Installation Instructions for
SAVE THESE INSTRUCTIONS!

GENERAL INFORMATION

- RISK OF FIRE: This product must be installed by a
qualified electrician. Turn the power to the electrical box off
during installation. Read the "Important Safety Instructions "
before installation.
- NOTE: To avoid overheating the power supply, install it in a
ventilated remote location where air flows. Maintain proper
spacing among power supplies when multiple power
supplies are installed in the same remote location.
- This product is not suitable for wet locations. It is approved
for the use at any height above the finished floor.
- A typical installation is shown. Specific installation must be
in accordance with the local electrical codes.
- TO REDUCE RISK OF FIRE, it is important to wire the
power supply for the system as described in this
installation instruction.
- Load the power supply to MAXIMUM 30 Watts.
- Use Lightolier "ZP600FAM120" 0-10 volt controller to dim
the Warm White LED soft strip.
- Use CDP color dial or CTP color touch screen controller with
RGB LED soft strip.
POWER SUPPLY
WATTAGE
30 WATT
12 Volt
1718 W. Fullerton Ave
Chicago, IL 60614
Tel: 773-770-1195
Fax: 773-935-5613
www.edgelighting.com
info@edgelighting.com
30 Watt 12 Volt DC LED Power Supply

IMPORTANT SAFETY INSTRUCTIONS

LOW VOLTAGE WIRE SIZE CHART
WIRE SIZE
WIRE SIZE
UP TO 26 FT
FOR 27-41 FT
#14 GA
#12 GA
PSB-30-12VDC
- Do not install this power supply in a wet location.
- To reduce the risk of the system overheating and possibly
causing a fire, make sure all the connections are tight.
- Do not install *LED fixture closer than three inches or as
specified in the *LED fixture installation instructions to
curtains or similarly combustible materials. Keep insulation
at least 3" away from the enclosure.
- Turn the electrical power off before modifying the lighting
system in any way.
- The system is "ETL" listed for USA and Canada only when
all the products used are supplied by Edge Lighting.
* See LED fixture installation instructions for proper
placement.
WIRE SIZE
FOR 42-68 FT
#10 GA
904-PSB-30-12VDC-04
WIRE SIZE
FOR 69-100 FT
#8 GA
