Summary of Contents for Vytronix PW1500
- Page 1 P W1 5 0 0 H I G H P E R F O R MA N C E P R E S S U R E WA S H E R I N S T R U C T I O N MA N U A L w w w .
- Page 2 BLANK PAGE...
- Page 3 WARNING: Do not use the appliance without reading the instruction manual. Technical Specification • Voltage: 220-240V 50/60Hz • Power: 1500W • Working Pressure: 70bar • Pressure(max): 105bar • Flow: 5.5L/per min Contents 1. Jet nozzle 2. Pressure lance 3. Pressure gun 4.
- Page 4 30cm. • It is your responsibility to check the suitability of surface to be cleaned, Vytronix cannot be held responsible for any damage caused by use. • Please keep the appliance away from open fires and heat sources, do not leave exposed for prolonged periods of time to direct sunlight and avoid exposure to rain, snow or frost.
- Page 5 • If the power cord is damaged, it must be replaced only by Vytronix to comply with warranty terms and conditions. • Do not let children or people who have not been trained in the use of a pressure washer nor read the instruction manual operate the machine unless properly supervised by a responsible adult.
- Page 6 2. First time instructions This section will explain in detail how to make your pressure washer ready for use. SAFETY FEATURES Trigger lock: The trigger gun features a locking device. When the knob is activated, the trigger gun cannot be operated. →...
- Page 7 3. Connecting a garden hose 1. Screw the inlet adaptor (1) tightly on to the water inlet with the provided water filter in place. Note: The inlet filter (A) must always be fitted in the water inlet pipe to filter out sand, lime stone and other impurities as these will damage the pump valves.
- Page 8 3.2 Connecting the lance and nozzle 1. Push the lance into the pressure gun. 2. When fully inserted twist in the direction illustrated below to lock. Check by pulling the two parts afterwards to ensure the lance is secure. 3. Attach the jet nozzle by pushing on to the end of the lance. When the jet nozzle is correctly attached, the release button should audibly click.
- Page 9 3.4 Start/stop of the machine IMPORTANT: Place the pressure washer on firm, level surface during operation, do not sit the pressure washer in long grass as objects may enter the vents or openings. Do not cover the machine during operation, use it indoors or in any area without adequate ventilation.
- Page 10 4. After use instructions Pump, hose and accessories should always be emptied of water prior to storing as follows: 1. Switch off the machine and detach water inlet hose. 2. Restart the machine and in short bursts, briefly activate the trigger of the pressure gun until no more water runs through the pressure gun.
- Page 11 • To ensure easy connection of components and to prevent perishing of seals and O-rings, the threaded couplings and connections may be occasionally treated with an appropriate lubricating grease. • Only allow repairs to be carried out by Vytronix.
- Page 12 Connect inlet water. Machine starts but Water filter blocked Clean the filter. no water comes Nozzle blocked Clean the nozzle with a needle and by spraying water backwards through the nozzle. For further advice, information or assistance please contact Vytronix.
- Page 13 7. Warranty To register you free one year Vytronix guarantee visit www.vytronix.com using product code: brandnew-vytronix-pw1500 8. Safe disposal This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to...
- Page 14 R e g i s t e r y o u r w a r r a n t y a t w w w . v y t r o n i x . c o m...
