Installation (suite)
Tableau de dépannage
2. Lorsque les thermostats sont connectés à
Symptôme
un dispositif ou à un système de chauffage :
Refroidissement :
Tourner le bouton dans le sens horaire
Le ventilateur ou le
au-dessus de la température ambiante,
refroidissement ne
l'appareil de chauffage doit s'allumer.
fonctionne pas
Lorsque le bouton est tourné dans le sens
Le refroidissement ou le
antihoraire (à un réglage de température
inférieure), l'appareil de chauffage doit
ventilateur fonctionne
continuellement
s'arrêter aux environs du réglage du bouton.
3. Thermostat à commutateur SPDT/SPDT à
Le système fonctionne
à l'inverse
deux étages : Si la connexion ressemble
à celle de la Figure 4, le ventilateur doit
démarrer vers la température ambiante et
Chauffage :
passer à la haute vitesse lorsque le bouton
L'appareil de chauffage
est tourné dans le sens antihoraire à un
ne fonctionne pas
réglage de température inférieure. Si le
câblage ressemble à celui de la Figure 5, le
L'appareil de chauffage
registre doit s'ouvrir alors que le bouton est
fonctionne continuellement
tourné dans le sens antihoraire (à un réglage
de température inférieure). Les dispositifs
Le système fonctionne
doivent s'activer dans la séquence inverse
à l'inverse
lorsque le bouton est tourné dans le
sens horaire.
GARANTIE LIMITÉE
Les modèles équipés de boîtiers NEMA 1
GARANTIE LIMITÉE D'UN AN FOURNIE PAR TEMPRO. LES MODÈLES DE THERMOSTATS DE TENSION DE
sont réglés en usine pour le réglage maximal
LIGNE DE TEMPRO
de l'échelle de température. Le réglage de
CONTRE TOUT DÉFAUT DE FABRICATION OU DE MATÉRIAU DANS DES CONDITIONS D'UTILISATION NORMALES
température maximale peut être abaissé en
DURANT UN AN À COMPTER DE LA DATE D'ACHAT. TOUTE PIÈCE PRÉSENTANT, SELON TEMPRO, DES DÉFAUTS
enlevant le couvercle, en desserrant légèrement
DE FABRICATION OU DE MATÉRIAU ET RETOURNÉE À UN CENTRE DE SERVICE AGRÉÉ DÉSIGNÉ PAR TEMPRO,
la vis de réglage adjacente au bouton de
PORT PAYÉ, SERA RÉPARÉE OU REMPLACÉE AU CHOIX DE TEMPRO, À TITRE DE RECOURS EXCLUSIF. VOIR LES
PROCÉDURES DE RÉCLAMATIONS SOUS GARANTIE SOUS LA RUBRIQUE « PROMPT RÈGLEMENT », CI-APRÈS. LA
réglage, et en déplaçant la vis de réglage
PRÉSENTE GARANTIE DONNE AUX ACHETEURS DES DROITS SPÉCIFIQUES QUI VARIENT SELON LES JURIDICTIONS.
le long de la fente jusqu'à la température
maximale désirée. Resserrer ensuite la vis de
LIMITES DE RESPONSABILITÉ. DANS LA MESURE PERMISE AU TITRE DE LA LOI APPLICABLE, TEMPRO
DÉCLINE EXPRESSÉMENT TOUTE RESPONSABILITÉ POUR TOUT DOMMAGE ACCESSOIRE ET INDIRECT. LA
réglage et remettre le couvercle en place.
RESPONSABILITÉ DE TEMPRO EST DANS TOUS LES CAS LIMITÉE ET NE SAURAIT DÉPASSER LE PRIX D'ACHAT.
Fonctionnement
CLAUSE D'EXONÉRATION DE GARANTIE. TEMPRO S'EST DILIGEMMENT EFFORCÉE D'ILLUSTRER ET DE
La Figure 8, page 3 illustre le fonctionnement
DÉCRIRE DE MANIÈRE EXACTE LES PRODUITS DE CETTE BROCHURE. CEPENDANT, CES ILLUSTRATIONS ET CES
des thermostats à commutateur SPDT/SPDT
DESCRIPTIONS NE SONTDONNÉES QU'À TITRE D'IDENTIFICATION ET NE GARANTISSENT PAS EXPRESSÉMENT OU
à deux étages. Lorsque la température est
IMPLICITEMENT QUE LES PRODUITS SONT DE QUALITÉ MARCHANDE OU ADAPTÉS À UN USAGE PARTICULIER,
augmentée à partir du réglage du bouton,
OU QU'ILS SERONT NÉCESSAIREMENT CONFORMES AUX ILLUSTRATIONS OU AUX DESCRIPTIONS FOURNIES.
le circuit entre R et Y du contacteur bas
SAUF DISPOSITIONS CONTRAIRES CI-DESSOUS, AUCUNE GARANTIE OU AFFIRMATION DE FAIT, EXPRESSE OU
IMPLICITE, AUTRE QUE CELLE ÉNONCÉE À LA RUBRIQUE « GARANTIE LIMITÉE » CI-DESSUS, N'EST FOURNIE
étage (RYL) se referme. Au même moment,
OU AUTORISÉE PAR TEMPRO.
le circuit entre R et B (RBL) s'ouvre.
Conseils et recommandations techniques; clause d'exonération. Nonobstant toute pratique ou action
Suite à une plus grande augmentation de
commerciale ayant eu cours dans le passé ou toute coutume du secteur d'activité, les ventes n'incluront pas la
température, le contacteur de l'étage supérieur
fourniture de conseils en matière de conception de système ou de résolution de problèmes techniques. Tempro
fonctionne et se ferme (RYH) tout en ouvrant
n'assume aucune obligation ni responsabilité en ce qui concerne les recommandations, opinions ou conseils
simultanément (RBH). La séquence inverse
non autorisés relatifs au choix, à l'installation ou à l'utilisation des produits.
a lieu lors d'une baisse de température.
Adéquation du produit. Dans de nombreuses juridictions, les codes et les réglementations qui régissent
REMARQUE : Aucune pièce de rechange
les ventes, la construction, l'installation et/ou l'utilisation de produits pour certains usages peuvent être
disponible. Ne pas tenter de réparer sur place.
différents de ceux de régions avoisinantes. Bien que Tempro se soit efforcée de rendre ses produits conformes
à ces codes, la société ne peut en garantir la conformité et ne saurait être responsable de la manière dont
les produits sont installés ou utilisés. Avant d'acheter et d'utiliser un produit, il est conseillé d'étudier son
application ainsi que les codes et réglementations nationaux et locaux, et de s'assurer de la conformité
à ces codes de ces produits, de leur installation et de leur utilisation.
Certains aspects des dénis de garantie ne sont pas applicables aux produits de consommation; par exemple
(a) certaines juridictions n'autorisent pas l'exclusion ou la limitation des dommages accessoires ou indirects, de
sorte que la limitation ou l'exclusion susmentionnée peut ne pas s'appliquer à votre cas; (b) en outre, certaines
juridictions n'autorisent pas de limite sur la durée d'une garantie implicite, par conséquent la limite susmentionnée
peut ne pas s'appliquer à votre cas; et (c) en vertu de la loi, durant la période de garantie limitée, toute garantie
implicite de qualité marchande ou d'adéquation à un usage particulier applicable aux produits de consommation
achetés par des consommateurs, est susceptible de ne pas pouvoir être exclue ou autrement déniée.
Prompt règlement. Tempro s'efforcera en toute bonne foi de faire les rectifications ou autres ajustements
prévus pour tout produit qui s'avère défectueux durant la période de garantie limitée. Pour tout produit jugé
défectueux durant la période de garantie limitée, contacter tout d'abord le concessionnaire où l'appareil a
été acheté. Le concessionnaire fournira des instructions supplémentaires. S'il est impossible de résoudre le
problème de façon satisfaisante, écrire à Tempro à l'adresse ci-dessous, en indiquant le nom et l'adresse du
concessionnaire, la date et le numéro de la facture du concessionnaire, ainsi que la nature du défaut constaté.
Le titre et le risque de perte passent à l'acheteur au moment de la livraison par le transporteur. Si le produit
a été endommagé pendant le transport, une réclamation doit être faite auprès du transporteur.
Tempro Brand, Kamal International LLC
www.temproducts.com
537 E. 10th Ave.
847-594-0250
Bowling Green, KY 42101
Cause(s) possible(s)
Action corrective
1. Câblage incorrect
1. Vérifier le câblage
2. Bouton réglé au-dessus de la
2. Régler le bouton à une
température ambiante
température inférieure
1. Câblage incorrect
1. Vérifier le câblage
2. Bouton réglé au-dessous de la
2. Régler le bouton à une
température ambiante
température supérieure
Câblage incorrect
Vérifier le câblage
1. Câblage incorrect
1. Vérifier le câblage
2. Bouton réglé au-dessous de la
2. Régler le bouton à une
température ambiante
température supérieure
1. Câblage incorrect
1. Vérifier le câblage
2. Bouton réglé au-dessus de la
2. Régler le bouton à une
température ambiante
température inférieure
Câblage incorrect
Vérifier le câblage
COUVERTS DANS CE MANUEL SONT GARANTIS PAR TEMPRO AU PREMIER UTILISATEUR
TP500 à TP525
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect
yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage!
Retain instructions for future reference.
Tempro
Thermostats
Description
These Line Voltage Thermostats are designed for reliable use in heating, ventilating,
and refrigeration applications. A variety of models offer a broad temperature range
between -30° and +120°F (-34° and +49°C) allowing for a wide range of heating,
ventilating, and refrigeration applications.
Models with metal enclosures are NEMA 1 and must be mounted in a dry environment
where they will not be exposed to rain or water spray. Models made with high strength
plastic enclosures are NEMA 4X rated, and may be mounted indoors or outdoors. These
models are protected from rain and may be washed down with a hose but must not be
exposed to standing water or be submerged. Models rated in accordance with NEC547
are suitable for use in agricultural buildings.
Model numbers and electrical ratings are found on the rating plate attached to
the thermostat.
Tempro Products is committed to significantly reducing and diverting waste. We
encourage owners of our controls to responsibly recycle their equipment when
it is no longer needed.
See the full range of Tempro Products @ http://www.temproducts.com.

General Safety Information

Disconnect all power
before installing or
servicing this product. If the power
disconnect is out of view, lock it in the
open position and tag it to prevent
unexpected restarting of power. Failure to
do so could result in fatal electric shock.
1. Special attention must be given to any
grounding information on this product
and to other equipment associated with
its installation and use. To ensure a
proper ground, the grounding means
must be checked by a qualified
electrician.
2. Be certain that the electrical ratings of
the thermostat conform to the power
source and the load(s) being controlled.
Loads that exceed the rating of the
thermostat should be handled with a
suitable rated relay or motor starter.
Do not depend upon
the thermostat as the
sole means of disconnecting power when
installing or servicing the product it is
controlling. Always disconnect power
at the main circuit breaker as described
above. Failure to do so could result
in fatal electric shock.
Form PN10120 3/18/2015
©Kamal International
Bowling Green, KY 42101
