Phoenix Gold DSP8.8 Manual

Digital signal processor

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

FEATURES

● 8-channel high level inputs with signal sense turn on and load resistors

● 6-channel low level inputs

● Aux input (3.5mm, high level for external NAVI/hands-free)

● USB input for uncompressed hi-res audio from iOS/Android smart devices/thumb drives up to 24bit/192kHz

● Wi-Fi input for wireless connectivity and uncompressed hi-res audio streaming up to 24bit/192kHz

● Toslink optical hi-res audio input up to 24bit/192kHz

● 8-channel 5 volt low level outputs

● Real time DSP tuning via DSP8.8 configurator app for iOS, Android, Mac and Windows PC

● 240 bands of 1/3 octave parametric EQ adjustment (30 bands per channel)

● DRC Included (Dash Mount Remote Control): multi-function remote for source select, volume, sub level, 6

selectable presets, and custom illumination

● DSP8.8 RC remote control app for iOS and Android phones/tablets for source select, volume, sub level, and

6 selectable presets

● Dimensions (WxHxD): 7.5" x 2" x 7.75" 190.5 x 51 x 197mm

DSP8.8 Manual

Digital Signal Processor

Table of Contents

Need help?

Do you have a question about the DSP8.8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Phoenix Gold DSP8.8

Page 1 ● DRC Included (Dash Mount Remote Control): multi-function remote for source select, volume, sub level, 6 selectable presets, and custom illumination ● DSP8.8 RC remote control app for iOS and Android phones/tablets for source select, volume, sub level, and 6 selectable presets ●...
Page 2: Table Of Contents
Box Contents utilization of the 5 available audio source inputs. Lastly, what makes the DSP8.8 transcend above all other automotive DSPs is that the DSP8.8 is the WORLD’S FIRST Wi-Fi streaming DSP for any device using DSP Features iOS, Android, Mac or Windows PC. This allows users full access of the most ergonomic, user friendly setup/ tuning interface to date that makes tuning the DSP8.8 a very simple and precise process no matter if...
Page 3: Dsp Features
DRC backlight color customization through app and configuration software Remote output current: max 1.3 A Dimensions: W x H X D 7.5” x 2” x 7.75” 190.5 x 51 x 197mm Weight: 2.15 lbs. 1326 kg © 2017 Phoenix Gold • www.phoenixgold.com © 2017 Phoenix Gold • www.phoenixgold.com...
Page 4: Device Connections
7. AUX input for 3.5mm 8. Status LED (red: error/clipping, green: operating/data, yellow: USB connection) 9. Power supply harness connector HIGH LEVEL INPUT HARNESS (33 ohm load resistors inside DSP8.8 on each input channel) 1. 8 RCA outputs 2. Aux input for phone/nav 3.
Page 5: Connecting Analog Sources
Connecting Digital Sources Two of the 5 selectable sources are digital, offering the highest level of audio resolution on the DSP8.8. TOSLINK IN: (S/PDIF) connector accepts a 2-channel digital audio signal from any device’s optical output via S/PDIF connector, with a sampling rate of 24bit/96kHz.
Page 6: Windows Installation For Xp
When the security pop-up appears, click “more info” (Win 10) this will allow the option for “Run anyway” (Win 10) or “Continue Anyway” (Win XP,7,8) Step 2: Open the folder and choose your operating system. © 2017 Phoenix Gold • www.phoenixgold.com © 2017 Phoenix Gold • www.phoenixgold.com...
Page 7 DSP8.8 Next the windows setup wizard begins, you must confirm installation by clicking on “Next” tab. The next window allows the setup wizard confirm installation of the DSP8.8 program by clicking the “Install” tab. The next window will confirm the folder location of installation files by clicking on “Next” tab.
Page 8: Mac App Installation
When actively connected to the DSP8.8, the Phoenix icon will continuously blink while data is being streamed between the smart device and the DSP8.8. This can also be seen on the DRC as the LED for button #1 (see image 4). The DSP8.8 is now ready for system configuration to begin.
Page 9: Configuration Screen
Mac/PC on the volume’s numerical display will reveal the pop-up window for exact adjustments in .50db increments (see image 6). Subwoofer level control from the DSP8.8 is off by default. To activate the sub level control for use in the app and for use on the DRC, a long press on a tablet or a right mouse click for Mac/PC on Ch7 and or Ch8 to reveal the pop-up window for channel configuration, select “SUB”...
Page 10 • Navi: Input on the aux harness is mixed into output Ch 1-2, Ch 3-8 audio in attenuated now • Phone: Input on the aux harness is passed to output Ch1-2, Ch 3-8 are muted IMAGE 13 IMAGE 14 © 2017 Phoenix Gold • www.phoenixgold.com © 2017 Phoenix Gold • www.phoenixgold.com...
Page 11 DSP8.8 DSP8.8 Autoremote: This feature is used to automatically turn on/off the DSP8.8 using signal sensing. To activate 4) Channel configuration: This is where each of the 8 independent output channels can be this, a single press of the autoremote icon (see image 15) on a tablet or a single mouse click for Mac/PC customized for sophisticated system setup and tuning.
Page 12 Phase is adjusted by a press on a tablet or a single mouse the DSP8.8 and any changes are made such as (X-over, EQ, T/A, phase, etc.) to the channel’s default click on Mac/PC of the 0/180 button (see image 25). This adjustment helps to acoustically align each configuration, causing the preset button’s title/name color to change from light orange to a dark orange...
Page 13 When all values have been entered simply press the compute button and the calculated measurements will be displayed (see image 28). Press the apply button to store these measurements into each output channel the DSP8.8. The rotary knob can still be used to make even more detailed adjustments, if required.
Page 14 EQ, time delay, output level and phase for each output channel. also. The default KEY or password of the DSP8.8 is PGDSP8.8, but it can be changed here to a more You will also see how these adjustments affect the audio signal that you’re hearing. You must press the secure choice if you choose to do so.
Page 15: Drc Functions
Button 1: Wi-Fi/Dimmer status: The default function is Wi-Fi communication status. The LED will blink during serial number, DSP FW version and APP version to be displayed. A Wi-Fi connection to the DSP8.8 must this process. Press button 1 once, the LED will illuminate solid and will allow LED dimmer adjustment. Use the rotary knob to adjust the LED brightness.
Page 16: Dsp8.8
LIMITED WARRANTY ON DIGITAL SIGNAL PROCESSORS Phoenix Gold warrants this product to be free of defects in materials and workmanship for a period of one (1) year from the original date of purchase. This warranty is not transferable and applies only to the original purchaser from an authorized Phoenix Gold dealer in the United States of America only.
