Fisher DE39 Operating Manual

Digital differential pressure transmitter with internal pressure sensors

Advertisement

Quick Links

d e v e l o p i n g
s o l u t i o n s
Operating Manual
DE39
Digital differential pressure transmitter
With internal pressure sensors

Table of contents

1
2
3
4
5
6
7
8
9
1
Safety Instructions
1.1
General
This operating manual contains instruc-
tions fundamental to the installation,
operation and maintenance of the de-
vice that must be observed uncondi-
tionally. It must be read by the assembler, operator
and the specialized personnel in charge of the de-
vice before it is installed and put into operation.
This operating manual is part of the product and
must be kept close by where it is easily accessible
to the responsible specialized personnel.
The subsequent sections, in particular the instruc-
tions on assembly, commissioning and mainte-
nance, contain important safety instructions, non-
observance of which can endanger persons, ani-
mals, the environment and physical objects.
1.2
Personnel Qualification
The device may only be installed and commis-
sioned by specialized personnel familiar with the in-
stallation, commissioning and operation of this
product.
Specialized personnel are persons who can assess
the work they have been assigned and recognize
potential dangers by virtue of their specialized train-
ing, their skills and experience and their knowledge
of the relevant standards.
1.3
Risks due to Non-Observance of Safe-
ty Instructions
Non-observance of these safety instructions, the in-
tended use of the device or the limit values given in
the technical specifications can be hazardous or
cause harm to persons, the environment or the sys-
tem itself.
The manufacturer will not be liable for damage
claims if this should happen.
1.4
Safety Instructions for the Operating
Company and the Operator
The safety instructions on correct operation of the
device must be observed. The operating company
must make them available to the installation,
maintenance, inspection and operating personnel.
Dangers arising from electrical components, energy
discharged by the medium, escaping medium and
incorrect installation of the device must be eliminat-
ed. For more information, please see the applicable
national and international regulations.
In Germany these are the DIN, EN, accident pre-
vention regulations (UVV) and - for industry-specific
individual applications - also in the industry guide-
lines issued by the DVWG, Ex, GL, etc. as well as
VDE and local EVUs.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DE39 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fisher DE39

  • Page 1: Table Of Contents

    Operating Manual DE39 Digital differential pressure transmitter With internal pressure sensors Table of contents Safety Instructions Application Purpose Description of the Product and Functional Description...
  • Page 2: Application Purpose

    Unauthorised Modification Description of the Product and Func- Modifications of or other technical alterations to the tional Description device by the customer are not permitted. This also Function Diagram applies to replacement parts. Any modifications / al- terations required must be carried out by Fischer Mess- und Regeltechnik GmbH only.
  • Page 3: Commissioning

    Display • Add a fuse adapted to the energy requirements. 4.2.1 3 wire connection / -Sig +Sig Supply DE39 Output 0/4…20 mA 0…10V 4.2.2 Socket assignment Designation Display function Status display of the switching outputs Measured Value Display...
  • Page 4 5.3.2 Display setting Reduce value û Enter key In DE39 the differential pressure is calculated by subtracting two relative pressures P1 and P2. In þ Page up menu Increase value some cases it is helpful if these values can be viewed separately.
  • Page 5: Bar

    display, output signal and switching points, not on Example: the load cell itself. This parameter can be used to The following applies for a basic measuring range set the response time to pressure jumps. The value  0,6 bar. of 0…6 bar : –...
  • Page 6 The table comprises 3…30 value pairs. For devices The parameter allows you to select between the following variants: with a power output, the first value pair is {I02|P02} The first value defines the level of the output signal. The second value determines the pres- linear characteristic curve (standard) sure at which the output signal is issued.
  • Page 7 Note: reverses the function of the switch output. If the Depending on the device model, individ- value = 1, the switch output works as an NO con- ual parameters may not be available if tact, if the value = 2, the switch output works as an the device does not have this feature.
  • Page 8: Maintenance And Repeat Tests

    Maintenance and Repeat Tests Measuring range unit Value range 1,2,3 The instrument is maintenance-free. We recom- The selection is backlit on the right next mend the following regular inspection to guarantee to the display. Not all basic measuring reliable operation and a long service life: ranges allow random switchover.
  • Page 9: Technical Data

    11 Technical data 0… bar Basic measuring range Static operating pressure max. bar Bursting pressure 100 100 max. %FS < 2.5 Characteristic curve de- viation* typ. %FS < 1.0 max. %FS/10K < 0.3 Tk span°°) typ. %FS/10K < 0.1 max. %FS/10K <...
  • Page 10: Dimensional Drawings

    11.1 Programming Via membrane keypad with menu-controlled operation or transmitter PC Interface EU03 (accessories), can be locked with a password Setting parameters Offset Nulling of the input differential pressure P1, P2, ΔP Pressure display Attenuation 0,0...100,0s (jump response time 10/90%) for signal output, separate also for display Switching output ...
  • Page 11: Order Codes

    13 Order Codes Digital differential pressure transmitter, with 3 ½-digit LED display DE39 Measuring ranges 0… 6 bar ..............> 0 0…10 bar ..............> 0 0…16 bar ..............> 0 0…25 bar ..............> 0 0…40 bar ..............> 1 Design of the measuring system Chromium nickel steel 1.4404 ..........
  • Page 12: Manufacturer's Declarations And Certificates
