SolStar T-55 Quick Connect Manual

Getting Started

Your T-55 Thrane 700 includes the following:
2.5 mm barrel plug to SAE plug
Closer View
2.5mm barrel plug
Connecting the SolStar T-55 Solar Charger to Thrane Explorer 700
Connect the 2.5mm barrel plug
side to the Thrane 700 DC
output.
*Hughes male cigarette lighter adapter must be purchased
Fold one side of the charger down
the hinge-fold, active solar cells to
the inside.
Then wrap the flap around until
both the hook and loop sides of
the Velcro are lined up.
Closer View
SAE plug

T-55 Quick Connect Guide

Connect the SAE plug side to
the SolStar T-55 solar charger.
Folding Instructions for the SolStar T-55 Solar Charger
Fold other side of the
charger down the second
hinge-fold, active solar cells
to the inside.
Lastly, press the Velcro
together to secure the fold
unit.
T-55 SolStar Solar Panel
Orient SolStar T-55 solar
charger directly towards the
sun for optimal charging.
Starting at the end away from the cable,
fold the charger along its hinge-folds.
www.solstarenergy.com
Phone: (1) 505-255-2499
Fax: (1) 505-243-6355
The Thrane 700 terminal will
automatically be powered on
and start charging.
T-55T700 Product Insert
