Summary of Contents for Millenium Mechatronics MI104

  • Page 1 MI104 INDICATOR Weighing Indicator User Manual...

  • Page 2: Table Of Contents

    MI104 Weighing Indicator User Manual CONTENTS SPECIFICATIONS….………………………………………………….……..3 INTRODUCTION………………………………………………………………...4 INSTALLATION …………………………………………………………………..5 Unpacking…………………………………………………………………..5 Installation…………………………………………………………………..5 Load cell connections..………………………………………………...6 Connect Adaptor and Charging..………………………………………...6 DESCRIPTION……………...……………………………………………...7 Overall view………………………………………………………………...7 Display……………………………………………………………………..7 Key board……………………………………………………………..…….8 OPERATION.…………………….………………………………….………….9 5.1. Power ON/OFF……………………………………………..………..9 5.2. Zero……………………..............9 5 . 3 . T a r e ..............9 5.4.

  • Page 3: Specifications

    MI104 Weighing Indicator User Manual 1. SPECIFICATIONS Model MI104 Resolution 1/30,000 Indicator housing ABS Plastic Stabilisation Time 1 Seconds typical Operating Temperature 0°C ~ +40°C / 32°F - 104°F AC Adaptor (12V/500mA) / Power supply (external) Ni-MH battery (1.2V/2000mAh x 6)

  • Page 4: Introduction

     It is suitable for general weighing or more specialized applications such as check weighing, animal weighing and accumulation applications.  MI104 Indicator can be connected to a Serial printer or a PC.  MI104 has a large (22mm high) LCD with white LED back light display - 4 -...

  • Page 5: Installation

    MI104 Weighing Indicator User Manual 3. INSTALLATION Unpacking When you receive the indicator / scale, inspect it to make sure that it is not damaged and that all are parts are included:  Remove the Indicator from the carton.  Remove the protective covering. Store the packaging to use if you need to transport the indicator later.

  • Page 6: Load Cell Connections

    Pin 4 Exc - Pin 5 Exc + MI104 can connect upto four 350 ohm load cells/ eight 700 ohm load cells. The load cell excitation voltage is 5V DC ±5% between Excitation + and Excitation -. Connect Adaptor and Charging ...

  • Page 7: Description

    MI104 Weighing Indicator User Manual 4. DESCRIPTION Overall View Display DISPLAY FUNCTION Check weighing ZERO Indicator for Zero display TARE Indicator for Tare display GROSS Indicator for Gross weight Indicator for Net weight STABLE Indicator for Display stability AUTO Indicator for Auto Accumulation...

  • Page 8: Key Board

    MI104 Weighing Indicator User Manual Key Board FUNCTION Turn the power On/ Off Used to reset to Zero. In setting mode can use to confirm entry Used to record tare values and change the value from gross value to net value. In setting mode, this key can be used to increase the value and scroll (up) in menu.

  • Page 9: Operation

    MI104 Weighing Indicator User Manual 5. OPERATION Initial Start – Up: Warm-up time of 15 minutes stabilizes the measured values after switching on. 5.1. Power ON/OFF: Switch on the balance by pressing key. The display is switched on after the self test(countdown). To switch off, press again the key.

  • Page 10: Check Weighing

    MI104 Weighing Indicator User Manual 5.5. Check Weighing It can set an upper or lower limit when weighing with the limits range. The unit will indicate whether a display value(weight) is within upper or lower limits with an alarm sound . For details see the parameter F3 oFF.

  • Page 11: Set Check Weighing Mode

    MI104 Weighing Indicator User Manual After entering the settings mode, F3 oFF Press until display will be appear bEEP Press key to enter, press until display show Press key to enter, press Check mode 1 Check mode 2 Check mode 3...

  • Page 12: Accumulation Automatically

    MI104 Weighing Indicator User Manual Wait few seconds for display stable. Then press . The value will be saved. Followed by the total number of weight will be displayed It can continue the process until the maximum capacity or value.

  • Page 13: Animal Weighing

     When the display gets stable for few seconds , the reading will be locked followed by a beep. 5.12. Peak Hold MI104 can operate peak hold function, peak reading will be stored and will update automatically when a newer peak is reached. For this function, select parameter P4 CHk to ModE 4...

  • Page 14: Parameter Block

    MI104 Weighing Indicator User Manual Select the menu  Press , it can change the menu block one by one.  Using increase the digit. Enter the selected menu  Press , it can confirm, which will be shown displayed.
  • Page 15 MI104 Weighing Indicator User Manual El on Display of back light on F3 oFF El au Display of back light on automatically El off Display of back light off beep Bp 1 Beep sound off during the check weighing Bp 2...
  • Page 16 MI104 Weighing Indicator User Manual Ty 711 Label printer Lp 50 Label printer prog Enter the programming and calibration menus by using password (Refer section 7 – Calibration on password entry). PROGRAM PARAMETERS Menu Sub Menu Description A2n 0 0.5d...

  • Page 17: Calibration

    MI104 Weighing Indicator User Manual You can calculate new rate by this formula & enter it: New rate = Old rate*Display weight/ Calibration weight. Count This display will show XXXXX for indicating the internal counts. Reset Factory default settings Set the local gravity...
  • Page 18 MI104 Weighing Indicator User Manual linear  Enter the function by pressing , display will show Nonlin  Press to select for normal calibration Nonlin Normal Calibration: unload  Enter the function by pressing , display will show   Make sure there are no loads on the platform and wait few seconds for stable indicator on.
  • Page 19 Linear Calibration The linearity error caused by the performance of the weighing unit can be corrected by “Linearity Calibration”. The digital linearization function can reduce the linearity error. MI104 employs a 3-point linearisation. linear Precise weight (1/3 , 2/3 and full capacity ) are needed for Linear calibration.

  • Page 20: Rs232 Out Put

    Pin 5: Pin 5 Note: If data not getting in to PC, inter-change the Pin 2 and Pin 3 connections from one of the connecter. (9 pin round connector is supplied with MI104 Indicator Continuously output protocol Weighing Mode; -14- ，...
  • Page 21 MI104 Weighing Indicator User Manual Print Out Formats Note: Lab 0 & 2 for English , Lab 1 and 3 are optional. 2011/12/30 11:11 WEIGHT: 1.00kg WEIGHT: 1.00kg 2011/12/30 11:11 WEIGHT: 1.00kg WEIGHT: 1.00kg TOTAL: 1.00kg TOTAL: 1.00kg 2011/12/30 11:11 NET: 1.00kg...

  • Page 22: Drawing

    MI104 Weighing Indicator User Manual 9. DRAWING Parts Name Key board overlay Overlay Upper cover Display protection Plate Key pad hat Main board PCBA Insulated washer Seal thread screw Rubber sealing ring Self-thread screw Battery Clamp Ni- NH battery Washer...
