- Page 1 Primo Series Amplifier 3200.1 1200.1/ 2000.1/ 1900.4 1200.4/...
- Page 2 INTRODUCTION Congratulations! And thank you for purchasing a "Massive Audio" Primo series amplifier for your car audio system. You now own an amplifier of uncompromising design and engineering incorporating the latest advances in micro topology. This handcrafted amplifier is designed to deliver the demands of serious sound competitors.
-
Page 3: Design Features
Full MOSFET with high grade switching devices Built-in auto sensing Turn On function (Hi-Inputs) 12V Remote Output for external devices (Hi-Inputs) 0~12dB variable Bass boost Next generation advanced 5 way protection circuitry 2CH / 4CH input mode switch (PX1900.4) World Wide standards compliant. (RoHS,E-mark,CEA-2006,CE) PRIMO SERIES... -
Page 4: Amplifier Functions
Amplifier Functions 1. Speakers Connect speakers/subwoofers to these terminals. Be sure to check wire for proper polarity. never connect the speaker cables to chassis ground. 2. +12 Volt Power Connect this terminal through a fuse or circuit breaker to the positive terminal of the vehicle battery or the positive terminal of an isolated audio system battery. -
Page 5: Panel Layout
pushing large caliber full frequency speaker, please switch to FULL mode. When switch to FULL mode, The filters will not function. WARNING: Use buttons and HPF knob correctly to prevent low frequency damage to tweeters. 13. Frequency Control (PX1200.4) This switch works together with X-over X1 / X10 For High Pass Frequency Crossover, When this button is set at the “X10”... - Page 6 15. EXTERNAL CAPACITOR INPUT For connecting an optional (RCP sold separately) external hi-voltage capacitor. This will help stabilizing the amplifiers needed voltage during operation while improving fidelity and maximizing head room. 16. Power / Protection This LED will light up when amplifier works properly. When LED is blue this amplifier is in safe operation.
-
Page 7: Wiring Diagram
PX1200.4 PX1900.4 Wiring Diagram Fig 4. Mono amplifier wiring (SINGLE WOOFER LOAD) P1200.1/P2000.1/P3200.1... - Page 8 Wiring Diagram Fig 5. Mono amplifier wiring (Multi-woofer load) primo series...
- Page 9 Wiring Diagram Fig 8. PX1200.4 / PX1900.4 AMPLIFIER WIRING (3-CHANNEL MODE) 2OHM-4OHM 2OHM-4OHM...
- Page 10 Wiring Diagram Fig 9. PX1200.4 / PX1900.4 AMPLIFIER WIRING (4-CHANNEL MODE) 2OHM-4OHM 2OHM-4OHM 2OHM-4OHM 2OHM-4OHM SPEAKER Signals SPEAKER Signals...
-
Page 11: Troubleshooting
Trouble Shooting... -
Page 12: Specifications
Specifications PX1200.4 px1900.4 P1200.1 P2000.1 P3200.1 PRIMO PRIMO PRIMO PRIMO PRIMO MONO MONO MONO 4-CHANNEL 4-CHANNEL BLOCK BLOCK BLOCK 1600W 600W 1000W 4x240W 4x150W 400W 600W 4x100W 4x150W 2x300W 2x480W 15Hz~25KHz 20Hz~45KHz 50Hz~750Hz 50Hz~6KHz 50Hz~750Hz 20Hz~6KHz THD at 4Ohm load 30% Rated Power 0~12dB BassBoost LEVEL... -
Page 13: Warranty
30 days of purchase. Except as provided herein, Massive Audio, Inc. makes no warranties or representations, express or implied, including any warranty implied by law, whether for merchantability or fitness for a particular purpose and shall be effective only for the period that this express warranty is effective. - Page 14 0040 U.S.A. Copyright 2017 Massive Audio ,Inc. USA Due to constant Improvements all designs and specifications are subject to change without notice. V170918...
