- Page 1 VG6000 Digital Gateway Administrator Installation and Configuration Guide 06VG60M.DG1.01a.EN1...
- Page 2 DSG, DSG logo, InterPBX, InterServer, Blaze Series, Savanna Series, VG5000, VG6000, IP580, IP500, InterClient, NAT Proxy, SIP Proxy and S300X are trademarks of DSG Technology. Windows and Outlook Express are trademarks of Microsoft Inc. Other names used here are trademarks of their respective owners.
-
Page 3: Table Of Contents
Table of Contents Table of Contents Chapter 1 Installing VG6000 Digital Gateway ............5 Before You Start ...................... 6 Installing VG6000 Digital Gateway ................ 6 Chapter 2 Configuring Digital Gateway ..............11 Configuring Trunks ....................12 Configuring Channels ..................15 Reset Trunks ...................... -
Page 5: Chapter 1 Installing Vg6000 Digital Gateway
IDSN (Integrated Services Digital Network) is a switched digital network for voice and data. It provides higher speed alternative to analog networks. If you have subscribed ISDN services, you may install DSG VG6000 Digital Gateway allowing you to access ISDN services when using DSG Blaze or Savanna IP-PBX. -
Page 6: Before You Start
Plug one end of the power cord to the power connector on the rear panel of VG6000. Plug the other end of the power cord into a power outlet. After you turn on the power switching on the rear panel, you can verify the function by checking if the LED labeled “Power”... - Page 7 Ethernet cable from the network RJ45 port on VG6000 to any 10/100BaseT RJ45 port on a switching hub. The default IP settings of VG6000 are as follows. You may change it to conform to your network later. Default IP Address: 192.168.1.206 Default Gateway: 192.168.1.254...
- Page 8 Shield/Return/Ground Shield/Return/Ground Step 5. Launch VG6000 Program Turn on the power of VG6000 and you will be prompted Windows From your desktop, double click on DigitalGW.exe shortcut go to C:\DG1.00a\Setup\DigitalGW.exe to launch the program. The name of DG1.00a folder varies in your software version.
- Page 9 Chapter 1 Installing VG6000 Digital Gateway Lines are gray out when not configured. You may edit them later. When connected and properly set, line description is in green text. Line indicator is in yellow when in use. Numbers of incoming call (represented as: I) or outgoing call (represented as: O) are displayed at the description field.
-
Page 11: Chapter 2 Configuring Digital Gateway
Chapter 2 Configuring Digital Gateway This chapter guides you through the details of configuring VG6000 Digital Gateway. You will need to input the required parameters and set its direction to your IP-PBX System. Each VG6000 can support one IP-PBX system. -
Page 12: Configuring Trunks
Chapter 2 Configuring Digital Gateway Configuring Trunks You need to properly set trunk and channel parameters to conform to the requirement of your ISDN services. Double click on DigitalGW.exe shortcut or go to C:\DG1.00a\Setup\DigitalGW.exe to launch the program. On the main menu, choose System>Setup. You will be prompt System Configuration window. - Page 13 Chapter 2 Configuring Digital Gateway T1_NI2_ISDN T1_4ESS_ISDN T1_5ESS_9_ISDN T1_5ESS_10_ISDN T1_DMS100_ISDN J1_TRANSPARENT T1_NTT_ISDN E1_AUSTEL_ISDN E1_HKT_ISDN E1_KOR_ISDN T1_HKT_ISDN E1_QSIG E1_TNZ_ISDN T1_QSIG V5_1_AN V5_1_LE V5_2_AN V5_2_LE T1_IUA E1_IUA Line Code: Line Coding is the pattern that data assumes as it propagated over a communications channel. B8ZS HDB3 Termination Side: For ISDN only.
- Page 14 Chapter 2 Configuring Digital Gateway choosing Clock_Master_On, the trunk clock source is provided by the internal clock source. Clock_Master_Off Clock_Master_On Line Build Out Loss: This setting is applicable only to T1 trunks and used to control loss for different lengths of the line. ac0DB ac7_5DB ac15DB...
-
Page 15: Configuring Channels
Chapter 2 Configuring Digital Gateway CAS Protocol File: It functions only when your select CAS protocol type. This file contains the CAS Protocol definition to be used for CAS-terminated trunks. Note: When you click the OK button, trunks will be reset. Please make sure there is no call activity on the system. - Page 16 Chapter 2 Configuring Digital Gateway PSTN Voice Volume: PSTN Voice Volume sets the voice decoder’s output gain. 0~63 PSTN Input Gain: PSTN Input Gain sets the gain at the voice decoder’s input. 0~63 Echo Cancellation: Depends on the voice quality, enable or disable echo canceller.
-
Page 17: Reset Trunks
Chapter 2 Configuring Digital Gateway this trunk. Notice that the number should conform to your carrier or regional telecom requirement. Source Numbering Type: Unknown_Number International_Number National_Number Network_Specific_Number Subscriber_Number Abbreviated_Number Destination Type: Unknown_Number International_Number National_Number Network_Specific_Number Subscriber_Number Abbreviated_Number Destination Plan: Unknown_Numbering_Plan Isdn_Numbering_Plan Data_Numbering_Plan Telex_Numbering_Plan... -
Page 18: Enable And Disable Channels
Chapter 2 Configuring Digital Gateway Note: When you click the OK button, trunks will be reset. Please make sure there is no call activity on the system. Enable and Disable Channels You may enable or disable all or some channels for maintenance purpose. Choose a specific trunk tab and select or deselect to enable or disable channels. - Page 19 Chapter 2 Configuring Digital Gateway...
-
Page 21: Chapter 3 Settings On Interpbx System
Chapter 3 Settings on InterPBX System Chapter 3 Settings on InterPBX System When adopting VG6000 Digital Gateway, your InterPBX IP Communication System, including Blaze, Savanna series IP-PBX, needs to enable the relevant function as well. You will need to create a VG6000 Digital Gateway list. -
Page 22: Adding Digital Gateway
Chapter 3 Settings on InterPBX System Adding Digital Gateway You need to set the MAC address of VG6000 Digital Gateway to the InterServer. 1. Launch the web browser. On the address bar, enter your InterServer’s IP address. (Please use service port 88.) Click on the Administrator icon and use your user name and password to login. - Page 23 Chapter 3 Settings on InterPBX System Trunk Number: Enter the available trunk numbers you may use or purchase. CO Line per Trunk: Input the available channels of each trunk. For example, input 32 for E1 or 24 for T1. CO Line Extension Base: Input the starting number of CO Line extension number.
-
Page 24: Setting Trunk Parameters
Chapter 3 Settings on InterPBX System Setting Trunk Parameters You can further more set the parameters of each trunk to adjust the voice quality and other items. Select a gateway you would like to edit from the list and click the Trunk button to edit each trunk of the selected gateway. Trunk: Select a trunk you would like to edit from the list. - Page 25 Chapter 3 Settings on InterPBX System Setting button. Select a port from the list and click the Port Parameters button to edit. Extension Number: The extension number will be displayed automatically based on your settings under “CO Line Extension Base”. You may also change the extension number here. Description: Input the telephone number or other information for this port.
- Page 26 Chapter 3 Settings on InterPBX System 660x-xxxx, but you have 4-digit extension number, set “1” to delete the first digit sent by your carrier. The default value is 0. Ring Assignment: Ring Assignment allows you to assign a specific extension, extension group or AA Menu to answer incoming calls from a specific CO line or CO Line Group.
-
Page 27: Setting Digital Trunk Ars
Chapter 3 Settings on InterPBX System Enter in the field “Apply to Port” the first and the last port you would like to be identical to the present settings. If the range selected includes this port, the new settings, if any, will also be applied to this one. - Page 28 Chapter 3 Settings on InterPBX System STEP 2: 1. Go to Main Menu>Group Management>Class of Service. 2. Select a Class of Service from the list and click the ARS button to apply the route you just created to the selected CoS. 3.
- Page 29 Chapter 3 Settings on InterPBX System Making calls using ARS 1. Lift the handset. Press your CO line access code “0” to get a line and input the phone number you would like to call. 2. Depending on your Class of Service and business hour, the call will be routed to your digital gateway for connecting to PSTN.
-
Page 30: Chapter 4 Line Status And Event
Chapter 4 Line Status and Event Chapter 4 Line Status and Event VG6000 Digital Gateway displays different real-time system status. It also provides log files and event logs allowing you to analyze the connection and transmission status. -
Page 31: Line Status
Chapter 4 Line Status and Event Line Status After you launch the program, you will see “Line Status” tab. Each line will have its status indicator and description. Lines are gray out when not configured. You may edit them later. When connected and properly set, line description is in green text. - Page 32 Chapter 4 Line Status and Event...
-
Page 33: System Specifications
System Specifications System Specifications System Capacity Blaze or Savanna InterPBX System x 1 E1 x 32/64/128 channel (1/2/4 Trunk) T1 x 24/48/96 channel (1/2/4 Trunk) 32 bit Memory 256MB DDR400 Network Interface 10/100 Mbps, RJ45 LAN Port Physical Interfaces E1/T1, 120 Ohm -RJ48 connectors Signaling CAS T1 robbed bit, MFC/R2 numerous country variants... -
Page 34: Index
Configuring Channels ....................15 Configuring Trunks ..................... 12 Enable and Disable Channels ..................18 Event ..........................31 Installing VG6000 Digital Gateway ................6 Launch VG6000 Program ....................8 Line Status ........................31 Pin Signals ........................7 Rest Trunks ........................17 Setting Digital Trunk ARS ..................
