Vertex Water Products PWC-9500 Owners & Installation Manual

Purewatercooler, purechill water dispenser

Advertisement

Quick Links

PureWaterCooler
PureChill Water Dispenser
OWNERS INSTALLATION
OWNERS INSTALLATION
OWNERS INSTALLATION
OWNERS INSTALLATION
MANUAL
MANUAL
MANUAL
MANUAL
PWC-9500

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PWC-9500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vertex Water Products PWC-9500

  • Page 1 PureWaterCooler PureChill Water Dispenser OWNERS INSTALLATION OWNERS INSTALLATION OWNERS INSTALLATION OWNERS INSTALLATION MANUAL MANUAL MANUAL MANUAL PWC-9500...
  • Page 2: Table Of Contents

    9.0 Trouble Shooting Guide 9.0 Specifications 10 Warranty List of Figures Fig. 1 Flow Schematic Fig. 2 PWC-9500 Assembly Fig. 3 Back View of Cooler Fig. 4a-b Installation Precaution Fig. 5 Saddle Valve Fig. 6 Quick Connect Fittings Fig. 7 Hot/Cold Power switches Fig.
  • Page 3: Introduction

    The Vertex PureWaterCooler™ products are a means to produce good-tasting, safe water without using bottles of stored water. The PureChill model PWC-9500 described here is made for floor-standing use. Please read all the instructions in this manual before operating the PureWater- Cooler™.
  • Page 4: Product Description

    3.0 Description 3.1 Assembly The countertop portion of the PWC-9500 assembly drawing is shown in Figure 1. The cooler has one chilling chamber and one hot tank. This chilling chamber holds one gallon of water and is automatically filled at start-up. This water is cooled in the chilling chamber with refrigerant coils.
  • Page 5: Fig. 2 Pwc-9500 Assembly

    Screws Top Assembly Base cabinet Assembly Figure 2 PWC-9500 Assembly...
  • Page 6: Fig. 3 Back View Of Cooler

    3.2 Rear View On the back of the cooler are the main power switches; one for heat- ing and one for cooling. When heating or cooling is occurring, indicator lights on the front panel will turn on. The hot temperature is fixed at a nominal 180°F and is controlled with a thermostat mounted on the outside of the hot tank.
  • Page 7: Installation

    4.0 Installation 4.1 Assembly of Countertop to Cabinet Identify the four depressions on the top of the base cabinet where the four feet of the cooler will locate. Lift the cooler and placed it on top of the cabi- net, aligning the feet of the cooler to the previously located depressions. 4.2 Positioning the Cooler There are some precautions to take when positioning and using the PureWaterCooler™.
  • Page 8 Do not place cooler next to Be sure to use correct power oven or dishwasher. Keep voltage. Plug power cord out of direct sunlight. directly into electrical socket. Figure 4b Installation Precautions 4.3 Cooler Water Connections When received, the water connections on the back of both the cooler and the cabinet have color coded tube sections with red shipping caps on them.
  • Page 9: Fig. 5 Saddle Valve

    4.4 Feed Water Connections To connect the feed water, use the supplied self-piercing saddle valve to con- nect to the cold water supply line under the sink. Attach the 1/4” tubing to the compres- sion fitting on the side of the valve. Clamp the saddle valve over the copper or plastic feed line (cold water only).
  • Page 10: Fig. 6 Quick Connect Fittings

    4.5 Quick Connect Fittings The standard tubing connections on the PureWaterCooler™ are of Quick Connect O-ring seal design and manufacture. Use the tubing and follow the instructions below to make the connections. If you cut the tubing make sure it is a square cut, fits squarely in the fitting, and seals properly. Figure 6 Quick Connect Fittings...
  • Page 11: Operation

    5.0 Operation 5.1 Start Up a. Connect feed water line and all tubing according to instructions. If cabinet does not have filtration system installed, skip to step e. Open door of cabi- net to expose filtration system. Turn the water on at the piercing valve or feed water valve.
  • Page 12: Fig. 8 Control Panel

    System Flush: It is recommended to flush both the cold and hot systems by dispensing 16-32 ounces of water out of each at Initial start-up. First press and hold the cold dispense button until 16-32 oz have been dispensed. Then press hot lock until beep and then press and hold hot dispense button until 16- 32 oz of water have been dispensed.
  • Page 13: Filter Monitor

    5.2 Tank Drain Occasionally, it may be desirable to drain both tanks, the hot tank and chilling chamber. There are drain plugs on the back of the cooler. See Figure 8. First, make sure all power is off. The cooler must be moved so that the wa- ter can be drained into a container to collect the water (about 1 1/4 gal).
  • Page 14: Filter Replacement

    7.0 Filter Replacement The filter elements must be replaced at regular intervals to maintain the quality of the water. The “F” Model 9500F has 2-stages of mechanical filtration, the “R” model 9500R has 2-stages of mechanical filtration plus additional RO membrane. The fil- ters are accessed through the lower front door panel.
  • Page 15: Leak Detection

    8.0 Leak Detection System There are 2 leak detection systems installed in the cooler, one is me- chanical, mounted in the lower cabinet in the rear of the filter compartment ; the other is electronic and mounted on the LHS rear of dispensing unit. (see diag.11) If water leaks to the base of the cooler cabinet, the mechanical leak detector valve will close and shut off the feed water to the filters and the cooler.
  • Page 16: Fig. 11 Leak Detection Probes

    8.1 Electronic Leak Detection system The electronic water leak detection system is installed in the rear left had corner of the cooler. If a water leak should occur inside the cooler and wa- ter collects in the leak probe tray the power will automatically be shut off. When power is cut off due to water leak: a.
  • Page 17: Trouble Shooting Guide

    9.0 Trouble Shooting Guide Problem Cause Solution Check that power cord is plugged • Panel Not Lit No Power Confirm that no water is at leak • probes. Controls Not Set Turn on cold power switch on back • Will Not Cool Thermostat in rear •...
  • Page 18: Specifications

    8.0 Specifications S516 Model No. PWC-9500 Voltage/Frequency AC110V Dimensions 13"W x 16"D x 51.5"H (L) 16 x (W) 13 x (H) 16 1/2 81 lb. Weight (empty) 42 lb. .5 gal. Hot Water Tank Capacity .25 gal. Cold Water tank Capacity 1.0 gal.
  • Page 19: Warranty

    LIMITED WARRANTY Vertex Water Products (“Manufacturer”) sell its products through independent retailer dealers (“Dealer”) who re-sell to the end-user customer. In this limited warranty, “Vertex” refers to Vertex Water Products and not to the Dealer. WHO IS COVERED BY THIS WARRANTY This limited warranty covers only the first purchaser of the Vertex PureWaterCooler™...
  • Page 20 SHALL INCLUDE, BUT NOT BE LIMITED TO, LOSS OF ANTICIPATED PROFITS, BUSINESS INTERRUPTION, LOSS OF USE OR REVENUE, COST OF CAPITAL, OR LOSS OR DAMAGE TO PROPERTY OR EQUIPMENT. Contact information: Vertex Water Products 5138 Brooks Street Montclair, California 91763 800-627-2146 www.vertexwater.com email: inquiries@vertexwater.com...
  • Page 21 PWCM-6 08/15 Copyright 2009 VERTEX INDUSTRIALS, INC.
