KILLARK MCX Series Installation, Operation & Maintenance Manual

CAUTION:
Before installing, make sure you are compliant with area classifications, as failure to do so may result in bodily injury, death and property damage. Do not
attempt installation until you are familiar with the following procedures. All installation must comply with the applicable Electrical Code(s).
Make sure that the circuit is de-energized before starting installation or maintenance.
Verify that the installation is grounded. Failure to ground will create electrical shock hazards, which can cause serious injury and or death.
IMPORTANT:
Please read these instructions carefully before installing or maintaining this equipment. Good electrical practices should be followed at all times and this
data should be used as a guide only.
Technical information, advice and recommendations contained in these documents is based upon information that Killark believes to be reliable. All the
information and advice contained in these documents is intended for use only by persons having been trained and possessing the requisite skill and know-
how and to be used by such persons only at their own discretion and risk. The nature of these instructions is informative only and does not cover all of the
details, variations or combinations in which this equipment may be used, its storage, delivery, installation, check out, safe operation and maintenance.
Since conditions of use of the product are outside of the care, custody and control of Killark, the purchaser should determine the suitability of the product
for his intended use, and assumes all risk and liability whatsoever in connection therewith.
Class I, Division 1, Groups A, B, C, D
Class II, Division 1, Groups E, F, &G; Class III.
Type 3, 4, and 4X, IP66, Operating Temperature Range -50°C +60°C
Armored Cable Assembly
USE FOR TYPE MC, MC-HL, TECK90,
TECK90-HL, RA90, RA90-HL, AC90, AC90-
HL, ACWU90, & ACWU90-HL CABLE.
SEE PAGES: 2-3
P/N KIL 00921499 FORM NO, K1499 MCX Series Cable Glands
HUBBELL ELECTRICAL PRODUCTS
A Division of HUBBELL INCORPORATED
(Delaware)
3940 Martin Luther Kind Drive
St. Louis, Missouri 63113 USA
MCX SERIES CABLE GLANDS
INSTALLATION, OPERATION &
MAINTENANCE DATA SHEET
MCX CABLE GLANDS
For use in Zone Classified Hazardous Locations
Tray Cable Assembly
REMOVE GROUNDING SPRING TO USE WITH
TYPE TC-ER-HL, TC, TC-ER, PLTC, PLTC-ER,
ITC, ITC-ER, MV & MARINE SHIPBOARD CABLE.
SEE PAGES: 4-7
Page 1 of 7
