Summary of Contents for Central Pneumatic 38898
- Page 12 ® AIR NAILER/STAPLER 2-IN-1 KIT Model 40115 ASSEMBLY and OPERATING INSTRUCTIONS ® 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our Web site at http://www.harborfreight.com ® Copyright 2002 by Harbor Freight Tools . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools.
-
Page 13: Specifications
Specifications Air Inlet 1/4”- 18 NPT Recommended Air Pressure 70 - 100 PSI Magazine Capacity Safety Feature Contact Safety Trip Mechanism Nail Size 18 Gauge, 1/4” - 1-1/4” Length Staple Size 1/4” Crown, 18 Gauge, 1/4” - 1-1/4” Accessories: Oil Dropper, 2 Wrenches, 1 Coupler Plug , Case Nails: 5/8”... - Page 14 Maintain tools with care. Keep tools clean for better and safer performance. Follow instructions for lubricating and changing accessories. Inspect tool cords and air hoses periodically and, if damaged, have them repaired by an authorized technician. The handles must be kept clean, dry, and free from oil and grease at all times. Disconnect air supply.
-
Page 15: Operation
Warning: The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be under- stood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator. Read and understand all of the instructions provided in the instruction manual of the air compressor being used. - Page 16 Operation (continued) Loading Nails or Staples 1. Depress the Click Lever (#49) and pull back on the Tail Cover (#53). 2. Insert the brad nails into the Magazine, letting the pointed end ride on the rail of Magazine A (#45). If loading staples, fit the crown of the staples so they fit over, and ride on the rail of the Magazine A (#45).
-
Page 17: Maintenance
Troubleshooting Warning! If you detect any air leaks, power loss, the Nailer/Stapler skips driving, drives too deep, or not deep enough, take the Nailer/Stapler to an authorized service technician for repair. Note: Have the following problems repaired by an authorized service technician. 1. -
Page 18: Parts List
Parts List Part No. Description Part No. Description Part No. Description Hex Bolt Seal Magazine B Cylinder Cap Unit Trigger Valve Head Pusher Unit Seal Comper Spring Holder 0-ring 0-ring Pusher Spring Compression Spring Valve Plunger (Low) Magazine A Gasket (Cylinder Cap) 26 0-ring 0-ring 0-ring... -
Page 19: Assembly Drawing
Assembly Drawing Page 8 SKU 40115...
Need help?
Do you have a question about the 38898 and is the answer not in the manual?
Questions and answers
What type oil
The manual does not specify a particular type of oil, but it recommends incorporating an oiler for best service. Therefore, use standard pneumatic tool oil compatible with air tools.
This answer is automatically generated
how di adjust the output pressure it is stuc at 30 psi
