Summary of Contents for Milestone CHIEF PAC780
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Height Assist Accessory Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description PAC780/782/784...
-
Page 2: Important Warnings And Cautions
The information contained in this document is subject to change without notice or obligation of any kind. Milestone WARNING: Exceeding the weight capacity can result in makes no representation of warranty, expressed or implied, serious personal injury or damage to equipment! It is the regarding the information contained herein. -
Page 3: Installation Instructions
Installation Instructions PAC780/782/784 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación Perforar... -
Page 4: Tools Required For Installation
PAC780/782/784 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 3/16" 1/2" (12.7mm) PARTS B (1) [Gas spring mount for stand] A (1) [72" lift assist gas spring assembly] C (4) 5/16-18 x 1"... -
Page 5: Assembly And Installation
Installation Instructions PAC780/782/784 ASSEMBLY AND INSTALLATION Install Gas Spring Assembly to Cart/Stand Remove any mounted displays and mounting devices from cart/stand. column Remove four button head screws from faceplate. (See Figure 1) Remove faceplate from column assembly. (See Figure 1) (MFC cart shown) (MF1 stand shown) Remove... - Page 6 PAC780/782/784 Installation Instructions Installing to Cart (columns shown as transparent) Remove and save end plate from end of gas spring assembly (A) by turning plate counterclockwise. (See Figure 4) Inner column Plate Top of outer column Figure 6 Replace plate removed in Step 1 to the end of gas spring assembly (A).
- Page 7 Installation Instructions PAC780/782/784 Remove four button head screws from bracket at end of inner column. (See Figure 9) Bottom of stand column Bracket at bottom of inner column Center plate Figure 11 (columns shown as transparent) Completing Installation to Cart/Stand Figure 9 Place plate on gas spring mount for stand (B) [or plate on gas spring assembly (A) for cart] at top of upper cart/stand...
- Page 8 PAC780/782/784 Installation Instructions Reattach faceplate on top of gas spring assembly plate. IMPORTANT ! : When attaching faceplate ensure that the ClickConnect lock is at TOP of head assembly, and bracket tabs slide into the cart/stand assembly. (See Figure 13) (C) x 4 ClickConnect lock...
-
Page 9: Height Adjustment
Installation Instructions PAC780/782/784 Tighten knob on back of column to secure pin into corresponding notch at desired height. Mount display onto cart/stand according to cart/stand installation instructions. Height Adjustment NOTE: Height should be adjusted with the weight of the display or equipment mounted on the cart/stand. - Page 10 PAC780/782/784 Installation Instructions...
- Page 11 Installation Instructions PAC780/782/784...
- Page 12 A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street Fotan, Shatin, Hong Kong 8807-002018 Rev00 P 852 2145 4099 2010 Milestone AV Technologies, a F 852 2145 4477 Duchossois Group Company www.chiefmfg.com 07/10...
