1-1 337-1064-04
2 SHIELD,ELEC:SIDE PLUG-IN UNITS
80009 337-1064-00
-2 366-1391-02
1 KNOB :GY,0.081 ID 0.28 OD,0 .32 L
80009 366-1391-02
213-0725-00 1 .SETSCREW:3-48 X 0.095 INCH,HEX SOC S
74445 OBD
-3 366-1319-02
1 KNOB :GY,0.79 ID,0.28 OD,0 .32 H
80009 366-1319-02
213-0725-00 1 .SETSCREW:3-48 X 0.095 INCH,HEX SOC S
74445 OBD
-4 366-1077-00
2 KNOB :GRAY
80009 366-1077-00
213-0153-00 2 .SETSCREW:S-40 X 0.125,S'1'L BK OXD,HEX
OOOCY OBD
-5 366-1189-00
2 KNOB :GRAY
80009 366-1189-00
213-0153-00 2 .SET'SCREW :S-40 X 0.125,S1'L BK OXD,HEX
OOOCY OBD
-6 366-1058-67
1 KNOB :LATCH--7885
80009 366-1058-67
***.* . ,.,. (ATTACHING PARTS)"*""'""
-7 214-1095-00
1 PIN,SPG,SPLIT:0 .094 OD X 0.187 INCH LONG
22599 52-022-094-0187
""""""(END ATTACHING PARTS)""""'
-8 366-1023-01
1 KNOB:GY,0.127 ID X 0.392 OD X 0.
80009 366-1023-01
213-0153-00
1 .SETSCREW:5-40 X 0.125,STL BK OXD,HEX
OOOCY OBD
-9 366-1166-00 1
KNOB :RED,0.127 ID X 0.392 OD
80009 366-1166-00
213-0153-00
1 .SETSCREW:S-40 X 0.125,STL BK OXD,HEX
OOOCY OBD
-10 366-1103-00 1
KNOB :GRAY
80009 366-1103-00
213-0153-00
2 .SETSCREW:S-40 X 0.125,STL BK OXD,HEX
OOOCY OBD
-11 366-1023-01
1 KNOB :GY,0.127 ID X 0.392 OD X 0.
80009 366-1023-01
-12 366-1257-93
1 PUSH BUTTON :+10 MAG
80009 366-1257-93
-13 366-1559-00 1
PUSH BUTTON :SIL GY,0 .18 SO X 0.43
80009 366-1559-00
-14 426-0681-00
1 FR,PUSH BUl'TON:GRAY PLASTIC
80009 426-0681-00
-15 426-1072-00
1 FRAME,PUSH BTN:PLASTIC
80009 426-1072-00
-16 131-1315-01
1 CONN,RCP'T,ELEC :BNC,FEMALE
24931 28JR 306-1
-17 105-0076-02 8010100 8092229 1
REL BAR,LATCH :PLUG-IN UNIT
80009 105-0076-02
105-0076-04 8092230
1 REl-EASE BAR,LCH :PLUG-IN UNIT
80009 105-0076-04
-18 214-1280-00 1
SPRING,HLCPS :0 .14 OD X 1 .126"L,0 .16"DIA
80009 214-1280-00
-19 333-1836-00 8010100
8085809 1 PANEL,FRONT:
80009 333-1836-00
333-1836-01 B085810 1
PANEL,FRONT:
80009 333-1836-01
-20 378-0074-00
14 REFLECTOR,LIGHT :PUSH BUTTON
80009 378-0074-00
-21 366-1650-00 14
PUSH BUTTON :CLEAR,0 .184 X 0.214 X 8.0 L
80009 360-1650-00
-22 351-0469-00
2 GUIDE,SWITCH :4 BUTTON
80009 351-0469-00
-23 351-0469-01 2 GUIDE,SWITCH :3 BUTTON
80009 351-0469-01
-24 200-0935-00
4 BASE,LAMPHOLDER:0 .29 OD X 0.19 CASE
80009 200-0935-00
-25 ---------- 1 LAMP,LED :2 .0 VOLTS.GREEN(SEE CR220 REPL)
-26 ----------
1 LAMP,LED :2 .2 VOLTS,YELLOW(SEE CR232 REPL)
-27
352-0157-00 2
LAMPHOLDER :WHITE PLASTIC
80009 352-0157-00
-28 ---------- 1
RESISTOR,VAR :(SEE R60 REPL)
"""'"'"""'"(ATTACHING PARTS)"""'*""
-29 210-0583-00 1
NUT,PLAIN,HEX:0 .25-32 X 0.312 INCH,BRS
73743 2X20317-402
""""'"""(END ATTACHING PARTS)""'"'""
-30 ---------- 1
RESISTOR,VAR :(SEE R410/R415 REPL)
"'"'"'""""(ATTACHING PARTS)"""""'
-31
210-0583-00 2 NUT,PLAIN,HEX :0 .25-32 X 0.312 INCH,BRS
73743
2X20317-402
-32
210-0046-00 1 WASHER,LOCK :0.261 ID,INTL,0 .018 THK,BRS
78189
1214-05-00-0541C
""""""'(END A'I"TACHING PARTS)"""*"
-33 ----------
2 RESISTOR,VAR :(SEE 8520 AND R530 REPL)
""""""'*(ATTACHING PARTS)""""""
-34 210-0583-00
4 NUT,PLAIN,HEX:0 .25-32 X 0.312 INCH,BRS
73743 2X20317-402
-35
210-0046-00 2 WASHER,LOCK :0 .261 ID,INTL,0 .018 THK,BRS
78189 1214-05-00-0541C
""""""(END ATTACHING PARTS)""'""'
-36 ----- -----
1 RESISTOR,VAR :(SEE 8210 REPL)
"""""""'(ATTACHING PARTS)""""""
-37 210-0583-00
2 NUT,PLAIN,HEX :0 .25-32 X 0.312 INCH,BRS
73743
2X20317-402
-38 210-0046-00
3 WASHER,LOCK:0 .261 ID,INTL,0 .018 THK,BRS
78189
1214-05-00-0541C
""""""(END ATTACHING PARTS)""""'
-39 ----------
1 RESISTOR,VAR :(SEE R295 REPL)
""""*""'(ATTACHING PARTS)""""""
-40 210-0583-00
1 NUT,PLAIN,HEX :0 .25-32 X 0.312 INCH,BRS
73743 2X20317-402
-41 210-0046-00
1 WASHER,LOCK:0 .261 ID,INTL,0 .018 THK,BRS
78189
1214-05-00-0541C
""""""(END ATTACHING PARTS)""""'
-42
---------- 1 RESISTOR,VAR :(SEE R705 REPL)
-43 210-0046-00
1 WASHER,LOCK:0 .261 ID,INTL,0 .018 THK,BRS
78189 1214-05-00-0541C
