USB-IDIO-16
USB-IDO-16
USB-IDIO-8
ISOLATED DIGITAL
INPUT / FET OUTPUT
BOARDS
USER MANUAL
File: USB-IDIO-16.A1e
ADL Embedded Solutions Inc., 4411 Morena Blvd., Suite 101, San Diego, CA 92117-4345
P. +1 858 490-0597 F. +1 858 490-0599
e-mail: sales@adl-usa.com; web:
www.adl-usa.com
Advertisement
Table of Contents
Summary of Contents for ADL Embedded Solutions USB-IDIO-16
- Page 1 MODELS USB-IDIO-16 USB-IDO-16 USB-IDIO-8 ISOLATED DIGITAL INPUT / FET OUTPUT BOARDS USER MANUAL File: USB-IDIO-16.A1e ADL Embedded Solutions Inc., 4411 Morena Blvd., Suite 101, San Diego, CA 92117-4345 P. +1 858 490-0597 F. +1 858 490-0599 e-mail: sales@adl-usa.com; web: www.adl-usa.com...
- Page 2 This document may contain or reference information and products protected by copyrights or patents and does not convey any license under the patent rights of ADL Embedded Solutions Inc., nor the rights of others.
-
Page 3: Table Of Contents
Figure 6-2: Isolated Input Pin Assignments (P2) ................13 Figure 6-3: USB-STB-84 Screw Terminal Board ................14 Chapter 7: Specification........................... 15 Isolated Inputs..........................15 Isolated FET Outputs ........................15 Power Required ..........................15 Environmental ..........................15 Customer Comments..........................16 Manual USB-IDIO-16... -
Page 4: Chapter 1: Introduction
The solid state outputs are comprised of sixteen fully protected and isolated FET outputs. The FET’s have built in current limiting and are protected against short-circuit, over- temperature, ESD and inductive load transients. The current limitation is activated until the thermal protection acts. The FET’s are all off at power-on. Manual USB-IDIO-16... -
Page 5: Screw Terminal Accessory Board
When the LED flashes continuously, this signifies that there is data being transmitted over the USB bus. Figure 1-1: Block Diagram Manual USB-IDIO-16... -
Page 6: Ordering Guide
The following components are included with your shipment. Please take time now to ensure that no items are damaged or missing. 1. USB-Isolated Input/FET Output Board (unit installed in labeled enclosure) 2. 6’ USB cable 3. Software Master CD (PDF user manual installed with product package) 4. Printed USB I/O Quick-Start Guide Manual USB-IDIO-16... -
Page 7: Chapter 2: Installation
The board can be installed in any USB 2.0 or USB 1.1 port. Please refer to the USB I/O Quick Start Guide which can be found on the CD, for specific, quick steps to complete the hardware and software installation. Manual USB-IDIO-16... -
Page 8: Chapter 3: Option Selection
FLT-4 IN04 FLT-12 IN12 FLT-5 IN05 FLT-13 IN13 FLT-6 IN06 FLT-14 IN14 FLT-7 IN07 FLT-15 IN15 This additional filtering provides a slower response for DC signals as described previously and must be used when AC inputs are applied. Manual USB-IDIO-16... -
Page 9: Figure 3-1: Option Selection Map
Figure 3-1: Option Selection Map Manual USB-IDIO-16... -
Page 10: Chapter 4: Usb Address Information
The board’s VID is “0x1605", and its PID is “0x8018". The Device Index is determined by how many of the device you have in your system, and provides a unique identifier allowing you to access a specific board at will. Manual USB-IDIO-16... -
Page 11: Chapter 5: Programming
GetDevices(void ) unsigned long QueryDeviceInfo(DeviceIndex, pPID, pName, pDIOBytes, pCounters) unsigned long DIO_Configure(DeviceIndex, bTristate, pOutMask, pData) unsigned long DIO_Write1(DeviceIndex, BitIndex, bData) unsigned long DIO_Write8(DeviceIndex, ByteIndex, Data) unsigned long DIO_WriteAll(DeviceIndex,pData) unsigned long DIO_Read8(DeviceIndex, ByteIndex,pBuffer) unsigned long DIO_ReadAll(DeviceIndex,Buffer) Manual USB-IDIO-16... -
Page 12: Chapter 6: Connector Pin Assignments
Bit 01 FET Supply Voltage OUT01+ Bit 01 Switched (Supply Voltage) Output OUT00- Bit 00 Power Supply Return (or Ground) OUT00VBB Bit 00 FET Supply Voltage OUT00+ Bit 00 Switched (Supply Voltage) Output Figure 6-1: FET Output Pin Assignments (P3) Manual USB-IDIO-16... -
Page 13: Figure 6-2: Isolated Input Pin Assignments (P2)
Isolated Input 13 A IN13 B Isolated Input 13 B IN14 A Isolated Input 14 A IN14 B Isolated Input 14 B IN15 A Isolated Input 15 A IN15 B Isolated Input 15 B Figure 6-2: Isolated Input Pin Assignments (P2) Manual USB-IDIO-16... -
Page 14: Figure 6-3: Usb-Stb-84 Screw Terminal Board
Figure 6-3: USB-STB-84 Screw Terminal Board Manual USB-IDIO-16... -
Page 15: Chapter 7: Specification
For example, when working with AC voltages do not connect the hot side of the line to an input. Tolerance of higher isolation voltage can be obtained on request by applying a conformal coating to the board. Manual USB-IDIO-16... -
Page 16: Customer Comments
Please detail any errors you find and include your mailing address so that we can send you any manual updates. Embedded Solutions ADL Embedded Solutions Inc., 4411 Morena Blvd., Suite 101, San Diego, CA 92117-4345 P. +1 858 490-0597 F. +1 858 490-0599 e-mail: sales@adl-usa.com; web: www.adl-usa.com...
