- Page 1 GEN II-R Residential / Light Commercial Zoning utilizing 2-postion zone dampers Installation and Applications Manual Control 2-10 Zones with 2 or 3 Wire Dampers using Standard Thermostats with only 1 Gen II-R per System...
- Page 2 18/5 thermostat wire to that one thermostat. 6. Wire TR1 and TR2 terminals from the GEN II-R controller to the first damper control board R and C - only (18 ga thermostat wire).
- Page 3 At startup, this display also reports the number of thermostats communicat- ing with the GEN II-R controller. The display and 3 buttons (H) beneath the display provide the insta- lling contractor the ability to tailor the system to your specific application.
-
Page 4: Table Of Contents
Damper Control Board Addressing and Configuration Thermostat Selection Based on System Operation Thermostat Wiring Schematic GEN II-R WIRING SCHEMATIC Wiring Schematic with Power Closed / Spring Open Dampers Wiring Schematic with Power Closed / Power Open Dampers SYSTEM START UP AND TESTING... -
Page 5: System Overview
DAISY CHAINED FROM DAMPER TO DAMPER SYSTEM OVERVIEW The GEN II-R is a residential / light commercial zone control system controlling 2-10 independent zones per unit. The GEN II-R controller is designed for auto changeover, multi-stage Heat Pump (2C/3H) and Gas Electric (2C/2H) applications. -
Page 6: Component Selection Guide
COMPONENT SELECTION GUIDE GEN II -R Universal Controller for Gas/Electric - 2-Stage Heat/Cool Heat Pump 3- Stage Heat/2-Stage Cool Includes Leaving Air Sensor (LAT) GAS/ELECTRIC HEAT PUMP* GAS/ELECTRIC THERMOSTATS HEAT PUMP THERMOSTATS PROGRAMMABLE PROGRAMMABLE Field Supplied Field Supplied ZONE DAMPERS 5 TONS AND UNDER OVER 5 TONS Low Pressure Dampers (12... -
Page 7: General Sequence Of Operation
3° away from set point, heating is turned off. After a 5-minute purge mode, Cooling is turned on until the cool call is satisfied. If necessary, GEN II-R will return to the heating mode, If all calls have been satisfied, dampers will open for ventilation. -
Page 8: Gas Electric Operation
General Installation Instructions GEN II-R Controller 1. Install the GEN II-R controller on an interior wall where the ambient temperature is between 32°- 120°F (0°- 48°C) non-condensing. This controller is to be installed in an accessible interior area; not in attics or above ceilings. -
Page 9: Ge Advanced Configuration
2nd Stage Heat and Cool Cut-in / Cut-out Configuration The GEN II-R controller is set up at the factory to stage Y2 and W2 cut-in operation based on a 3-min- ute time delay and supply air temperature. This is done using the TIME/TEMP (I) jumper. Time may be field configured from 3-20 minutes by the contractor during system configuration. -
Page 10: 2Nd Stage Operation
GAS ELECTRIC ADVANCED FEATURE CONFIGURATION Adjust 2 Stage Cut-in Time Delay 1. To increase the Y2 and W2 cut-in delay, press and hold the SET and DN buttons (H) simultaneously. When 03 appears in the display, release the buttons and immediately press the UP button and hold until the desired delay time is displayed, and release. -
Page 11: Heat Pump Operation
General Installation Instructions GEN II-R Controller 1. Install the GEN II-R controller on an interior wall where the ambient temperature is between 32°- 120°F (0°- 48°C) non-condensing. This controller is to be installed in an accessible interior area; not in attics or above ceilings. -
Page 12: Basic Configuration
The operation and setup procedures are the same as with “O” mode reversing valve, except the reversing valve will be energized for heat operation. GEN II-R Heat Pump Basic Configuration The GEN II-R controller is shipped from the GEN II-R factory for Gas Electric operation. -
Page 13: Heat Pump Advanced Configuration
2nd Stage Heat and Cool Cut-in / Cut-out Configuration The GEN II-R controller is set up at the factory to stage Y2 and W2 cut-in operation based on a 3-min- ute time delay and supply air temperature. This is done using the TIME/TEMP (I) jumper. Time may be field configured from 3-20 minutes by the contractor during system configuration. -
Page 14: Damper Control Board Call Out
Setting Damper Boards for Heat Pump Operation When the GEN II-R controller is set up for Heat Pump operation, every damper board in the system needs to be placed in heat pump mode. This allows the dampers boards to work with heat pump thermostats. Place the HP... -
Page 15: Thermostat Selection Based On System Operation
THERMOSTAT WIRING SCHEMATIC THERMOSTAT SELECTION BASED ON SYSTEM OPERATION All thermostats are field selected, make sure to choose a programmable thermostat for each zone based on the system parameters below. Programmable thermostats allow multiple schedules on a zone by zone basis. GAS / ELECTRIC - Use any standard gas / electric single stage Heat / Cool 7 day programable thermostat. -
Page 16: Gen Ii-R Wiring Schematic
GEN II-R WIRING SCHEMATIC WITH PC / SO DAMPERS G W2 TC TC TR1 TR2... -
Page 17: Wiring Schematic With Power Closed / Power Open Dampers
GEN II-R WIRING SCHEMATIC WITH PC / PO DAMPERS ACTUATOR ACTUATOR ACTUATOR G W2 TR1 TR2 TC TC... -
Page 18: System Start Up And Testing
B wires going to the next damper control board in the link and address the first damper control board as #1. Turn the GEN II-R power switch Off, then On, to see if the display flashes 01, at the GEN II-R controller. -
Page 19: Advanced Configuration
For constant fan operation place the FAN jumper (I) on the center and upper pins on ON. Opposing Call Changeover The GEN II-R controllers are configured at the factory for Opposing Call Changeover with a time delay setting of 10 minutes. With this configuration, any number of thermostats can make a like active call (heat or cool). - Page 20 2 WIRE ZONE DAMPERS Zonex Systems zone dampers are used in cooling / heating systems to provide room by room zone control. The damper is provided with a zone actuator. Each zone damper is controlled by a zone thermostat. More than one damper can be controlled by one zone thermostat.
- Page 21 ROUND MEDIUM PRESSURE ZONE DAMPERS Zonex Systems round medium pressure zone dampers are recom- mended for systems with a maximum differantial static pressure up to 1.75”. This power open / power closed damper is manufactured from 20-22 gauge galvanized steel with rolled-in stiffening beads for superior rigidity.
- Page 22 MOTOR RECTANGULAR HEAVY DUTY ZONE DAMPERS (STCRX) Zonex Systems rectangular heavy duty dampers are recommended for systems 5 tons or larger with a maximum differential static psure of 1.75”. These are power open / power closed dampers made of 20 gauge “snaplock” steel frame with S & Drive duct connections.
-
Page 23: Sizing
DAMPER TRANSFORMER SIZING The 24V transformer connected to TR1 and TR2 of the GEN II-R System Controller powers the zone dampers. The power rating of the transformer must be sufficient to power the number of dampers used. Also, a properly rated in line fuse must be used on the secondary of the transformer. -
Page 24: Slaving Zone Dampers
SLAVING ZONE DAMPERS SLAVING MORE THAN THREE 2-WIRE ZONE DAMPERS When slaving more than three zone dampers, use the following diagram. An additional 24-volt transformer and control relays are needed for these applications. Note: All slave dampers need to be model TR / TREC and are 12va per damper. ZONE DAMPER 1 ZONE DAMPER 2 ZONE DAMPER 3... -
Page 25: Bypass Dampers
This will control static pressure and noise at the diffusers. be used. NOTE: When using the electronic bypass (STBP/ST- CDBP), see the Bypass Dampers - Electronic Section, Pages Zonex Systems offers two types of bypass dampers, Barome- 23-26; or contact Technical Support at 800-228-2966. BYPASS DAMPERS – BAROMETRIC The barometric bypass damper is for systems 5 tons or under. - Page 26 BYPASS DAMPERS- BAROMETRIC INSTALLATION BAROMETRIC BYPASS SETUP The round barometric bypass damper can be installed in any a) Turn off all thermostats. position. This damper is factory set for horizontal installation b) Turn on Controller and set fan switch to “ON” position. and can be field modified for vertical installation.
- Page 27 24” 4700 STRDBP24 24” 24” 27” The Zonex Systems STBP damper is used for round bypass applications. When you know the bypass CFM requirements, use the ROUND BYPASS SELECTION TABLE to confirm the round damper size. NOTE: Multiple round dampers can be slaved from one static pressure control to provide the correct capacity.
-
Page 28: Slaving Bypass Dampers
RECTANGULAR BYPASS SELECTION TABLE RECTANGULAR BYPASS SELECTION TABLE WIDTH IN INCHES 1000 1167 1333 1500 1667 1833 2000 2333 2667 3000 3333 3667 4000 1042 1250 1458 1667 1875 2083 2292 2500 2917 3333 3750 4167 4583 5000 1000 1250 1500 1750 2000... -
Page 29: Ipc - Static Pressure Controller
INTEGRATED PRESSURE CONTROL SETUP BYPASS DAMPER with INTEGRATED PRESSURE CONTROL (Part # STBP or STCDBP) Bypass Damper with Integrated Pressure Control is used to control bypass operations. The bypass damper modulates to maintain static pressure as zone dampers open and close. The bypass system reduces air noise from the supply registers caused by excessive air velocity. - Page 30 INTEGRATED PRESSURE CONTROL SETUP Static Pressure Option: The Integrated Pressure BYPASS CHECKOUT FOR STATIC PRESSURE Control Board can be field configured for specified CONTROLLER static pressure using a multi meter and the static pressure – voltage chart. (Exhibit A). This chart Make cool call at the zone thermostat of the shows voltage (DC) to inches of W.C.
- Page 31 The easy way to Get Quotes Fast PATENTED PRODUCT Part #GENII-RMAN Zonex Systems reserves the right to discontinue, December 2018 or change at any time, specifications or designs without notice and without incurring obligations. Copyright 2018 by Zonex Systems...
