Summary of Contents for FAFCO CoolPV
- Page 1 ® FAFCO S o l a r E n e r g y P e r f e c t e d O W N E R ’ S M A N U A L FOR USE WITH SWIMMING POOLS...
- Page 2 Chico, CA Figure 1 ® CoolPV Panel Components Each CoolPV ® Panel consists of (left to right) a PV Module, a FAFCO Inc. Thermal Collector, and a support structure which ensures thermal connection between the Module and Collector. 2 ...
- Page 3 Panel attaches a ® FAFCO Inc. Thermal Collector to the back face of the PV module. Water flows through the hundreds of small diameter tubes constituting each Thermal Collec- tor, taking heat from the module, increasing the electrical performance of CoolPV by up to 10% higher than uncooled modules.
- Page 4 System Overview ® Fafco System Specifications ® 295W CoolPV Panel Specifications (CS6K-295MS, PN: 09883) Panel Area 17.6 ft (1.67 m Panel Dimensions (HxWxD) 65 x 39 x 4.72in (1650 x 992 x 120 mm) Weight 55.3 lbs (25.1 kg) Roof load 3.2 psf (15.6 kg/m...
- Page 5 ® Fafco Figure 2 ® Components of a Typical CoolPV System...
- Page 6 6 & 7. Your Pump and Filter For optimal performance a variable speed pump is preferred. Please contact your FAFCO Inc. dealer for more information. Keeping your skimmer and pump baskets clean enhance performance by ensuring the maximum flow of cooling water. When cleaning the filter the solar system should be isolated, preventing debris from entering the system.
- Page 7 Electrical Power: Check for shading of the panels and consider seasonal or other explanations. If the issue remains unresolved call your authorized FAFCO Inc. dealer. If Your Concern Relates To The Heating Of Your Pool: 1. Has your filter been backwashed and are the skimmer and the pump basket clean? 2.
- Page 8 All systems, when shut down for the winter, must be checked to ensure that they are completely drained. It is suggested to set up a winterization and spring tune-up schedule with your FAFCO Inc. Authorized Dealer. CoolPV Systems are not warranted against freeze damage.
- Page 9 Sys- ® tem. Keep this form in a safe location and be sure to send a copy to FAFCO, Inc. within 30 days of system installation date or system will not be eligible for installer incentive program credits. Home Owner...
- Page 10 3. The use of variable speed pumps is recommended to conserve energy. 4. Maintaining a high rate of water flow allows for rapid pool water turnover and proper regula- tion of pool chemistry. This keeps your pool clean and clear while making the CoolPV System ®...
