Read this instruction manual before using the product in order to achieve maximum performance.
Keep this instruction manual within your reach after reading so that it can be used at any time.
28, Namyang-ro 930beon-gil, Hwaseong-si, Gyeonggi-do, Korea
Tel 82.31.299.5453 Fax 82.31.357.2610
Instruction Manual
ION BLOWER
AMF-AE Series
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DONG IL TECHNOLOGY LTD AMF-AE1
Summary of Contents for DONG IL TECHNOLOGY LTD AMF-AE1
- Page 1 Instruction Manual ION BLOWER AMF-AE Series Read this instruction manual before using the product in order to achieve maximum performance. Keep this instruction manual within your reach after reading so that it can be used at any time. 28, Namyang-ro 930beon-gil, Hwaseong-si, Gyeonggi-do, Korea Tel 82.31.299.5453 Fax 82.31.357.2610...
-
Page 2: Table Of Contents
DONG IL TECHNOLOGY LTD CONTENTS 1. Product Introduction…………………………………………………………… 03Page 1.1 Features 1.2 Specification 1.3 Dimensions 1.4 Performance 1.5 Package contents 1.6 Parts’ names and functions 2. Installation……...………..……………………………………………....09Page 2.1 Installation 2.2 Wiring diagram 2.3 Cautions 3. Cautions & Maintenance………….………………………….….………….. 12Page 3.1 Cautions for operation... -
Page 3: Features
1. 제품 소개 DONG IL TECHNOLOGY LTD 1.1 Features Welcome to become a DIT customer! AMF-AE series is a pulsed AC ion blower neutralizing static electricity using Corona Discharge method. AMF-AE series, • is easy to maintain with auto cleaning function for emitter pin. -
Page 4: Dimensions
DONG IL TECHNOLOGY LTD 1.3 Dimensions Category Code Length [mm] Remarks Controller 54.6 Fan Module 170.0 Space Box 56.6 Side Cover 18.6 Bracket Ass'y Height 217.8 Width 106.1 Bracket Height 173.6 Bracket Width 97.5 Bracket Depth 68.0 Blower Length Min. Length... - Page 5 DONG IL TECHNOLOGY LTD 1.3 Dimensions Category Code Length [mm] Remarks Controller 54.6 Fan Module 170.0 Space Box 56.6 Side Cover 18.6 Bracket Ass'y Height 217.8 Width 106.1 Bracket Height 173.6 Bracket Width 97.5 Bracket Depth 68.0 Min. Length (2Fans) Blower Length Min.
-
Page 6: Performance
DONG IL TECHNOLOGY LTD 1.4 Performance . Relation between Distance and Decay Time . Relation between Distance and Decay Time ． Fan Speed: L 5 ． Frequency : 30Hz ． Measure Condition: 1kV →100V ．Charged plate size : 150 x 150㎜... -
Page 7: Package Contents
DONG IL TECHNOLOGY LTD 1.5 Package contents Be sure to check the package contents before installation. ① Main body ② Standard brackets ③ AC power cable [1,800㎜] ④ DC Power Cable 1500mm (Including ground wire) ⑤ Remote controller ⑥ RJ45 CABLE (8Pin) [PLC/RS485 Communications] ※... -
Page 8: Parts' Names And Functions
DONG IL TECHNOLOGY LTD 1.6 Parts’ names and functions <Front-side> ⑤ ④ ③ ⑥ ① ② ① Control - Display operation condition, menu and setting value - Control on/off AC input power ② Air outlet and front cover ③ Emitter fixing cover ④... - Page 9 DONG IL TECHNOLOGY LTD 1.6 Parts’ names and functions <Controller> <Display and control function> ① DISPLAY Display operation condition, menu and setting value ② Remote Control receiver ① ③ Output power alarm (LED Green/Red) Shows the state of ion emissions ②...
- Page 10 ⑤ ① ② ③ ① AC POWER Connector ② DC POWER Connector (Only for AMF-AE1 Model) - Be sure to check a diagram(page 13.) before wiring. ③ RJ 45 Connector - PLC cable, RS485 communication ④ Filter Cover Lock ⑤ Air inlet...
- Page 11 DONG IL TECHNOLOGY LTD 1.6 Parts’ names and functions <Bracket> ① ② ③ ① Tilt hole - Use this hole if you need to adjust angle. ② Height hole - Use this hole if you need to adjust height. ③ Main body fixing hole...
-
Page 12: Installation
DONG IL TECHNOLOGY LTD 2.1 Installation ① Install this blower making sure no obstruction between the blower and the target object. Separate air outlet part and target object, air inlet part and any object such Warning as wall minimum 150mm to keep air flow smoothly. -
Page 13: Wiring Diagram
DONG IL TECHNOLOGY LTD 2.2 Wiring diagram < 24V DC Power Input Cable > PIN No. Color Connection & Usage ① Black Power Ground (DC Power Ground) ② White Power Ground (DC Power Ground) ③ Yellow +24V DC Power Supply ④... - Page 14 DONG IL TECHNOLOGY LTD 2.2 Wiring diagram <AMF-AE Series PLC(NPN Type) Circuit Diagram> 4. Orange: PLC P상 (DC +24V) DC 24V INPUT 2. Brown: HVPS Alarm Signal LOAD 7. Blue: Fan Alarm Signal LOAD 3. Red: PLC N상 (GND) 5. Yellow: PLC Clean Signal PLC CLEAN S/W 6.
- Page 15 DONG IL TECHNOLOGY LTD 2.2 Wiring diagram <AMF-AE Series PLC(NPN Type) I/O Table> Switch Display PLC Alarm ‘nc’ PLC Alarm ‘no’ Close Ion ‘on’ Open High Close Ion ‘off’ Open High HVPS error / Fan error /Er4 PLC cleaning signal input...
-
Page 16: Cautions
DONG IL TECHNOLOGY LTD 2.3 Cautions ① Supply power only after you make sure that the power cable is wired correctly according to the wiring diagram in page 11. ② Ground installed equipment and ionizer. No grounding may cause malfunction. -
Page 17: Cautions For Operation
DONG IL TECHNOLOGY LTD 3.1 Cautions for operation ① Before connect the power cable, be sure to check the power supply specification and wiring diagram. ② Don’t touch the product with a hand or other material during operation because high voltage is generated. -
Page 18: Cleaning & Replacement Of Ion Emitters
DONG IL TECHNOLOGY LTD 3.2 Cleaning & replacement of ion emitters Auto pin cleaning function operation method ① Using the button on a front side. - When PIN CLN key on a controller be pressed , auto pin cleaning function is started. - Page 19 DONG IL TECHNOLOGY LTD 3.2 Cleaning & replacement of ion emitters Manual cleaning method of pin and cover ① Be sure to disconnect power before cleaning or replacement of ion emitters. ② Separate the fan cover. Fan cover is designed to be grabbed easily by a right hand. Grab the fan cover, turn it counter clockwise a little bit and pull it toward the body .
-
Page 20: Settings
DONG IL TECHNOLOGY LTD 4. 1 How to set values When using key panel When using remote controller Entering address with number key Entering Menu mode and Press “Menu” key: “MnU” is displayed Entering right address display “SEL” on the panel. Press OK to enter the finding an option on FND. -
Page 21: Explanation On Menu Options
DONG IL TECHNOLOGY LTD 4. 2 Explanation on Menu options Menu Description Remark Assigning “A01” – “A63” is allowed (up to 63 units). If there are duplicated addresses, controlling the system with Setting Address a remote controller may result in false operation by controlling a wrong unit. -
Page 22: Appendix
APPENDIX DONG IL TECHNOLOGY LTD Trouble shooting Problem Inspection . Check the power supply status. . Check the power cable connection in back Both LED and fan don’t work side of the product . If the product doesn’t work after checking all above, please contact your dealer. -
Page 23: Warranty
DONG IL TECHNOLOGY LTD Warranty We, Dong Il Technology Ltd. Manufactured this product under a strict quality control system and guarantee its quality for1 year of period from the shipment date. However, we don’t take any responsibility for 1) Any damage if the product is used in a way different from that is explained in this manual or remade by users arbitrarily.
