single key or combination keys: you can input a single key command or a combination of key commands to any key.
  • Page 11 2. Once the following screen is displayed, click on Key assignment. 3. You can press any key on the keyboard to assign a different value to Q. We will change it to Ctrl-Z. Press Z and click on the Ctrl button. Once done, click OK to save the setting.
  • Page 12 4. Now every time you press Q on your keyboard, it will automatically press Ctrl-Z, which is the Undo function in Windows. 5. If you want to reset the function key, click on Q again. Then press the restore button on the upper right corner followed by OK to accept the change.
  • Page 13 B. Assign a multimedia key: For illustration purposes, we will use the Q key. 1. Click on Q. You will get a popup as seen below. Click on Media. 2. Select any of the 18 preset functions. Once done, click OK. Now any time you click on Q, the selected preset will occur.
  • Page 14 C. Macro editor: 20 macros, and each macro can contain a maximum of 8 characters. 1. Click on Macro editor. A new window will open. Right click under Macro List and select New macro. 2. Enter a name for the Macro. For this example we will use Test. Once done, click on OK.
  • Page 15 3. Ensure the Macro you just made is highlighted. Press on Start record. Now you can enter in any combination of characters you want. Automatic recording time delay is on by default. So, it will automatically record how much time you take between key presses. This feature can be turned off.
  • Page 16 D. Macro options • Macro loop settings: A. Cycle until the key is released: This will repeat the macro until you release the macro button. B. Specified cycle times: Here you can enter how many times you want the macro to loop over and over again.
  • Page 17 2. You can also use the Insert event option to edit your Macro. Just pick a spot in the key list you wish to insert the event. The available options are: Key down, Key up, or Delay.
  • Page 18 E. Import/Export Macro: 1. Export: Click on the Macro you wish to export. Right click and select Export. Name the Macro, choose a folder on your computer and click Save. 2. Import: Right click on the empty space on the Macro list. Click on Import macro, go to folder containing your saved Macros.
  • Page 19 F. Assign macro key: 1. To assign a Macro, click on the key you wish to assign the desired sequence. In this example, we will assign the Test macro to the letter Q. 2. Click on Q followed by Macro. Choose the macro from the list and then click on OK. 3.
  • Page 20 3. Lighting effects: 1. This menu allows you to configure the lighting effects and colors on the keyboard. Click on the Light option. 2. There are 10 different lighting effects available. Some of them allow you to pick the brightness or speed.
  • Page 21 3. Click Apply to save your color and illumination settings.

  • Page 22: Multimedia Functions

    IV. MULTIMEDIA FUNCTIONS...
  • Page 23 1. The keyboard comes with quick command functions • Fn+F1 = My Computer • Fn+F2 = Search • Fn+F3 = Calculator • Fn+F4 = Open Music player • Fn+F5 = Previous track • Fn+F6 = Next track • Fn+F7 = Play/Pause •...
  • Page 24 3. Pre-set backlight mode: The LED will light up on the defined preset keys based on the game mode you are on. • FN+1= game mode 1 (FPS) - ASDW ↑↓←→ ESC • FN+2= game mode 2 (CF) - ASDW Ctrl Shift Alt Space RGQEB 1-5 Tab F1-F4 Home End PgUp PgDn PrtSc SCRLK •...
  • Page 25 SOFTWARE INSTALLATION GUIDE...
