Chapter MAN - Cover front.indd- PRINTFILE CREATED ON: 20190620 16:56 - DESIGN: SEEB - UPDATES BY: WILLY
SMART CAMERA / DOORBELL
SLIMME CAMERA/DEURBEL
SMART KAMERA / TÜRKLINGEL
ART.NR.: 140110
0110-MAN-ML-2019061701-SHA-A6.indb 1
25/06/2019 14:0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 140110 and is the answer not in the manual?

Questions and answers

Summary of Contents for idinio 140110

  • Page 1 Chapter MAN - Cover front.indd- PRINTFILE CREATED ON: 20190620 16:56 - DESIGN: SEEB - UPDATES BY: WILLY SMART CAMERA / DOORBELL SLIMME CAMERA/DEURBEL SMART KAMERA / TÜRKLINGEL ART.NR.: 140110 0110-MAN-ML-2019061701-SHA-A6.indb 1 25/06/2019 14:0...
  • Page 2 4.Fixed bracket 5.Install the doorbell into the bracket Fig. 1 Camera External power port Microphone Status Light Button Reset Speaker SD card slot Mini USB Power Port: AC 8V~24V Doorbell button: Press the button to activate the doorbell Status light: ∙...
  • Page 3 Functions Shared device The doorbell device can be shared with friends, and friends can also preview online. There is no limit to the number of sharing devices, but only 6 accounts are supported for online preview at the same time. Full-duplex audio When the visitor push the doorbell button, you will get a call.
  • Page 4 Box contents A x 2 B x 2 C x 3 Electrical safety ∙ To reduce risk of electric shock, this product should only be opened by an authorized technician when service is required. ∙ Do not use the product if the cable or plug is damaged or defective. When damaged or defective, it must be replaced by the manufacturer or an authorised repair agent.
  • Page 5 B x 2 Use of the product / Installation C x 3 1. Download and install the “Idinio“ app from the Apple App Store or Google Play C x 3 Store on your mobile device. 2. Activate the “Idinio“ app.
  • Page 6 Connect the external USB bell with the Smart doorbell 1. Connect the USB bell with an adapter (5V 1A output). Briefly press the RESET button to pair the doorbell. - Blue light blinking: Awaiting for configuration. - Blue light solid on: Configuration completed. (To restore to factory settings: press and hold the RESET button for 5s) 2.
  • Page 7 Connect the external USB bell with the Smart doorbell 3. Go to Call settings. 4. Change the call settings to “Wireless call” 0110-MAN-ML-2019061701-SHA-A6.indb 7 25/06/2019 14:0...
  • Page 8 Connect the external USB bell with the Smart doorbell 4. Change the call settings to “Wireless call” 0110-MAN-ML-2019061701-SHA-A6.indb 8 25/06/2019 14:0...
  • Page 9 Connect the external USB bell with the Smart doorbell 6. Change the sound of the USB bell in „Ring Tone Settings“ - Press “remove binding” in the set ring tone menu - Press add again and try the bell again 0110-MAN-ML-2019061701-SHA-A6.indb 9 25/06/2019 14:0...
  • Page 10 Connect the external USB bell with the Smart doorbell 7. To select one-way or two-way speech please go to the Basic function settings. NOTE: With one-way audio you cannot talk back. With two-way audio you can. 0110-MAN-ML-2019061701-SHA-A6.indb 10 25/06/2019 14:0...
  • Page 11 Connect the external USB bell with the Smart doorbell 8. To communicate between doorbell and phone you must ensure that the speaker icon is turned on. To talk back, you have to hold the microphone button until it turns blue. When the icon is blue you can start talking. As long as the microphone icon is blue you can talk.
  • Page 12 APP STORE PLAY STORE LET’S MEET ONLINE For installation and instructions with Google Assistant and Amazon Alexa scan the QR code or go to: www.shada.nl/idinio 0110-MAN-ML-2019061701-SHA-A6.indb 12 25/06/2019 14:0...
