Summary of Contents for VooDoo Evolve 80TC
- Page 3 Specification: Size: 22*38*82mm Output Mode: VV/VW/TC Mode Output Wattage: 7-80W Resistance Range during VV/VW mode: 0.2-3.0 OHM Resistance Range during TC mode: 0.15-1.0 OHM Temperature Range: 100-315°C, 200-600°F Applicable Coil wire under TC mode: Stainless steel wire, Ni-200 wire, Ti wire...
-
Page 4: How To Use
HOW TO USE: 1. How to turn off the device Slide down the magnetic back cover and place the 18650 battery in to the mod. Be sure to follow the diagram inside the body for correct battery orientation. The + side should be at the top when installing your 18650 battery. - Page 5 3. How to select TC/VW modes: While the device is on, thread your tank system to the device. The screen will light up and show “SELCOIL” as well as the coil resistance below it. Use the + or – buttons at the bottom of the device to move through the different selections.
- Page 6 Once selected the screen will show the main interface displaying the present output wattage, voltage and resistance or the present temperature, wattage and resistance. In order to change the wattage hold the + or – button until the wattage starts to blink and then move up or down accordingly.
- Page 7 Malfunction Indication and Protection Over 10 second protection: When the power button is pressed for 10 seconds, the output will shut off and the OLED screen will display “Over 10s protection” Low Power Alert: When the voltage of the battery is lower than 3.3v before using the device, or under 2.8v during use of the device, the OLED screen will display ”Battery Low”...
- Page 8 Temperature Alert: If the temperature of the device is over 185 degrees, the output will shut off automatically and the screen will display “Device Too Hot”. Maintenance of the product: To ensure best usage of the device: • Regularly clean the 510 threading with a Q-Tip or an absorbent paper to remove any dirt or liquids.
- Page 9 Warranty Terms The Voodoo Evolve 80TC kit is guaranteed from factory defects for 90 days from the date of purchase. We will not guarantee products that have been damaged due to neglect or improper use. This product is only intended for use with the provided usb charger and Voodoo Evolve accessories.
-
Page 10: Customer Care
CUSTOMER CARE For more information on our products or to keep up to date on our latest news, please visit us at VoodooVape.com WARNING: This product has not yet been approved by the FDA. This product is not intended to diagnose, treat, prevent, cure or mitigate any disease or medical condition or offer any therapeutic benefit. - Page 11 Voodoo reserves the right of final decision in all warranty cases. Voodoo may interpret and revise the content of the warranty terms. WARNING 1. Keep out of the reach of children 2. This product is not recommended for use by anyone under the age of 21 3.
- Page 12 FOLLOW US ON...
