Summary of Contents for Gimenez Ganga Anti-wind PREMIUM 65 mosquito screen
- Page 1 PREMIUM ANTI-WIND MOSQUITO SCREEN ASSEMBLY MANUAL...
- Page 2 IMPORTANT: It is important for the safety of persons and the integrity of the product to read these instructions carefully before installing, operating, repairing or using the mosquito screen for the first time. This document is an integral part of the titled mos- "Mosquito screens: prescriptions for the user and installer"...
-
Page 3: Table Of Contents
TABLE OF CONTENTS COMPONENTS 1.1 PREMIUM ANTI-WIND MOSQUITO SCREEN CUTTING - MOTORIZED 1.2 PREMIUM ANTI-WIND MOSQUITO SCREEN CUTTING - MANUAL 1.3 PROFILES 1.4 ACCESSORIES MANUFACTURING DIMENSIONS 2.1 MAXIMUM/MINIMUM DIMENSIONS - MOTORIZED 2.2 MAXIMUM/MINIMUM DIMENSIONS - MANUAL CUTTING AND SELECTION TABLES 3.1 ALLOWANCES 3.2 FABRIC PRODUCTION MEASUREMENTS 3.3 NUMBER OF EQUALIZER SPRING TURNS... -
Page 4: Components
COMPONENTS PREMIUM ANTI-WIND MOSQUITO SCREEN CUTTING - MOTORIZED DESCRIPTION DESCRIPTION Box profile 65 100153 Set of 65mm box end caps 100157 Terminal 33.5x18 mm 100150 Motor Kit - Anti-wind Premium 65 100159 100152 Clipable Premium Lower Guide 502599 Motor Roll Up Wireless RTS Clipable Premium Upper Guide 100151 Mosquito Screen Spring 65 axle of 25 - Right... -
Page 5: Premium Anti-Wind Mosquito Screen Cutting - Manual
ASSEMBLY MANUAL PREMIUM ANTI-WIND MOSQUITO SCREEN 1.2 PREMIUM ANTI-WIND MOSQUITO SCREEN CUTTING - MANUAL DESCRIPTION DESCRIPTION Box profile 65 100153 Set of box end caps 65 100157 Terminal 33.5x18 mm 100150 Mechanism kit - Anti-wind Premium 65 100158 Clipable Premium Lower Guide 100152 Tilt chain mechanism- Axle 25 030405... -
Page 6: Profiles
1.3 PROFILES 65.80 AXLE Ø43.50 Box profile 65 Terminal 33.5x18 mm 100153 100150 33.40 01. Clipable Premium Lower Guide 100152 Rack and pinion guide 26x13.50 mm 024179 100151 02. Clipable Premium Upper Guide Brush Ref.: 38-550 Brush Ref.: 69-1000 026005 041068... -
Page 7: Accessories
ASSEMBLY MANUAL PREMIUM ANTI-WIND MOSQUITO SCREEN 1.4 ACCESSORIES Set of box end caps 65 Motor Kit - Anti-wind Premium 65 100157 100159 Set of Terminal Caps 33,5x18 Mechanism kit - Anti-wind Premium 65 100114 100158 Motor Roll Up RTS 503351 12V Ac/DC Transformer 503308 Mosquito screen spring 65 axis 25 - Right... -
Page 8: Manufacturing Dimensions
MANUFACTURING DIMENSIONS 2.1 MAXIMUM/MINIMUM DIMENSIONS - MOTORIZED MOSQUITO SCREEN MAXIMUM MINIMUM Width 2.00 m 0.80 m Width Motor radius High 2.40 m High 2.2 MAXIMUM/MINIMUM DIMENSIONS - MANUAL MOSQUITO SCREEN MAXIMUM MINIMUM Width 2.00 m Width 0.50 m High 2.40 m High CUTTING AND SELECTION TABLES IMPORTANT... -
Page 9: Fabric Production Measurements
ASSEMBLY MANUAL PREMIUM ANTI-WIND MOSQUITO SCREEN 3.2 FABRIC PRODUCTION MEASUREMENTS DIMENSIONS IMPORTANT For the cutting of the fabric it is necessary to take into account the measurement chart, according to High +150 the size of the box. Dimensions are always total Width without zipper and are expressed in mm. -
Page 10: Number Of Equalizer Spring Turns
3.3 NUMBER OF TENSION SPRING TURNS WIDTH / 1.00 1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00 HEIGHT (m) 1.00 1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00 2.10 2.20 2.30 2.40 ASSEMBLY INSTRUCTIONS 4.1 AXLE ASSEMBLY AND CONFIGURATION IMPORTANT Depending on the drive system, the axle must be configured differently. -
Page 11: Premium Anti-Wind Mosquito Screen Axle Configuration - Motorized
ASSEMBLY MANUAL PREMIUM ANTI-WIND MOSQUITO SCREEN 4.1.1 PREMIUM ANTI-WIND MOSQUITO SCREEN AXLE CONFIGURATION - MOTORIZED DESCRIPTION unit DESCRIPTION unit DESCRIPTION unit Motor Roll Up Wireless RTS Aluminium tube 45 Mosquito screen Spring 65 * Motor fixing screw * Spring wheel * Spring fixing screw * Drive wheel * The pieces with an asterisk are part of the article 100159 (Motor kit - Anti-wind premium 65). -
Page 12: Axle Assembly
4.1.3 AXLE ASSEMBLY STEP 1 Insert the fabric into the axle. STEP 2 Depending on the drive system, configuring the axle as indicated in section 4.1. STEP 3 Roll the screen onto the axle. -
Page 13: Terminal Assembly
ASSEMBLY MANUAL PREMIUM ANTI-WIND MOSQUITO SCREEN 4.2 TERMINAL ASSEMBLY STEP 1 Insert the screen and the brush (Ref. 69-1000) into the terminal. STEP 2 Join the plug set with the terminal. The screen stays be- tween the two parts of the stopper. Connect both parts using the DIN screw 7505 2,5x12 mm... -
Page 14: Box Assembly
4.3 BOX ASSEMBLY STEP 1 Insert the brush (Ref. 38-550) into the box profile. Brush (ref. 38-550) STEP 2 Insert the axle with the screen rolled up and the terminal that is fixed to the screen into the inside of the box profile. STEP 3 Insert the end plate pivot into the spring housing. - Page 15 ASSEMBLY MANUAL PREMIUM ANTI-WIND MOSQUITO SCREEN STEP 4 Finish the assembly of the drawer by coupling the opposite end piece to the one already installed and fix it with the screw.
-
Page 16: Installation Instructions
INSTALLATION INSTRUCTIONS STEP 1 Check the dimensions of the place where it is to be installed. X = Total width (mm) Y = Total height (mm) STEP 2 Check the dimensions of the product before installation. Check that they are correct. X = Total width (mm) Y = Total height (mm) - Page 17 ASSEMBLY MANUAL PREMIUM ANTI-WIND MOSQUITO SCREEN STEP 3 Join the box with the rear guides. Insert the end plating footing through the housing of the rear guide. STEP 4 Check that the product has been correctly levelled and squared in all positions.
- Page 18 STEP 5 Check that the product has been correctly levelled and squared in all directions. 90º 90º 90º STEP 6 Fix the system using the guides. Take the type of wall into account when choosing the fixing method.
-
Page 19: Wind Resistance (Une-En 13659:2004+A1:2008)
ASSEMBLY MANUAL PREMIUM ANTI-WIND MOSQUITO SCREEN STEP 7 Clip the two aluminium profiles that make up the guide. WIND RESISTANCE (UNE-EN 13659:2004+A1:2008) CLASSES Nominal test pressure (Pa) or (N/m <50 Pa 50 Pa 70 Pa 100 Pa 170 Pa 400 Pa 270 Pa Test safety pressure 1.5 (Pa) or (N/m <75 Pa... - Page 20 gimenezganga.com...
