  • Page 1 AOC-162 User's Manual...
  • Page 2 AOC-162 User's Manual (OM120000036A) Notes: 1. Reproduction of the contents of this manual in part or in whole without the permission of the copyright holder is prohibited. 2. Contents of this manual are subject to change without notice. 3. We made assurance doubly sure on the contents of this manual. However, if you find something questionable, incorrect, or omitted, please contact the shop of purchase.
  • Page 3 AOC-162 User's Manual (OM120000036A) Before Reading User's Manual Following symbols and signal words are used in this manual to ensure that our customer can use this product safely and to prevent the harm to persons or property. Fully understand the meanings of these symbols before reading the body of the manual.
  • Page 4 AOC-162 User's Manual (OM120000036A) CAUTION: ◆ Do not use this product in a watery or humid place. Otherwise it can cause electric shock. ◆ Do not hold the plug of equipment’s power cord with wet hand when connecting it to AC outlet.

  • Page 5: Table Of Contents

    AOC-162 User's Manual (OM120000036A) Table Of Contents Precautions ..............1 Chapter1 Handling of the Product ............. 1 1.1.1 Place to use or store the product............1 1.1.2 Cautions for use of product ............2 After-Sales Service ..............2 1.2.1 User's registration ..............2 1.2.2 Customer Support ..............
  • Page 6 AOC-162 User's Manual (OM120000036A) Image capture limit ..............22 Power over Camera Link (PoCL) ............ 22 Revision History ................23 Inquiry ..................24...

  • Page 7: Chapter1 Precautions

    Chapter1 Precautions Thank you for purchasing「AOC-162」 Please read this user's manual thoroughly to ensure the proper use of this product. Handling of the Product 1.1.1 Place to use or store the product ■Do not use this product at a place where it can be subject to spillage of chemicals etc.

  • Page 8: Cautions For Use Of Product

    AOC-162 User's Manual (OM120000036A) 1.1.2 Cautions for use of product Cautions Be sure to unplug the power code and turn off the power of the system before installing or removing this product. Otherwise it can cause electric shock. ■ Precautions for installing procedure of the product...

  • Page 9: Customer Support

    AOC-162 User's Manual (OM120000036A) 1.2.2 Customer Support For the products inquiries, please contact to the support line below. Customer service AVAL DATA CORPORATION (URL http://www.avaldata.co.jp/) Head Quarters / Machida OFFICE SALES DEPARTMENT 1-25-10, Asahimachi, Machida-shi, Tokyo TEL 042-732-1030 FAX 042-732-1032 Business hours ：Monday-Friday 9:00AM-17：00PM(except for a national holiday)

  • Page 10: Serial Number

    AOC-162 User's Manual (OM120000036A) 1.2.4 Serial number The serial number of the product is printed on the label on the main unit(case and substrate), the warranty certificate, the box, given each. Location of the serial number label of the product is shown below.

  • Page 11: Dealing With Occurrence Of Failure Or Abnormality

    AOC-162 User's Manual (OM120000036A) 1.2.5 Dealing with occurrence of failure or abnormality When the following failure or abnormality occurred on the module, turn off the power of the system immediately and pull out the plug of power cord from AC outlet.

  • Page 12: In The Case Of Transferring The Product To A Third Party

    AOC-162 User's Manual (OM120000036A) 1.2.8 In the case of transferring the product to a third party A) User who transfers the product Following conditions shall be satisfied when the product is transferred to a third party. ・All attachments to the module (instruction manual, warranty certificate, accessories, etc.) shall be transferred.

  • Page 13: Chapter2 General Description

    AOC-162 User's Manual (OM120000036A) Chapter2 General Description This chapter describes general description of this product Product Summary This product is an unit for converting Camera Link into Opt-C:Link. This product has two SFP+ connectors. It can connect with two Base Configuration cameras.

  • Page 14: Specifications

    AOC-162 User's Manual (OM120000036A) Specifications The specifications of this product are described as follows. Table2-3 specifications CameraLink I/F CameraLink BaseConfiguration 2ch Two connector of SDR26pin Area camera and Line camera correspondence Opt-C:Link I/F Access Speed : 6.25Gbps Access Mode : MultiMode...

  • Page 15: Block Diagram

    AOC-162 User's Manual (OM120000036A) Block Diagram Block Diagram of this product. SDR(26pin) SDR(26pin) CameraLink CameraLink Receiver Receiver FPGA ArriaⅡGX EP2AGX45 CU17I3N Module Module DC+12V / External trigger Figure2-4 block diagram - 9 -...

  • Page 16: Case Outline View

    AOC-162 User's Manual (OM120000036A) Case outline view Case outline view of this product is shown below. HDR-EC26LFDT1-SLD+（HONDA TSUSHIN KOGYO） HR10A-10R-12S （HIROSE ELECTRIC） SFP+connector AFBR-57D7AMZ （AVAGO Technologies） Figure2-5 case outline view - 10 -...

  • Page 17: Connector Pin Configuration

    AOC-162 User's Manual (OM120000036A) Connector pin configuration Connector of this product is shown below. 2.6.1 Optical Connector (OPT OUT 1、OPT OUT 2) This is an optical connector for connecting between the equipment of Opt-C:Link. Connector form is SFP+. Manufacture：AVAGO Technologies Model ：AFBR-57D7AMZ...

  • Page 18: Camera Link Connector(Cl In1、Cl In2)

    AOC-162 User's Manual (OM120000036A) 2.6.2 Camera Link Connector(CL IN1、CL IN2) This is a SDR connector corresponding to Camera Link. Manufacture：HONDA TSUSHIN KOGYO Model ：HDR-EC26LFDT1-SLDP Figure2-6-2 Camera Link Connector - 12 -...
  • Page 19 AOC-162 User's Manual (OM120000036A) Table2-6-2_1 CL IN 1 PinAssign Signal Signal NC/+12V(PoCL) CC4- CC4+ CC3+ CC3- CC2- CC2+ CC1+ CC1- SerTFG+ SerTFG- SerTC- SerTC+ XCLK+ XCLK- NC/+12V(PoCL) Table2-6-2_2 CL IN 2 PinAssign Signal Signal NC/+12V(PoCL) CC4- CC4+ CC3+ CC3- CC2-...

  • Page 20: Powerconnector(Dc In)

    AOC-162 User's Manual (OM120000036A) 2.6.3 PowerConnector(DC IN) This is 12pin round shape connector. Manufacture：HIROSE ELECTRIC Model ：HR10A-10R-12S Figure2-6-3 PowerConnector Table2-6-3 PowerConnector PinAssign PinNumber Name Power Input(DC+12V) External trigger ch1 (Refer to Chapter External trigger ch2 (Refer to Chapter - 14 -...

  • Page 21: Settings And Interface

    AOC-162 User's Manual (OM120000036A) Chapter3 Settings and Interface Hardware initial setting of this product Hardware initial setting Before attaching this product, you need to set up the jumpers and the switches correctly. 3.1.1 CH1_PoCL、CH2_PoCL Setup CH1_PoCL and CH2_PoCL respectively are the jumpers for PoCL setup of CH1 and CH2.

  • Page 22: Attachment Of A Case / Removal

    AOC-162 User's Manual (OM120000036A) 3.1.2 Attachment of a case / removal ・Removal of the cover of a case a) Before removing this product, be sure to turn OFF the power supply of a system. It causes breakdown. *This product should be careful to be high temperature immediately after the power supply OFF.
  • Page 23 AOC-162 User's Manual (OM120000036A) Figure 3-1-2_2 mounting dimension - 17 -...

  • Page 24: Connection Of The Optical Cable

    AOC-162 User's Manual (OM120000036A) 3.1.3 Connection of the optical cable Connection of the optical cable of this product is shown below. Insert it close with a snapping motion, because the optical cable is a lock mechanism. Figure 3-1-3 connection of the optical cable The optical cable for connecting this product and frame-grabber should meet the following specification.

  • Page 25: Connection Of The Cameralink Cable

    AOC-162 User's Manual (OM120000036A) 3.1.4 Connection of the CameraLink Cable Connection of the CameraLink Cable of this product is shown below. CameraLink connector is using the screw lock of a SDR connector. Turn a screw lock and fix, after inserting a CameraLink cable.

  • Page 26: Connection Of The Power Supply Cable

    AOC-162 User's Manual (OM120000036A) 3.1.5 Connection of the power supply cable Connection of the power supply cable of this product is shown below. Insert it close with a snapping motion, because the optical cable is a lock mechanism. Figure 3-1-5 connection of the power supply cable...

  • Page 27: Chapter4 Function

    AOC-162 User's Manual (OM120000036A) Chapter4 Function This chapter describes Function of this product. CameraLink→Opt-C:Link This product is a box for converting Camera Link into Opt-C:Link. This product has mounted two SFP+ connectors and can connect the two Base cameras at one this product.

  • Page 28: Image Capture Limit

    AOC-162 User's Manual (OM120000036A) Image capture limit There is restriction about Image capture. The restriction of line size depends on tap number. The maximum line size inputted is shown in Table 4-3. Table 4-3 line size limit Tap number Maximum line size (pixel)

  • Page 29: Revision History

    AOC-162 User's Manual (OM120000036A) Revision History Version Revised Date Revised Contents 2012.11.16 First edition Ａ - 23 -...

  • Page 30: Inquiry

    AOC-162 User's Manual (OM120000036A) Inquiry AOC-162 User's Manual November 16, 2012 first edition edit AVAL DATA CORPORATION publish AVAL DATA CORPORATION ○ OM120000036A C 2012 AVALDATA CORPORATION Head Quarters Machida office Sales department 1-25-10, Asahimachi, Machida-shi, Tokyo, 194-0023 TEL 042-732-1030 FAX 042-732-1032 :http://www.avaldata.co.jp/...
