MIP-2300 EXTRA HD STEEL CUTTER
KEY#
DESCRIPTION
1
Handle Grip
2
Upper Handle Assembly
3
Lower Handle Assembly
4
Handle Pin
5
Retaining Ring
6
Link Pivot Bolt
7
Link Pivot Nut
8
Jaw Pivot Nut
9
Jaw Pivot Retaining Ring
10
Jaw Pivot Bolt
11
Toggle Link
12
Moving Blade
Reference part number when ordering.
Read and follow all operating & safety instructions on reverse.
QTY PART#
2
M2300-1
1
M2300-2
1
M2300-3
2
M2300-4
1
M2300-5
1
M2300-6
1
M2300-7
1
M2300-8
1
M2300-9
1
M2300-10
1
M2300-11
1
M2300-12
2/4/05 boss
Advertisement
Table of Contents
Summary of Contents for MIP MIP-2300
- Page 1 MIP-2300 EXTRA HD STEEL CUTTER KEY# DESCRIPTION QTY PART# Handle Grip M2300-1 Upper Handle Assembly M2300-2 Lower Handle Assembly M2300-3 Handle Pin M2300-4 Retaining Ring M2300-5 Link Pivot Bolt M2300-6 Link Pivot Nut M2300-7 Jaw Pivot Nut M2300-8 Jaw Pivot Retaining Ring...
- Page 2 SAFETY WARNINGS • Always read the instructions. Only use equipment recommended for the strap. The MIP-2300 is recommended only for 3/4" .015 through 1-1/4” .050 gauge steel. • Always wear adequate safety equipment for protection of your eyes, hands and body.
