Summary of Contents for Uponor Smatrix Base PRO R-147 KNX
- Page 1 Uponor Smatrix Base PRO R-147 I N S TA L L AT I O N A N D O P E R AT I O N M A N U A L 12 | 2016...
-
Page 2: Table Of Contents
Required devices and softwares ........5 Installation procedure ..........5 Install KNX gateway module ........6 Prepare for installation ..........6 Install Uponor Smatrix Base PRO system ....6 Attach KNX gateway module to the wall using DIN rail ............6 Installation example ..........7 Disconnect the Smatrix Base PRO system from AC power ..............8... -
Page 3: Copyright And Disclaimer
Modification or use of any of the contents of the time without prior notice or obligation. The manual manual for any other purpose is a violation of Uponor’s is provided “as is” without warranties of any kind, copyright, trademark and other proprietary rights. -
Page 4: Dk 2 Preface
Preface This installation and operation manual describes how Correct disposal of this product to install and operate the Uponor Smatrix Base PRO (Waste Electrical and Electronic Gateway Module R-147 KNX. Equipment) Safety instructions N O T E ! Applicable in the European Union and other... -
Page 5: Ee 3 Description
An Uponor Smatrix Base PRO system can be connected The following list states what is needed to utilize a full to a standard KNX bus via an Uponor Smatrix Base PRO KNX connection for a Uponor Smatrix Base PRO system: Gateway Module R-147 KNX (KNX gateway module). -
Page 6: Install Knx Gateway Module
ETS) correctly and powered off. module using a DIN rail. See separate documentation (not supplied by Uponor) for more information. To determine where to best place the Uponor Smatrix Base components, follow these guidelines: • Ensure that the KNX gateway module can be installed close to the Smatrix Base PRO bus. -
Page 7: Installation Example
X-147 24...30 V DC 230 V AC R-147 T-143 aution An Uponor Smatrix Wave PLUS Interface I-147 is needed to enable en KNX Gateway module. aution A separate power supply is needed for the KNX bus. N O T E ! -
Page 8: Disconnect The Smatrix Base Pro System From Ac Power
S Disconnect the Smatrix Base PRO yStem With ponor thermoStatS A connection example of an Uponor Base PRO system system from AC power connected to the KNX bus using the KNX gateway module. arning Electrical installation and service behind •... -
Page 9: Connect The Knx Gateway Module To The Smatrix Base Pro Bus
3. Remove the cover from the Smatrix Base PRO controller. See the installation and operation manual for Uponor Smatrix Base/Base PRO for more information. 4. Connect the wires from the thermostat bus on the Smatrix Base PRO controller to the lower connector on the KNX gateway module. -
Page 10: Connect The Knx Gateway Module To
Connect the KNX gateway module Connect the KNX bus to DC power to the KNX bus 24...30 V DC The illustration shows the KNX gateway module connected to the KNX bus. arning There is 24 – 30 V DC in the KNX bus, if connected to the mains. -
Page 11: Connect The Smatrix Base Pro System To
4.10 Connect the Smatrix Base PRO 4.11 Enable the KNX gateway module in system to AC power the interface I-147 Integration GPI: Heating/Cooling switch Supply water controller: Disable KNX Gateway: Enable X-147 1. Check that all wiring is complete and correct: To connect the enable the KNX gateway module in interface I-147: •... -
Page 12: System Setup
4. If the ETS® address is assigned succesfully, the programming LED is turned off. 1. Download the product data file from the Uponor website (http://www.uponor.com/smatrix/knx). 2. Load the product data file into the ETS® tool. -
Page 13: Lv 5.4 Setting Up A System
Controller Default ETS® configuration flag settings etS® tool In order for the Uponor Smatrix Base PRO system to aution communicate with the KNX bus, the KNX gateway If using a BMS to set the heating and/ module must be programmed in the ETS® tool. - Page 14 If using KNX thermostats it is recommended to use thermostats that can send the aution If using a BMS to set the setpoints of Uponor setpoint and room temperature cyclically, thermostats it is recommended to change the even if the value doesn’t change. Otherwise...
- Page 15 Cooling offset activated (requires changed flag (default flag settings) settings) In this setup only Uponor thermostats are used and all In this setup only KNX thermostats, or a mixture of ETS® configuration flags are set to default. Setpoints are Uponor and KNX thermostats, are used with Cooling transmitted to the controller and touch screen interface, offset activated in the Uponor system.
-
Page 16: Data Point Lists
Data point lists Uponor provides default configuration flags (in the product data file) which normally does not need to be changed. General parameters Configuration flags, group objects Data point Description KNX data type Outdoor temperature Measured outdoor temperature DPT_Value_Temp Forced ECO... - Page 17 etS® vailaBle Configuration flagS Flag Description COMMUNICATION Enables the KNX gateway module to communicate with the data point. Must always be activated when the data point is used. TRANSMIT Enables the KNX gateway module to transmit Smatrix Base PRO data points to the KNX bus.
-
Page 18: Nl 7 Troubleshooting
Troubleshooting KNX gateway module LEDs The table below describes the status of the KNX gateway module LEDs. It is recommended to occasionally check the status LEDs on the KNX gateway module for alarms. Status Power The power LED is always on. •... -
Page 19: Knx Gateway Module Error Codes
KNX gateway module error codes Resetting the KNX gateway module If an error in the KNX gateway module has occured If the KNX gateway module does not work as expected, during normal operation, the bus LED (KNX and/or or if an error is indicated, it can be reset and maybe Modbus) changes to red. -
Page 20: No 7.4 Led Error Codes
Occupied thermostat A KNX thermostat is registered on the 1. Ensure that an Uponor thermostat is not registered to a channel same channel as an Uponor thermostat. channel used by a KNX thermostat. - Page 21 Uponor controllers are present in the system. If the alarm is persistent (not automatically reset): 1. Ensure that all Uponor controllers in the system is powered up. 2. Perform a hard reset on the KNX gateway module.
- Page 22 Description Probable cause Solutions KNX gateway module The KNX gateway module has not received 1. Ensure that all Uponor controllers in the system is and Smatrix Base PRO any communication replies from one of the powered up. controller communication controllers for a period of time.
-
Page 23: Technical Data
A, B, – on controller system bus http://www.uponor.com/ce-compliance U P O N O R S M AT R I X B A S E / B A S E P R O · I N S TA L L AT I O N A N D O P E R AT I O N M A N U A L... -
Page 24: Pl 8.3 Dimensions
Wiring diagram Dimensions (mm) 50.5 R-147 30.5 A B - + - - X-147 U P O N O R S M AT R I X B A S E / B A S E P R O · I N S TA L L AT I O N A N D O P E R AT I O N M A N U A L... - Page 25 U P O N O R S M AT R I X B A S E / B A S E P R O · I N S TA L L AT I O N A N D O P E R AT I O N M A N U A L...
- Page 26 Uponor Corporation www.uponor.com Uponor reserves the right to make changes, without prior notification, to the specification of incorporated components in line with its policy of continuous improvement and development.
