Summary of Contents for Excelitas Technologies MVS-5770 Series
- Page 1 IR ILLUMINATOR MVS-5770 MACHINE VISION STROBE OPERATION MANUAL Excelitas Technologies Illumination, Inc 35 Congress St., Salem, MA 01970 USA Phone: (978)745-3200 FAX: (978)745-0894 Toll Free: (800)950-3441 in USA only http://www.excelitas.com Website 102761 UM0097 Rev E...
- Page 2 MVS-5770 MACHINE VISION STROBE OPERATION MANUAL WARNING! The MVS-5770 produces lethal voltages. Ensure that input power is disconnected and storage capacitors have been discharged before beginning any inspection or internal adjustment. WARNUNG! Das MVS-5770 erzeugt lebensgefährliche Spannungen. Es muss deshalb darauf geachtet werden, dass der ankommende Strom ausgeschaltet ist und die Ladekondensatoren entladen sind, bevor Kontrollen oder Regelungen am Gerät unternommen werden! ATTENTION!
-
Page 3: Table Of Contents
FIGURE 2. POWER SUPPLY INPUTS CONNECTIONS ..................6 FIGURE 3. FLASHEAD CABLE CONNECTIONS ....................7 FIGURE 4. FLASHEAD INSTALLATION ......................9 FIGURE 5. SIMPLIFIED SCHEMATIC, MVS-5770 SERIES ................12 TABLES TABLE 1. – OPTICAL _______________________________________________________________________ 4 TABLE 2. – ELECTRICAL ___________________________________________________________________ 4 TABLE 3. -
Page 4: Introduction
INTRODUCTION 1.1. DESCRIPTION The MVS-5770 series illuminators are high intensity, low flash rate, Xenon strobes for direct illumination. The system consist of a separate power supply and flashhead chassis. A standard two and one half meter (2½m) interconnecting cable is shipped pre-wired to the flashhead unit. System installation requires power supply and flashhead mounting, connecting the flashhead cable, suppling AC power, trigger and a control voltage signal. -
Page 5: Unpacking
MVS-5770 MACHINE VISION STROBE OPERATION MANUAL 1.2. UNPACKING If the condition of the outer packaging suggests mishandling has occurred, examine the 5770 Series strobe for any signs of breakage during shipment. The Xenon Flashlamp is particularly vulnerable to rough treatment during shipment. Although the utmost care is taken to preserve the integrity of this item, its fragile nature makes it susceptible to breakage if the container is mishandled in transit. -
Page 6: Specifications
MVS-5770 MACHINE VISION STROBE OPERATION MANUAL SPECIFICATIONS Table 1. – Optical MVS-5770 MVS-5770 Narrow Beam Wide Beam Maximum flash rate 1 Hz 1 Hz Optical output @ 1 meter 1.0 mJ/cm² max 0.4 mJ/cm² max Vertical Beam Spread 8 degrees 25 degrees Horizontal Beam Spread 75 degrees... -
Page 7: Installation
3.1. MOUNTING The MVS-5770 Series of strobes are designed for indoor or outdoor use. The power supply has four (4) mounting holes in the feet that must be secured to a suitable structure using four (4) ¼-20 threaded screws. It can be mounted in any orientation. -
Page 8: Operation
MVS-5770 MACHINE VISION STROBE OPERATION MANUAL OPERATION 4.1. CONNECTIONS Two terminal strips and a ground lug are used to make the required connections for system operation. They are located inside the power supply chassis. All input connections are made to TB1, and output connections to the Flash head are made to TB2. -
Page 9: Figure 3. Flashead Cable Connections
MVS-5770 MACHINE VISION STROBE OPERATION MANUAL Figure 2. Power Supply Input Connections Figure 3. Power Supply Input Connections 102761 UM0097 Rev E... -
Page 10: External Voltage Adjust
MVS-5770 MACHINE VISION STROBE OPERATION MANUAL EXTERNAL VOLTAGE ADJUST An external reference signal can be used to control the intensiy of the strobe. The 4 - 6.7VDC Voltage reference signal should be connected per Figure 2. The lamp voltage may be varied from 600 VDC to a maximum of 1000 VDC. x 150). -
Page 11: Maintenance
Field repairs and customer modifications are not authorized, and, if attempted, will void the warranty. Repairs must be made only by factory-trained personnel. 5.2. FLASHLAMP REPLACEMENT Replacement lamps are available directly from Excelitas Technologies Illumination, Inc. or our authorized distributors listed below. Order part number FXQG-1714-3.25. Salem, MA USA... - Page 12 MVS-5770 MACHINE VISION STROBE OPERATION MANUAL Disconnect line voltage from the unit. Wait 120 seconds to allow energy storage capacitors to discharge. Remove four captive access screws on the face of the Flashlamp Chassis. Slide the Flashlamp Chassis out to the stops. Verify capacitors are completely discharged by shorting across the lamp connections with an insulated shorting bar.
-
Page 13: Cleaning
MVS-5770 MACHINE VISION STROBE OPERATION MANUAL 5.3. CLEANING After disconnecting power from the unit, clean it with a mild, non-abrasive cleaner. Never immerse the unit in water or any other liquid. 5.4. REPACKING AND STORAGE If the 5770 Series strobe is to be stored for a prolonged period, shipped to another location, or returned to the factory for repair, it should be repacked in the original packaging material. -
Page 14: Figure 5. Simplified Schematic, Mvs-5770 Series
MVS-5770 MACHINE VISION STROBE OPERATION MANUAL Figure 5. Simplified Schematic, MVS-5770 Series 102761 UM0097 Rev E...
