Summary of Contents for SPIDER HSN 02
- Page 1 R O T A R Y S L O P E M O W E R Operation manual Winch HSN 02 original Operation manual Revision 10-04-01-2018 DVOŘÁK – svahové sekačky, s.r.o. Tel: +420 564 036 099 Pohled 277, 582 21 Pohled Mail: info@spider-cz.com...
-
Page 2: Table Of Contents
Operation manual - Winch HSN02 CONTENTS: 1. INTRODUCTION ......................3 2. CONFORMITY CERTIFICATE ..................4 3. PRODUCT DESCRIPTION .................... 5 4. PROHIBITED USE ......................5 5. PRODUCT IDENTIFICATION ..................5 6. SAFETY INSTRUCTIONS ..................... 6 7. SAFETY DECALS ......................7 8. -
Page 3: Introduction
Operation manual - Winch HSN02 1. INTRODUCTION Thank you for purchasing the stabilizing hydraulic winch HSN 02 (further referred to as “winch”). The winch was designed as an accessory for SPIDER ILD01 and SPIDER ILD02 radio-controlled slope mowers (further referred to as “mower” or “machine”) and increases the possibility of their application. The meaning of the word “machine”... -
Page 4: Conformity Certificate
Operation manual - Winch HSN02 2. CONFORMITY CERTIFICATE DECLARATION OF INCORPORATION OF PARTLY COMPLETED MACHINERY DVOŘÁK – svahové sekačky s.r.o. We manufacturer Pohled 277, 582 21 Pohled VAT ID: 26013797 declare that the product name: Stabilizing hydraulic winch model: HSN02 design for: Stabilization of mower on a slope serial number: fullfils all the essential requirements of Directive and the technical documentation... -
Page 5: Product Description
Operation manual - Winch HSN02 3. PRODUCT DESCRIPTION The winch was designed as an accessory to a SPIDER slope mower. The winch is a stabilizing device, which improves the mower stability on slope, prevents the mower from sliding downhill and reduces lawn erosion. -
Page 6: Safety Instructions
Operation manual - Winch HSN02 6. SAFETY INSTRUCTIONS The winch may only be used and operated with SPIDER ILD01 and SPIDER ILD02 slope mowers if these mowers are in a configuration allowing the installation of the winch. For more information contact either the manufacturer or an authorized dealer/service of SPIDER slope mowers. -
Page 7: Safety Decals
Operation manual - Winch HSN02 7. SAFETY DECALS This chapter is devoted to the safety label symbols (pictograms) used on the product and their meaning. Under each symbol you will find a number of the position of the label on the machine. Safety labels inform the operator about risks while using the product. -
Page 8: Protective And Safety Elements Of The Winch
Operation manual - Winch HSN02 9. PROTECTIVE AND SAFETY ELEMENTS OF THE WINCH The winch is supplied in such a condition, which eliminates health and safety risks to the operator and to third persons as well as the risk of damage to their property. For this purpose, the hydraulic circuit is equipped with an electric valve, which closes the oil outlet from the winch and blocks its further use in emergency situations. -
Page 9: Working With The Winch
Operation manual - Winch HSN02 12. WORKING WITH THE WINCH The winch is a device, which extends and improves the mower application possibilities, but it does not allow the operator to use the mower on all slopes. The winch has a folding part, which guides the winding rope on the drum. This part is in the upper position for transport and must be folded down before anchoring. -
Page 10: Anchoring Procedure
Operation manual - Winch HSN02 14. ANCHORING PROCEDURE 1. Transport the mower to the area you want to mow and place it on a level ground under the slope you intend to mow, directly below the anchoring point. 2. Turn the wheels of the mower across the slope (along the contours) 3. -
Page 11: Cutting
15. CUTTING When driving on a slope the operator of the machine must carefully watch and evaluate the movements of the mower and the characteristics of the terrain, especially the momentary adhesion of the wheels to the ground. Pay attention to climatic conditions. Do not rely on the anchoring of the mower on the rope. Climbing ability of the mower will rapidly change on dry, wet or moist grass. -
Page 12: Emergency Situations During Winch Operation
Operation manual - Winch HSN02 Do not drive the mower into bushes or similar obstacles that you want to cut (especially when driving down a slope). These obstacles may stop the mower, cause the rope to unwind undesirably and consequently jam. The rope must always be tight. - If the driving wheels lose contact with the ground, the winch will stop working as a stabilizing device! While working with the mower AVOID:... -
Page 13: Technical Specification
Operation manual - Winch HSN02 STOP button on the remote controller. Exchange all defective parts. Engine stops Immediately turn the driving wheels across the slope (along contours) and push the STOP button on the remote controller. Machine rolls over Immediately push the STOP button on the remote controller. -
Page 14: Maintenance Chart
20. MAINTENANCE CHART every Action / intervals in hours • • x • Check for oil leakage from the hydraulic system • x Check bolt tightness • Check the rope • • x • Check tension and wear of the roller chain •... -
Page 15: Gear Maintenance
Operation manual - Winch HSN02 23. GEAR MAINTENANCE Drum drive chain Check the chain tightness and wearing. If the wear is significant, the risk of the winch failure is increased. This may lead to hazardous situation while operating the mower. The chain can be tensioned by moving the hydraulic motor in its oval mounting holes. -
Page 16: Linking The Snap Hook
25. LINKING THE SNAP HOOK Tie the rope to the snap hook according to the diagram below: Leave at least 8 cm of free rope at the end of the rope. Tighten the knot properly to avoid its loosening. Use a dry process to clean the rope up. Do not use water or chemical liquids. The rope must not come in contact with oil products and lubricants. -
Page 17: Troublesooting
– the whole machine (according to the maintenance schedule – see the Operation Manual for Spider ILD01/ILD02) Before performing any maintenance or other work on the winch you must switch off the mower engine and push the EMERGENCY STOP button. -
Page 18: Warranty Conditions, Service, Spare Parts
2601379 (further referred to as “Manufacturer”) provides a Warranty for new Products according to the set regulations For commercial machines (Spider ILD01, Spider ILD02 and higher) and accessories for the period of 24 months from the day the Product is delivered to the Customer, or from such a Product being set into operation, or up to 800 operating hours, according to whichever happens first. - Page 19 Operation manual - Winch HSN02 12. The Warranty will only be valid subject to the condition that the Product is correctly registered at the Manufacturer´s website within 14 days of the date the Product is delivered to the Customer. 13. The Warranty applies to the Product in the condition in which it leaves the production plant. The Manufacturer is not liable for damage during transportation.
