STRAXGAS Theme Plus Supplementary Installation And Servicing Instructions

SUPPLEMENTARY INSTALLATION AND SERVICING
INSTRUCTIONS FOR THE STRAXGAS THEME GAS FIRES
Important: These instructions are to be read in conjunction with the installation
and service instructions for the appropriate Straxgas Theme gas fire.

Amended appliance data

For Natural Gas (G20) Cat. I
Injector size
Gross heat input (high)
Gross heat input (low)
Supply pressure
Appliance test pressure on inlet
Ignition
For Propane Gas (G31) Cat. I
Injector size
Gross heat input (high)
Gross heat input (low)
Supply pressure
Appliance test pressure on inlet
Ignition

Before Installation

1. Remove gas assembly from convector box.
2. Undo nut on pivot arm and rotate linkage to right hand side. Temporarily refit nut to
avoid loosing it.
3. Remove screws from legs of burner and slide out burner assembly.
4. Refer to installation instructions to fit convector box.

Refit Burner Assembly

1. Place assembly into base of convector box and refit mounting screws through burner
legs.
2. Refit pivot linkage (ensure two washers are fitted under the pivot arm and the locknut
is loosely tightened).
3. Check operation of linkage and if it is not operating freely slacken the locknut on the
pivot arm.
4. Fit 1.5v AA battery supplied into battery holder in centre of burner ensuring the polarity
markings on the battery corresponds with the markings on the battery holder.
5. Check the spark generator clicks when the control linkage is depressed downwards.
6. Refer to installation instructions to continue installation.
Theme Slider Valve Supplement Issue 1.3 09/07/01
Division of Legge Fabheat Ltd.
Longfield Road, Leamington Spa, Warks. CV31 1XB
Tel. (01926) 882233 Fax. (01926) 450846 Email: info@straxgas.co.uk
Registered in England No 500091
WITH ALTERNATIVE SLIDE CONTROL
(To be left with the appliance)
2H
Theme Plus
80
6.9kW
4.4kW
20mbar
19mbar
1.5v AA battery operated spark generator
3P
Theme Plus
53
6.9kW
3.5kW
37mbar
36.5mbar
1.5v AA battery operated spark generator
Theme 18"
86
7.6kW
4.4kW
20mbar
19mbar
Theme 18"
56
7.6kW
3.5kW
37mbar
36.5mbar
Theme 22"
2 x 80
10.2kW
4.4kW
20mbar
19mbar
Theme 22"
62
10.0kW
3.5kW
37mbar
36.5mbar
Page 1 of 2
