Summary of Contents for Themis XV1 Series

  • Page 1 User User Manual Manual Intel Quad-Core Xeon CPU / Up to 2.13 GHz / 6RU VME64 Platform 1/2/3 PMC Slots / 1-Gigabit Ethernet / SATA II / SVGA / USB / IDE / Floppy / Audio...
  • Page 3 XV1 Hardware Manual Version 1.0—June 2009 Themis Computer—Americas and Pacific Rim Themis Computer—Rest of World 47200 Bayside Parkway 5 Rue Irene Joliot-Curie Fremont, CA 94538 38320 Eybens, France Phone (510) 252-0870 Phone +33 476 14 77 80 Fax (510) 490-5529 Fax +33 476 14 77 89 World Wide Web http://www.themis.com...
  • Page 4 Themis Computer assumes no responsibility for inaccuracies. Themis Computer retains the right to make changes to this publication at any time without prior notice. Themis Computer does not assume any liability arising from the application or use of this publication or the product(s) described herein.
  • Page 5 XV1 Hardware Manual Version Revision History Version 1.0 ....................June 2009 Themis Computer...
  • Page 6 XV1 Hardware Manual Themis Computer...

  • Page 7: Table Of Contents

    1.7 TOD/NVRAM Battery ..................1-8 2. XV1 Features and Specifications ................. 2-1 2.1 Baseboard ....................... 2-1 2.2 PMC/XMC Cards ....................2-4 2.3 Paddle Board ......................2-4 2.4 PMC/XMC Carrier Boards ................... 2-5 2.5 I/O-Expansion Board ..................... 2-5 2.6 System Specifications .................... 2-6 Themis Computer...
  • Page 8 A.2.2.2 SATA3 Port ................A-7 A.2.2.3 USB Ports USB0 & USB1 ............A-8 A.2.2.4 VGA Graphics Port ..............A-8 A.3 Push-Button RESET ..................... A-8 A.4 XV1 PMC Module Card Connectors ..............A-8 A.4.1 PMC Module Connector J21 / J11 ............A-9 Themis Computer...
  • Page 9 C.1 Introduction ......................C-1 C.1.1 Front-Panel Dimensions ................C-1 C.1.2 Injector/Ejector Handles ................C-2 C.1.2.1 VME64-type Handles ..............C-2 C.1.2.2 Legacy-VME Handles ..............C-2 C.2 XV1 Front Panels ....................C-3 C.2.1 Multiple-I/O Connector ................C-3 C.2.2 XV1/1—1 PMC/XMC Module ...............C-4 C.2.3 XV1/2—2 PMC/XMC Modules ...............C-5 Themis Computer...
  • Page 10 C.2.4 XV1/3—3 PMC/XMC Modules ...............C-6 C.3 LEDs ........................C-7 Appendix D. Board Component and Connector Diagrams .......... D-1 D.1 XV1 Baseboard ..................... D-1 D.2 P2 Paddle Board ....................D-1 Appendix E. VME Slot Configurations ................E-1 Index..........................Index-1 Reader Comment Card viii Themis Computer...
  • Page 11 XV1 Paddle-Board Jumper-Pin Locations (Top Side) ........B-5 Figure B-3 XV1 Solder-Bead Locations (Bottom Side) ............ B-7 Figure C-1 PMC/XMC Injector/Ejector Handles............... C-3 Figure C-2 Multiple-I/O Connector Cable ................. C-3 Figure C-3 XV1/1 Front Panel ................... C-4 Figure C-4 XV1/2 Front Panel ................... C-5 Themis Computer...
  • Page 12 Figure C-6 XV1 Front-Panel LEDs ................... C-7 Figure D-1 XV1 Component and Connector Diagram (Top Side) ........D-2 Figure D-2 Paddle Board Component and Connector Diagram (Top Side) ..... D-3 Figure E-1 XV1 VME Slot Configurations ..............V-3 Themis Computer...
  • Page 13 P2 Paddle Board Serial COM1 and COM2 Connector-Pin Signals ..... A-13 Table A-9 P2 Paddle Board PS/2 Connector-Pin Signals ..........A-13 Table A-10 USB Ports 2/3 and 4/5 Connector-Pin Signals ..........A-14 Table A-11 P2 Paddle Board SVGA Connector-Pin Signals.......... A-15 Themis Computer...
  • Page 14 XV1 Paddle-Board Jumper-Pin Settings (Top Side Only) ......B-4 Table B-3 XV1 Solder-Bead Settings (Bottom and Top Side)......... B-6 Table B-4 FSB Frequency Selection................. B-6 Table C-1 XV1 Model Configurations ................C-1 Table C-2 Front-Panel LED Interpretation ............... C-8 Table E-1 XV1 Model Configurations ................E-1 Themis Computer...

  • Page 15: How To Use This Manual

    Preface Section How to Use This Manual The Themis XV1 (see Figure 1 for the single-slot model) is a high-performance ® 6RU VME-bus computer with an Intel quad-core Xeon™ processor that operates at 2.13 GHz. It supports a variety of I/O from the front panel—including gigabit Ether- net, USB 2.0, SATA Revision 1.0a (at speeds up to 3.0 Gb/s), serial, and SVGA...
  • Page 16 Comment Card” is located at the end of this manual for your use. Please take the time to fill out this card with any comments concerning Themis products and ser- vices, and return it to Themis Computer. Your comments may also be forwarded to Themis by sending email to docfeedback@themis.com.

  • Page 17: Intended Audience

    XV1 / 3 3 Modules (2 VME Slots) Caution: Since the original Themis 2P2 PMC/XMC Carrier Board or 2P2/2P3 PMC Carrier Boards physically cannot be installed onto the XV1, a new PMC/XMC Carrier Board is presently being designed, but not yet released.
  • Page 18 Be certain to observe industry-standard ESD protection procedures when handling static-sensitive components. The package should include all elements of your order. Please report any shipping discrepancies to the Themis Computer Customer Support group immediately: support@themis.com or 1-510-252-0870. Themis Computer...

  • Page 19: Chapter Overview

    • Appendix D, “Board Component and Connector Diagrams” provides descrip- tions of the major components and connectors of the XV1 Baseboard and Pad- dle Board. • Appendix E, “VME Slot Configurations” illustrates the various model configu- rations used by the XV1. xvii Themis Computer...
  • Page 20 Website Information Themis Computer corporate and product information may be accessed on the World Wide Web by browsing the website http://www.themis.com. The Sales & Marketing Department may be reached at info@themis.com.
  • Page 21 Please review the Themis Computer warranty and complete the product registration card delivered with your XV1 board(s). Return of the registration card is not required to activate your product warranty but, by registering your XV1, Themis Computer will be better able to provide you with timely information updates and product-enhancement notifications.
  • Page 22 XV1 Hardware Manual Themis Computer...

  • Page 23: Xv1 Installation

    Chapter XV1 Installation Determine Board Type The Themis XV1 single-board computer is available in three model configurations, as defined in Table 1 on page xv of the Preface chapter. To determine your Baseboard type and configuration, check the white sticker located near your Baseboard’s VME P2 connector.

  • Page 24: Check Configurations

    Beads” gives detailed information regarding jumper-pins and solder beads, including default settings. Solder-bead settings are set by Themis at the factory before shipping and should only be changed by Themis at the factory. Warning: Attempting to alter a solder-bead configuration could seriously damage the XV1.

  • Page 25: Figure 1-1 Paddle Board Component And Connector Diagram (Top Side)

    Gigabit Ethernet A 5-Row P2 Connector only VME P2 Development Only Gigabit Ethernet B 5-Row P2 Connector only To VME 5-Row or 3-Row SATA3 P2 Connector SATA4 / SATA5 Figure 1-1. Paddle Board Component and Connector Diagram (Top Side) Themis Computer...

  • Page 26: Table 1-1 Xv1 P2 Paddle Board I/O Connections

    If you have installed a Paddle Board, go to the following sections to attach the appropriate cables to the connectors you will be using. Themis provides most of these cables in the Integration Kit shipped with the XV1 (see Table 1-2).

  • Page 27: Attach Front-Panel I/O Cables

    Connect the multiple-I/O connector cable (P/N 116667-L01; see Figure A-4, page A-6, in Appendix A, “Connector Pinouts and Signal Descriptions”) to the multiple- I/O connector. on the XV1 Front Panel. At the other end, connect each of the sup- ported I/O connectors listed in Table 1-3. Themis Computer...

  • Page 28: Attach Paddle-Board Cables

    Appendix A, with signal descriptions described in Table A-10, page A-14.] 1.5.4 SVGA Video Port Attach one end of a standard 15-pin (3 rows x 5) display cable to the video port on the Paddle Board and the other end to an SVGA display. Themis Computer...

  • Page 29: Sata Ports 3, 4, And 5

    Connect both power cables (P/N 111230-001) to each of the 6-pin power connectors (J1 and J15) on the Paddle Board. Connect the other end of each power cable to the appropriate +5-volt voltage source of the 19” rack power supply. Themis Computer...

  • Page 30: Daisy-Chain Jumper Settings

    To remove the battery (see Figure 1-2), carefully slide it past the opening in the holder until it is free. When replacing the battery, make sure the plus (+) side is fac- ing toward you. TOD/NVRAM Lithium Battery Battery Holder Figure 1-2. Location of the TOD/NVRAM Battery Themis Computer...

  • Page 31: Xv1 Features And Specifications

    • Front-Panel PMC/XMC Module Slot(s) (64 bit/66 MHz) • AMI BIOS with Diagnostic Extension Option • Battery Backup for TOD/NVRAM • Front-Panel System LEDs • PCI and PCI-Express expansion capabilities • Front-Panel I/O ports / Multiple I/O ports through rear VME P2 connector Themis Computer...

  • Page 32: Figure 2-1 Xv1 Block Diagram

    Note: The Intel Dual-Core 5238 Xeon CPU is Gate Array also supported by the XV1. Choice of VME P2 Paddle Board LPC = Low Pin Count CPU must be specified at time of order. Figure 2-1. XV1 Block Diagram Themis Computer...

  • Page 33: Table 2-1 Xv1 Front-Panel I/O Connections

    Channel 0 and Channel 1 (see Figure 2-1 on page 2-2). Note: The size and type of XV1 memory should be specified at the time of your order. SO-DIMMs must be Themis-qualified and registered. Table 2-2. XV1 Memory Configurations...

  • Page 34: Pmc/Xmc Cards

    SVGA monitor ports on both the Front Panel and the Paddle Board. For higher-performance graphics support, it is recommended that the user install a Themis TGA-7000 PMC Graphics Card in one of the PMC/XMC Mod- ule slots within the system (the XV1 baseboard itself or its I/O Expansion Board).

  • Page 35: Pmc/Xmc Carrier Boards

    Themis Computer for a cost estimate. PMC/XMC Carrier Boards Caution: The original Themis 2P2 PMC/XMC Carrier Board or 2P2/2P3 PMC Carrier Boards physically cannot be installed onto the XV1. A new PMC/XMC Carrier Board is presently being designed, but has not yet been released.

  • Page 36: System Specifications

    32-bit version, not for the 64-bit version. Solaris 10, Version 10 05/09 No VME driver is available Solaris 10, Version 10 10/08 No VME driver is available Windows Vista No VME driver is available Windows 2008 Server No VME driver is available Themis Computer...

  • Page 37: I/O Subsystem

    A and Ethernet B are also connected to the P0 backplane connector. b—COM1 must be configured by Themis at the time of your order to be accessed through either the Front Panel or the P2 connector, but not both.

  • Page 38: Auxiliary Functions

    POR reset signal is generated when voltage is out of tolerance POR voltage Environmental monitoring: Vdd, 3.3 V, 5 V, +-12 V Temperature Sensors Monitors whether the CPU temperature stays within a specified range Range can be changed by software (BIOS firmware) Themis Computer...

  • Page 39: Environmental Specifications

    Electrostatic Discharge 15 kV 15 kV a—A non-condensing environment must be maintained at all times. Themis recommends that the board be operational (pow- ered on) and temperature stabilized before and during humidity testing. Regulatory Compliance Table 2-10. XV1 Regulatory Compliance...

  • Page 40: Typical Power Requirements

    (Paddle Board) Total: 61.9 watts 5-volts DC 14.0 watts To be determined 8 GB Auxiliary Voltage 49.5 watts To be determined (Paddle Board) Total: 63.5 watts a—No SO-DIMM installed. b—12-volt or 5-volt source from the P2 Paddle Board. 2-10 Themis Computer...

  • Page 41: Hardware Overview

    The Intel 5408 Xeon architecture enables the system to use a wide range of peripher- als and high-performance operating systems, including Solaris 10, Linux, and Microsoft Windows. For details on the Intel 5408 Xeon processor, refer to the Intel website at http://www.intel.com/. Themis Computer...

  • Page 42: Intel 5100 Memory Controller Hub (Mch)

    • ACPI Power Management Logic Support • Enhanced DMA controller, interrupt controller, and timer functions • Integrated IDE controller support • System Management Bus with additional support for I2C devices • Low-Pin Count (LPC) interface • Firmware Hub (FWH) interface support Themis Computer...

  • Page 43: 82571Eb Dual Gigabit Ethernet Controller

    • Complete legacy Super I/O functionality, including 8042=-based KB/M controller, IEEE 1284, EPP, and ECP-compatible parallel port, serial port, IR port, and floppy-disk controller • ACPI 1.0/2.0 compatibility, therefore supports multiple low power-down modes • Support for the ISA Plug-and-Play Standard register set (v1.0a) Themis Computer...

  • Page 44: Tundra Tsi148 Pci/X-To-Vme Bridge

    (primary and backup), which serve to boot the system. These Serial Periph- eral Interface Flash devices are attached to the Intel 82801 ICH chip (see Figure 2-1 on page 2-2 in Chapter 2, "XV1 Features and Specifications"). The BIOS occupies approximately 512 KB of system memory. Themis Computer...

  • Page 45: Pmc/Xmc Carrier Boards

    PMC/XMC Carrier Boards PMC/XMC Carrier Boards Caution: The original Themis 2P2 PMC/XMC Carrier Board or 2P2/2P3 PMC Carrier Boards physically cannot be installed onto the XV1. A new PMC/XMC Carrier Board is presently being designed, but has not yet been released.
  • Page 46 XV1 Hardware Manual Themis Computer...

  • Page 47: Appendix A. Connector Pinouts And Signal Descriptions

    The connector pinout for the 3-row, VME P1 connector is shown in Figure A-1. Connector-pin signal descriptions are described in Table A-1 on page A-2. Row C Bottom Edge of Board Figure A-1. XV1 VME P1 Connector Pinout Themis Computer...

  • Page 48: Table A-1 Xv1 Vme P1 Connector-Pin Signals

    Not Connected VME_A17 VME_IACKOUT_L Not Connected VME_A16 VME_AM4 VME_A15 VME_A07 VME_IRQ7_L VME_A14 VME_A06 VME_IRQ6_L VME_A13 VME_A05 VME_IRQ5_L VME_A12 VME_A04 VME_IRQ4_L VME_A11 VME_A03 VME_IRQ3_L VME_A10 VME_A02 VME_IRQ2_L VME_A09 VME_A01 VME_IRQ1_L VME_A08 –12V Not Connected +12V _L Indicates an active low. Themis Computer...

  • Page 49: Vme P2 Connector

    (refer to Appendix B, “Jumper Pins and Solder Beads” for details). Note: In Table A-2, • an _L indicates an active low • (–) and (+) indicate one member of a signal pair • a thick border groups associated signals Themis Computer...

  • Page 50: Table A-2 Xv1 Vme P2 Connector-Pin Signals

    SIO_DTR1_P2_L VME_D[24] USB2N LAN_A_MDIN3 VME_D[25] USB3P LAN_A_MDIP3 SIO_CTS1_P2_L VIN_AUX VME_D[26] USB3N VME_D[27] SIO_TXD1_P2 V_1V8 SIO_DSR1_P2_L VIN_AUX VME_D[28] SIO_RXD1_P2 LAN_LINKB100_L VME_D[29] VIN_AUX LAN_LINKB1000_L SIO_DCD1_P2_L VIN_AUX VME_D[30] VIN_AUX LAN_ACTB_L VME_D[31] V_3V3 LAN_LINKA100_L SIO_RI1_P2_L VIN_AUX LAN_LINKA1000_L VIN_AUX VCC (+5V) ALL_PWRGD LAN_ACTA_L Themis Computer...

  • Page 51: Xv1 Front-Panel Connectors

    = Link Speed BI_DC+ Bi-directional pair C+ Green 1000 Mb/s BI_DC– Bi-directional pair C– Green BI_DB– Bi-directional pair B– (Bottom) Flashing rate is 300 ms for = Network transmit/receive activity. BI_DD+ Bi-directional pair D+ Traffic BI_DD– Bi-directional pair D– Themis Computer...

  • Page 52: Multiple-I/O Connector

    USB0 / USB1 Attach to 60-pin Multiple-I/O Port on XV1 faceplate COM1 COM2 VGA Graphics Figure A-4. Multiple-I/O Connector Cable A connector pinout for the multiple-I/O connector is shown in Figure A-5. Baseboard Figure A-5. Multiple-I/O Connector Pinout Themis Computer...

  • Page 53: A.2.2.1 Serial Ports Com1 & Com2

    38 to 41 and 50 to 53 (these include signals for modem support). Serial port COM2 is supported by multiple-I/O connector pins 21 and 22 (transmit and receive only). A.2.2.2 SATA3 Port The SATA3 port is supported by multiple-I/O connector pins 6, 7, 9, and 10 (see Table A-4). Themis Computer...

  • Page 54: A.2.2.3 Usb Ports Usb0 & Usb1

    PMC card installation is shown in Figure A-6; three connectors are required for 64-bit operation, and two connectors for 32-bit operation. J11, J12, J21, J22, J23, J24 Figure A-6. PMC Module Card Connector (4 required) Themis Computer...

  • Page 55: A.4.1 Pmc Module Connector J21 / J11

    +3.3V AD[17] FRAME# Ground Ground IRDY# DEVSEL# Ground LOCK# SDONE# SBO# Ground V(I/0) AD[15] AD[12] AD[11] AD[09] Ground C/BE[0]# AD[06] AD[05] AD[04] Ground +3.3V AD[03] AD[02] AD[01] AD[0] Ground REQ64# a—Connectors J21/J11 corresponds to the PMC standard Jn1. Themis Computer...

  • Page 56: A.4.2 Pmc Module Connector J22 / J12

    +3.3V Ground STOP# PERR# Ground +3.3V SERR# C/BE[1]# Ground AD[14] AD[13] Ground AD[10] AD[08] +3.3V AD[07] PMC-RSVD +3.3V PMC-RSVD PMC-RSVD Ground PMC-RSVD PMC-RSVD Ground PMC-RSVD ACK64# +3.3V Ground PMC-RSVD a—Connector J7 corresponds to the PMC standard Jn2. A-10 Themis Computer...

  • Page 57: Pmc Module Connector J23

    AD[46] AD[45] Ground +3.3V AD[44] AD[43] AD[42] AD[41] Ground Ground AD[40] AD[39] AD[38] AD[37] Ground Ground AD[36] AD[35] AD[34] AD[33] Ground +3.3V AD[32] PCI-RSVD PCI-RSVD PCI-RSVD Ground Ground PCI-RSVD a—Connector J23 corresponds to the PMC standard Jn3. A-11 Themis Computer...

  • Page 58: Pmc Module Connector J24

    COM1 and COM2 are also accessible from the XV1 front panel, in which case, they cannot be accessed through the Paddle Board. Call the Themis sales office at the time of purchase to inform them as to where you would like to access the COM1 and COM2 ports.

  • Page 59: Din-8 Ps/2 Keyboard/Mouse Connector

    DIN-8 PS/2 Keyboard/Mouse Connector Connector Type: 8-pin mini-DIN (Female) Manufacturer; Part Number: TYCO/AMP; 749179-1 Themis Cable P/N: 110104-002 Connector-pin signals for the 8-pin mini-DIN PS/2 port (see Figure A-8) on the XV1 P2 Paddle Board are given in Table A-9.

  • Page 60: Usb Ports Usb2 / Usb3 And Usb4 / Usb5

    USB C Power USB0_D_N USB C Data - Negative USB0_D_P USB C Data - Positive USB0_GND USB C Ground USB1_PWR USB D Power USB1_D_N USB D Data - Negative USB1_D_P USB D Data - Positive USB1_GND USB D Ground A-14 Themis Computer...

  • Page 61: Svga Monitor Port (5-Row Vme Backplane Only

    Red signal output Filtered Vcc voltage source GREEN OUT Green signal output Ground BLUE OUT Blue signal output No connection No connection Display Data Channel—Data Ground HSYNC Horizontal synchronization Ground VSYNC Vertical synchronization Ground Display Data Channel—Clock Ground A-15 Themis Computer...

  • Page 62: Sata Ports 3, 4, And 5

    Figure A-11. P2 Paddle Board SATA Connector Pinout Table A-12. P2 Paddle Board SATA Connector-Pin Signals VGA Signal Description Ground Tx A+ Transmit Signal A-Positive Tx A– Transmit Signal A-Negative Ground Rx A+ Receive Signal A-Positive Rx A– Receive Signal A-Negative Ground A-16 Themis Computer...

  • Page 63: Auxiliary +12-Volt/+5-Volt Power Connectors

    ITT Cannon connector, P/N 192990-0980). Use power cable P/N 111230-001. Warning: The Themis cable connected to this power connector should receive +12V directly from the +12V lug on the chassis power supply, not from +12V pins on the backplane or from the +12V cable supplying the backplane.

  • Page 64: Stereo Audio In/Out Connectors

    P2 Paddle Board Figure A-13. Stereo Audio Connectors A.5.8 Gigabit Ethernet A and Ethernet B (5-Row VME Backplane Only) Both gigabit Ethernet A and Ethernet B on the P2 Paddle Board are used for Themis testing purposes only. A-18 Themis Computer...

  • Page 65: Appendix B. Jumper Pins And Solder Beads

    XV1. Solder beads are considered “factory-configurable” and must not be altered by the user. If a solder bead requires reconfiguration, contact Themis Customer Service. Warning: Solder beads are set by Themis at the factory. Attempting to alter a sol- der-bead configuration could seriously damage the XV1. If you encounter a prob- lem, contact Themis Customer Support.

  • Page 66: Memory Module Jumper Pins

    VME System Controller. a—Boldface = the default jumper position. Absence of a default position indicates a manufacturing or user decision. b—SPI = Serial Peripheral Interface. B.1.2 Memory Module Jumper Pins There are no jumper pins on the XV1 Memory Modules. Themis Computer...

  • Page 67: Figure B-1 Xv1 Jumper-Pin And Solder-Bead Locations (Top Side

    B—Jumper Pins and Solder Beads Field-Configurable Jumper Pins See Figure B-3 for Solder-Bead Legend. Legend VME P1 Jumper Jumper Pin 1 VME P0 VME P2 Top Side Figure B-1. XV1 Jumper-Pin and Solder-Bead Locations (Top Side) Themis Computer...

  • Page 68: Xv1 Paddle-Board Jumper Pins

    Remember that pin 1 is indicated on the board by a thick bar line. Caution: When dealing with a 3-pin solder-bead switch, a solder bead will short only one set of pins, either 1–2 or 2–3. If a solder bead shorts more than 2 pins, call Themis Customer Support. Themis Computer...

  • Page 69: Figure B-2 Xv1 Paddle-Board Jumper-Pin Locations (Top Side

    B—Jumper Pins and Solder Beads Factory-Configurable Solder Beads Legend Jumper Jumper Pin 1 VME P2 Figure B-2. XV1 Paddle-Board Jumper-Pin Locations (Top Side) Themis Computer...

  • Page 70: Table B-3 Xv1 Solder-Bead Settings (Bottom And Top Side

    SB3 [BSEL0] Frequency Short 2–3 Open Open 166 MHz Short 2–3 Open Short 2–3 200 MHz Short 2–3 Short 2–3 Short 2–3 266 MHz Open Short 2–3 Short 2–3 333 MHz Short 1–2 Short 1–2 Short 1–2 CPU Select Themis Computer...

  • Page 71: Figure B-3 Xv1 Solder-Bead Locations (Bottom Side

    = Actual location of solder beads = Description of solder beads SB4 SB5 VME P2 Bottom Side Note: Solder-bead SB6 is located on the Top Side of the board (see Figure B-1). Figure B-3. XV1 Solder-Bead Locations (Bottom Side) Themis Computer...

  • Page 72: Memory Module Solder Beads

    XV1 Hardware Manual B.2.2 Memory Module Solder Beads There are no solder beads on the XV1 Memory Module. B.2.3 XV1 Paddle-Board Solder Beads There are no solder beads on the XV1 Paddle Board. Themis Computer...

  • Page 73: Appendix C. Front-Panel I/O Connections And Leds

    XV1 / 3 3 Modules (2 VME Slots) C.1.1 Front-Panel Dimensions A single-slot XV1 front panel measures 235-mm (9.25”) high by 20-mm (0.78”) wide (with VME64-type handles) or 241-mm (9.5”) high by 20-mm (0.78”) wide (with older Legacy-VME handles). Themis Computer...

  • Page 74: Injector/Ejector Handles

    • Legacy-VME handles, which aid only in the extraction of the PC board from the VME backplane connectors When a PCB board product such as the XV1 is shipped from Themis, VME64-type handles will be installed unless the customer specifies a different handle such as the Legacy-VME.

  • Page 75: Xv1 Front Panels

    2.0 USB0/USB1, and VGA graphics. To attach to each of these different ports, a special multi-split connector cable must be connected to the multiple-I/O connec- tor (see Figure C-2). SATA3 USB0 / USB1 Attach to 60-pin Multiple-I/O Port on XV1 faceplate COM1 COM2 VGA Graphics Figure C-2. Multiple-I/O Connector Cable Themis Computer...

  • Page 76: Xv1/1-1 Pmc/Xmc Module

    Gigabit Ethernet Port C (RJ45) Status LEDs (2) See Section C.3, “LEDs”, for interpretations Serial COM1/COM2 Dual 2.0 USB 0/1 [KB/M] Multiple-I/O Port * SATA3 (SATA II) VGA Graphics Supported by multi-split connector cable. Baseboard Figure C-3. XV1/1 Front Panel Themis Computer...

  • Page 77: Xv1/2-2 Pmc/Xmc Modules

    C—Front-Panel I/O Connections and LEDs XV1 Front Panels C.2.3 XV1/2—2 PMC/XMC Modules PMC/XMC Module PMC/XMC Module See Figure C-3 for a description of Front-Panel connectors Baseboard Figure C-4. XV1/2 Front Panel Themis Computer...

  • Page 78: Xv1/3-3 Pmc/Xmc Modules

    XV1 Hardware Manual C.2.4 XV1/3—3 PMC/XMC Modules PMC/XMC Module PMC/XMC Module PMC/XMC Module See Figure C-3 for a description of Front-Panel connectors Baseboard Figure C-5. XV1/3 Front Panel Themis Computer...

  • Page 79: Leds

    C—Front-Panel I/O Connections and LEDs LEDs LEDs Callouts indicating front-panel LEDs are shown in Figure C-6. Description and interpretation of front-panel LEDs are given in Table C-2 on page C-8. Figure C-6. XV1 Front-Panel LEDs Themis Computer...

  • Page 80: Table C-2 Front-Panel Led Interpretation

    If any power rail fails, the LED will not light either during POST or afterwards. 10 Mbit/s Link Speed Green 100 Mbit/s Gigabit Amber 1000 Mbit/s Ethernet Port C Network LED lights when traffic is detected on the Green Activity network a—From Figure C-6 on page C-7. Themis Computer...

  • Page 81: Appendix D. Board Component And Connector Diagrams

    Figure D-1 on page D-2 identifies front-panel, major board-surface components, and connectors as seen from the top side of the XV1 Baseboard. P2 Paddle Board Figure D-2 on page D-3 identifies the major connectors on the P2 Paddle Board, as viewed from the top side. Themis Computer...

  • Page 82: Figure D-1 Xv1 Component And Connector Diagram (Top Side

    Gigabit Ethernet C Reset Switch (bottom side) VME P2 Intel Intel Quad-Core 5100 L5408 Memory Controller Xeon Processor Multiple-I/O Port Hub (MCH) Heatsink QG5100MCH 2.13 GHz Outline Top Side Figure D-1. XV1 Component and Connector Diagram (Top Side) Themis Computer...

  • Page 83: Paddle Board Component And Connector Diagram (Top Side

    Gigabit Ethernet A 5-Row P2 Connector only Testing VME P2 only Gigabit Ethernet B 5-Row P2 Connector only To VME 5-Row or 3-Row SATA3 P2 Connector SATA4 / SATA5 Figure D-2. Paddle Board Component and Connector Diagram (Top Side) Themis Computer...
  • Page 84 XV1 Hardware Manual Caution: Connect the Paddle Board to the P2 connector of the VME Backplane only. Connection to the P1 connector will cause operational malfunctions as well as possible damage to both the Baseboard and the Paddle Board. Themis Computer...

  • Page 85: Appendix E. Vme Slot Configurations

    XV1 / 3 3 Modules (2 VME Slots) Caution: The original Themis 2P2 PMC/XMC Carrier Board or 2P2/2P3 PMC Carrier Boards physically cannot be installed onto the XV1. A new PMC/XMC Carrier Board is presently being designed, but has not yet been released.
  • Page 86 XV1 Hardware Manual Themis Computer...

  • Page 87: Figure E-1 Xv1 Vme Slot Configurations

    1 PMC Slot Top View Note: The I/O Expansion Board is only 2/3 high (4RU). = Single-height heat sink. = Double-height heat sink. Approved PMC Cards supported by Themis: VME Slot: 5/2009 Figure E-1. XV1 VME Slot Configurations Themis Computer...
  • Page 88 XV1 Hardware Manual Themis Computer...

  • Page 89: Index

    1-4, 1-5 FPGA (Field-Programmable Gate Array) 3-4 Multiple-I/O Connector (60 pins) 1-4 Front Panel Paddle Board 1-6 Dimensions C-1 COM1 and COM2 1-6 I/O Connections 1-5, 2-3 Power Connectors +12V/+5V 1-7 LED Interpretation C-8 PS/2 KB/M 1-6 Index-1 Themis Computer...
  • Page 90 Serial ports COM1 and COM2 1-5, 2-3 Intel 82801 I/O Controller Hub 3-2 SVGA graphics port 1-5, 2-3 Intended Audience xv USB ports 0 and 1 1-5, 2-3 Multiple-I/O Connector-Pin Signals A-7 multi-split connector cable A-6 Jumper Pins B-1 Jumper-Pin Locations B-3 Index-2 Themis Computer...
  • Page 91 SMSC SCH5027 Super I/O Controller 3-3 Module Connector J21/J11 A-9 SO-DIMMs 2-3 Module Connector J22/J12 A-10 Solder Beads B-1, B-4 Module Connector J23 A-11 Solder-Bead Location B-3 Module Connector J24 A-12 Specifications 2-1 PMC Module Card connectors A-8 Index-3 Themis Computer...
  • Page 92 Connector A-1 Signals A-16 Connector Pinout A-1 P2 Paddle Board Serial COM1/COM2 Con- Connector-Pin Signals A-2 nector Pinout A-12 VME P2 P2 Paddle Board USB Ports 2/3 and 4/5 Con- Connector A-3 nector Pinout A-14 Connector Pinout A-3 Index-4 Themis Computer...
  • Page 93 Photo of Model XV1/1 xiii Photo of Model XV1/2 xiv Photo of Model XV1/3 xiv Power Requirements 2-10 PS/2 Mini-DIN Connector Pinout A-13 Rear-Panel Connectors A-1 Regulatory Compliance 2-9 Slot Configurations E-1 Solder Beads B-4 System Specifications 2-6 Index-5 Themis Computer...
  • Page 94 XV1 Hardware Manual Index-6 Themis Computer...
  • Page 95 Place Stamp Here Themis Computer 47200 Bayside Parkway Fremont, CA 94538 Attn: Publications Department Fold here; tape at top to seal...

  • Page 96: Reader Comment Card

    Reader Comment Card We welcome your comments and suggestions to help improve the XV1 User Manual. Please take time to let us know what you think about this manual. • Information provided in the manual was complete. Agree___ Disagree___ Not Applicable___ •...
