- Page 1 USE MANUAL English CUTTING UNIT MOD. GRT12DT ED.1-04/13 Enfocus Software - Customer Support...
- Page 2 All the parts of the devices have been planned and produced to guarantee an optimum performance. In order to keep the high quality level and the long reliabilty of the Rasor ® products, it is recommended to use only original spare parts and to contact the head office for any maintenance work.
-
Page 3: General Safety Rules
1. GENERAL SAFETY RULES This manual is an integral part of cutting unit GRT12DT and must be carefully read before using it since it gives important indications with regards to its safe installation, use and maintenance. Keep it with care. - Page 4 Moreover, they cannot work in case of rain. In case of damage or malfunction, cutting unit GRT12DT must not be used until the Customer Care Technical Service has repaired them.
-
Page 5: Transport And Packing
In such a case, the operator is the only person responsible. Model R EAD S H E A R I N G T H E Serial number GRT12DT R ISK INSTRUCTION 0,52 Electric data MANUAL Year of production... -
Page 6: Product Description
4. PRODUCT DESCRIPTION The fixture described in this manual is a cutting unit model GRT12DT which can be assembled on automatic machines (e.g. spreaders, computerized cutting) by means of proper holes located in the motor support. Cutting unit GRT12DT can operate continuously and bidirectionally (i.e. -
Page 7: Technical Features
6. NOISE LEVEL The maximum acoustic pressure level emitted by cutting unit GRT12DT is about 60 dB (A). Noise tests have been carried out in compliance with Standard UNI EN ISO 11202. The device noise levels, measured at different distances (without any sound wave filtering system), vary in the extent of few db (A). -
Page 8: Use Warnings
• Always pay attention to the electric cable position to prevent it from being cut or damaged by the blade. • It is allowed to assemble cutting unit GRT12DT on machines O.E.M. on condition that their original structure is not modified. Otherwise, the intervention must be certified by Rasor ®... -
Page 9: Residual Risks
6) Carry out the cutting operation. NOTE Cutting unit GRT12DT can work in a fixed position (the material has to be moved) or it can move forward while the material is kept in the same position. Make sure the material to be cut is properly stretched, preventing it from curling. -
Page 10: Blade Sharpening
To carry out this operation, remove the protective plug “A” located on the motor support of the cutting unit and fill it with lubricating grease Rasor. Screw plug “A” again a few turns. Screw plug “A” a few turns every 2-3 working days (see picture 9). -
Page 11: Blade Replacement
Rasor can be seen by the operator. 6) Assemble all the components again and carry out the sharpening. -
Page 12: Troubleshooting
15. TROUBLESHOOTING PROBLEM SOLUTION Check the distance between the blade and the counterblade Check the kind of fabric Sharpen the blade The fabric is not cut or it gets stuck between Check the fabric thickness the blade and the counterblade Check the compatibility between blade and fabric Make sure that the motor turns correctly Reduce the feeding speed... - Page 13 Enfocus Software - Customer Support...
-
Page 14: Warranty
The warranty covers all manufacturing and material defects. Replacement and repair operations are covered only if carried out by our company and at our workshop. If in-warranty goods need to be repaired, the customer must always send the complete machine to Rasor ®... -
Page 15: D D Eclaration Of Conformity
UNI EN ISO 12100-2. Noise tests have been carried out according to UNI EN ISO 11202 Standards. Cutting unit GRT12DT has been produced according to workmanlike standards. We declare that the above-mentioned goods comply with the standards in force concerning safety and hygiene at work that can be applied to the material itself according to the Italian legislative decree No. - Page 16 Enfocus Software - Customer Support...
